Поз.
Артикул
Описание
196
SWITCH LIQUID TANK, 023 060688 033 029143 123 043369 130 055527
205
SEAL RING FROM EXPANSION VALVE TO COMPRESSOR
214
SWITCH AT LIQUID TANK,FOR ADDITIONAL BLOWER
214
SWITCH
589
CONDENSER
589
CONDENSER ,A 496760
589
CONDENSER
589
CONDENSER
591
CONDENSER
591
CONDENSER
595
CLAMP FORKED SUPPORT,TOP
596
SHEET METAL SCREW BRACKET TO CAB FLOOR
597
SPRING CONDENSER TO STIFFENING AND TO FRONT CROSS MEMBER
606
INTERMEDIATE LAYER CONDENSER TO STIFFENING AND TO FRONT CROSS MEMBER
615
GROMMET CONDENSER TO FRONT CENTRAL STIFFENING AND TO SUPPORT,BOTTOM
624
TANK , Replaced By: A1268300383, +001A0048200710
624
TANK LIQUID TANK TO CONDENSER
633
SHEET METAL SCREW BRACKET TO CAB FLOOR
642
BRACKET ADDITIONAL BLOWER TO FRONT CENTRAL STIFFENING
660
BRACKET ADDITIONAL BLOWER TO FRONT CENTRAL STIFFENING,126.A036919
660
BRACKET ADDITIONAL BLOWER TO FRONT CENTRAL STIFFENING, FROM CHASSIS: 126.120 A 036920
660
BRACKET ADDITIONAL BLOWER TO FRONT CENTRAL STIFFENING
670
GROMMET BREATHER LINE
678
LOCK
687
SHEET METAL SCREW
689
LOCK WASHER PLUG SOCKET TO REAR CROSS MEMBER
691
COMBINATION BOLT
701
CLAMP , FROM CHASSIS:107.024 018638 107.044 041612
706
GROMMET REFRIGERANT LINE THRU FIRE WALL
762
PIPE LINE FROM LIQUID TANK TO EXPANSION VALVE
769
PIPE LINE
769
PIPE LINE FROM CONDENSER TO LIQUID TANK
780
PIPE LINE FROM COMPRESSOR TO CONDENSER, FOR REPAIR PURPOSES ONLY
790
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR PIPE LINE
798
PIPE LINE (SUCTION LINE),FROM EXPANSION VALVE TO FIRE WALL
800
PIPE LINE (DELIVERY LINE),FROM EXPANSION VALVE TO FIRE WALL
832
SEAL RING HOSE TO CONDENSER 14 MM
841
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
850
O-RING HOSE TO EXPANSION VALVE 17X2
999
MOUNTING , FOR REPAIR PURPOSES ONLY
999
MOUNTING , FOR REPAIR PURPOSES ONLY
