Поз.
Артикул
Описание
330
GASKET KIT , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
332
TRANSMISSION CASE , 016,018,019 FROM TRANSMISSION 041342, 057,058 FROM TRANSMISSION 001648
335
STUD BOLT
490
DRIVE GEAR
505
TRANSMISSION CASE COVER , 669557
507
PLUG
509
GASKET
511
SEAL RING
515
SHAFT
517
DRIVE GEAR
521
SCREW
523
SCREW MOUNTING AND RAIL TO LEAF SPRING
525
SCREW , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
527
WASHER COVER PLATE TO COVER PLATE
527
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
529
WASHER RADIATOR TO RUBBER MOUNTING
529
WASHER , Replaced By: N000125010532
531
FLANGE
533
NUT
535
SCREW PLUG , Replaced By: A0009972632
537
SCREW PLUG
537
SCREW PLUG , Replaced By: A2109970132
539
SEAL RING OIL FILLING AND OIL DRAIN
540
TRANSMISSION CASE COVER , Replaced By: A1152611618, +001A1152610243, +001A0059978647
540
TRANSMISSION CASE COVER , Replaced By: A6022610218
540
TRANSMISSION CASE COVER , UP TO CHASSIS: 023 009860 UP TO TRANSMISSION: 766040
542
SEAL RING
544
GASKET KIT TRANSMISSION CASE FRONT COVER
546
GUIDE TUBE SEE FIG. NO.: 152A
547
SCREW , Replaced By: N304017006018
547
COMBINATION BOLT , Replaced By: N000933006103, +001N000137006204
547
SCREW COVER PLATE TO COVER PLATE M 6 X 12
549
SPACER WASHER AS REQUIRED 0.10 MM, UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
551
GASKET , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359 INCLUDED IN REPAIR KIT 115 586 00 26
552
WASHER COVER PLATE TO COVER PLATE
552
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
553
SCREW BRACKET TO TRANSMISSION M 7X22,556500
558
SHIFTING FORK 3RD AND 4TH SPEED, UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
558
SHIFTING FORK
560
SHIFTING FORK
560
SHIFTING FORK , Replaced By: A6022650501
561
TRANSMISSION CASE COVER , Replaced By: A1172603113, +001A1152603873
561
TRANSMISSION CASE COVER
562
BUSHING
563
NEEDLE BEARING
563
NEEDLE BEARING , Replaced By: A0109816010
564
CYLINDRICAL PIN
565
GASKET
568
DETENT , 016 FROM CHASSIS 027622 ALSO INSTALLED ON, SEE FOOTN.11,018 FROM CHASSIS 028985 ALSO INSTALLED ON,SEE FOOTN.56,019 FROM CHASSIS 029326
569
PIN
571
SPRING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
572
SPRING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
573
BALL , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
575
SCREW PIPE CLAMP
575
SCREW , Replaced By: N304017008021
576
WASHER , Replaced By: N000125008443
576
WASHER EXHAUST MUFFLER TO STRAP
578
DETENT , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
579
DETENT 3RD AND 4TH SPEED
579
DETENT , Replaced By: A1152603873, +001A0049815510
580
SEAL RING
581
BREATHER , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
582
SNAP RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
583
WASHER COVER TO P.T.O. CASE
583
WASHER , Replaced By: A0039906840
584
LOCK PLATE INTERMEDIATE BEARING
586
SHAFT
587
SEAL RING
588
LOCK PLATE INTERMEDIATE BEARING
589
SCREW
591
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
591
WASHER COVER PLATE TO COVER PLATE
999
NUT RETAINER , Replaced By: A0019906791
999
NUT RETAINER , Replaced By: A0009902291, +001N914130006100
999
BALL , 054531
999
NUT RETAINER LICENSE PLATE TO BRACKET
999
NEEDLE BEARING 3RD SPEED
999
BALL BEARING
999
BALL BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
NEEDLE BEARING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
NEEDLE BEARING 3RD SPEED, 016 FROM CHASSIS 027622 ALSO INSTALLED ON, SEE FOOTN.11,018 FROM CHASSIS 028985 ALSO INSTALLED ON,SEE FOOTN.56,019 FROM CHASSIS 029326
999
NEEDLE BEARING 3RD SPEED, 016 FROM CHASSIS 027622 ALSO INSTALLED ON, SEE FOOTN.11,018 FROM CHASSIS 028985 ALSO INSTALLED ON,SEE FOOTN.56,019 FROM CHASSIS 029326
999
NEEDLE BEARING , 016 FROM CHASSIS 027622 ALSO INSTALLED ON, SEE FOOTN.11,018 FROM CHASSIS 028985 ALSO INSTALLED ON,SEE FOOTN.56,019 FROM CHASSIS 029326
999
NEEDLE BEARING 1ST AND 2ND SPEED
999
PLUG HOUSING
999
SEAL RING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
TRANSMISSION CASE COVER , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTN.11,018 UP TO CHASSIS 028985 EXCEPT FOR SEE FOOTN.56,019 UP TO CHASSIS 029325
999
REPAIR KIT , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTN.11,018 UP TO CHASSIS 028985 EXCEPT FOR SEE FOOTN.56,019 UP TO CHASSIS 029325
999
GEAR , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
999
COUNTERSHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 414557, 002,003,005,011,017 FROM TRANSMISSION 011431
999
TRANSMISSION CASE
999
GEAR , 016 FROM CHASSIS 007396-027622 ALSO INSTALLED ON,SEE FOONT.11,018 FROM CHASSIS 006394-028985 ALSO INSTALLED ON,SEE FOOTN.56, 019 FROM CHASSIS 029325
999
SYNCHRONIZER BODY 3RD AND 4TH SPEED, 016 FROM CHASSIS 007396-027622 ALSO INSTALLED ON,SEE FOONT.11,018 FROM CHASSIS 006394-028985 ALSO INSTALLED ON,SEE FOOTN.56, 019 FROM CHASSIS 029325
999
TRANSMISSION
999
SLIDING COLLAR , NO LONGER AVAILABLE
999
SYNCHRONIZER BODY , NO LONGER AVAILABLE
999
BUSHING , 024/025 UP TO CHASSIS 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,00 2763,002797,002862
999
WASHER1.0 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
WASHER0.5 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
WASHER 0.30 MM, ON SPECIAL REQUEST, FLOOR SHIFT
999
WASHER
999
BUSHING
999
END PIECE
999
SHIFT LEVER , Replaced By: A1232601139, +001A1262670110, +001A1232670097, +001A1152680950, +001N007346040010, +001N070616010003
999
SHIFT LEVER , Replaced By: A1152603639, +001A1152603839, +001A1152604239
999
SHIFT LEVER , Replaced By: A1152603739, +001A1152603839, +001A1152604339
999
SYNCHRONIZER BODY , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359, Replaced By: A1152604445, +002A1152623034
999
SHIFT LEVER , Replaced By: A1152603839, +001A1152604239, +001A1152604339
999
SHIFT LEVER , Replaced By: A1152604339, +001A1152604139, +001A1152604239
999
SHIFT LEVER , Replaced By: A1152604239, +001A1152604139, +001A1152604339
999
SHIFT LEVER , Replaced By: A1152604139, +001A1152604239, +001A1152604339
999
SHIFTING TUBE , 114.005,007,015 105875 114.010 075500 114.021 008262 114.022 020445 115.000,002,010 095742 115.015 116805 115.100,102,110 246475 115.115 123400
999
LEVER , Replaced By: A1152603839, +001A1152604239, +001A1152604339
999
LEVER , Replaced By: A1152603639, +001A1152603839, +001A1152604239
999
LEVER , Replaced By: A1152603739, +001A1152603839, +001A1152604339
999
LEVER , Replaced By: A1152603839, +001A1152604239, +001A1152604339
999
LEVER , Replaced By: A1152603639, +001A1152603839, +001A1152604239
999
LEVER , Replaced By: A1152603739, +001A1152603839, +001A1152604339
999
GASKET
999
THRUST WASHER AS REQUIRED 3.9 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 4.0 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 4.1 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 4.2 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
SYNCHRONIZER RING 1ST AND 2ND SPEED, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
SYNCHRONIZER RING 3RD AND 4TH SPEED, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
SHIFT LEVER , Replaced By: A1232601139, +001A1262670110, +001A1232670097, +001A1152680950, +001N007346004010, +001N070616010003
999
BUSHING , 011483
999
BUSHING FROM LEVER TO VALVE BODY ASSEMBLY
999
SLEEVE BRACKET TO PEDAL BEARING BRACKET
999
SNAP RING AS REQUIRED 2.1 MM, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
SYNCHRONIZER BODY , Replaced By: A1172603045, +002A1152622934
999
TRANSMISSION , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A1172603401
999
TRANSMISSION , NOT USED
999
REVERSE IDLER SHAFT , 016,018,019 UP TO CHASSIS 041341, 057,058 UP TO CHASSIS 001647 016 FROM CHASSIS 027622 ALSO INSTALLED ON, SEE FOOTN.11,018 FROM CHASSIS 028985 ALSO INSTALLED ON,SEE FOOTN.56,019 FROM CHASSIS 029326
999
THRUST WASHER 4.50 MM
999
THRUST WASHER , NOT USED
999
THRUST WASHER , Replaced By: A1202622062
999
THRUST WASHER AS REQUIRED
999
BOOT
999
SPACER WASHER 0.20 MM
999
SPACER WASHER 0.2 MM
999
SPACER WASHER 0.3 MM
999
SPACER WASHER 0.30 MM
999
SNAP RING , Replaced By: A1369940935
999
SNAP RING 2.05 MM
999
THRUST WASHER 3.90 MM
999
THRUST WASHER 4.00 MM
999
THRUST WASHER 4.10 MM
999
THRUST WASHER AS REQUIRED 4.20 MM
999
THRUST WASHER AS REQUIRED 4.30 MM
999
THRUST WASHER 4.40 MM
999
THRUST WASHER 4.50 MM
999
SHIFTING FORK 1ST AND 2ND SPEED
999
BUSHING
999
SPACER WASHER 0.25 MM
999
SPACER WASHER 0.50 MM
999
WASHER COVER PLATE TO COVER PLATE
999
WASHER
999
LOCK WASHER TAIL LAMP TO BRACKET
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
HEADLESS SETSCREW , Replaced By: A1109900110, +001N000137010101
999
SCREW , Replaced By: N000933006194
999
SCREW
999
SCREW YOKE TO SHIFTING TUBE
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW , Replaced By: N304017008043
999
SCREW , Replaced By: N304017010050
999
SCREW , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
SCREW CAB FLOOR COVERING M 6X25
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N304032008006
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT
999
SNAP RING , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
999
NUT
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW VALVE TO BRACKET M 8X55
999
SCREW , Replaced By: N304017010055
999
NUT
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
