Поз.
Артикул
Описание
118
ACCESSORIES
119
ACCESSORIES
124
ELECTRIC CABLE
126
PLUG TRIPLE
126
PLUG , Replaced By: A0045458628
126
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
126
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
128
PLUG , Replaced By: A0055451328
128
PLUG , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0065458028, +006A0015453726, +001A0095453028
128
PIN BUSHING HOUSING 4-POLE
130
PLUG , Replaced By: A0045458628
130
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
130
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
130
PLUG TRIPLE
137
SWITCH , FROM CHASSIS: 010 088660 110 226324
138
BULB , Replaced By: A6885447093
145
KNOB INSTRUMENT PANEL
148
ESCUTCHEON
150
SWITCH. RELAY HEATED REAR WINDOW PANE, 033 013155 EXCEPT FOR 013129,013132,013134,013135,013139,013141,013142,013143-013154.
153
SHEET METAL SCREW
155
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
155
WASHER , Replaced By: N009021005205
158
FUSE BOX , Replaced By: A0005459901
158
FUSE BOX BIPOLAR,K 100807 MIT AUSNANME VON K 093739
160
FUSE , Replaced By: A0005458334
160
FUSEA16
162
SHEET METAL SCREW CABLE CONNECTOR TO RIGHT WHEEL ARCH PANEL
165
CABLE CONNECTOR , FROM CHASSIS:108.016 050831 108.018 053598 108.019 054235
168
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
168
SCREW , Replaced By: N007985004107
169
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
169
LOCK WASHER T-FITTING TO BRACKET
175
GROMMET
180
GROMMET BLINKER LAMP BRANCH-OFF
183
CLAMP , Replaced By: N072571001035
187
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
191
CLIP WIRE CABLE TO AIR CLEANER
193
LOCK WASHER T-FITTING TO BRACKET
193
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
195
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
999
PLASTIC SECTION
999
SWITCH , Replaced By: A1078200010
999
INNER MOULDING RIGHT LATERAL, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 000,002,010 039786 015 038832 100,102,103,110 091421 112 089799 115 041839 005,017,105,107,108,117,119 000001
999
INNER MOULDING RIGHT TOP, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 000,002,010 039041 015 037838 100,102,103,110 089270 112 089799 115 040797 005,017,105,107,108,117,119 000001
999
GARNISH MOULDING RIGHT, FROM CHASSIS: 015,115 200001 110 400001 005,017,105,107,108,117,119 000001
999
FRAME RIGHT, FROM CHASSIS: 015,115 200001 110 400001 005,017,105,107,108,117,119 000001
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
