Поз.
Артикул
Описание
9
REAR SEAT CUSHION IMITATION LEATHER, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 010 105672 110 277011, ALSO INSTALLED ON: 275349,275350,276194,276195,276539,276540,276823,276869,276871,276879,276880,276885,276886,276895, 276928,276964,276969.
11
CUSHION FRAME , FROM CHASSIS: 015 250811 017 038250 110 440114 114 006350 115 266006 117,119 075815
15
PAD
17
CLIP COVER TO PAD
21
COVER
23
CLIP
25
BRACKET
35
BACKREST IMITATION LEATHER, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 010 105672 110 277011, ALSO INSTALLED ON: 275349,275350,276194,276195,276539,276540,276823,276869,276871,276879,276880,276885,276886,276895, 276928,276964,276969.
37
BACKREST FRAME , 034415
41
PAD
43
CLIP COVER TO PAD
47
COVER
51
FOLDING ARMREST , STATE COLOR NUMBER WHEN ORDERING
56
COVER
62
LOCK PLATE CONTROL SHAFT TO CAB
64
CLIP
66
SUPPORT , FROM CHASSIS: 015 310831 017 084917 110 466497 114 050799 115 348912 117,119 126430
68
LOCK PLATE
69
WASHER BRACKET TO HEAT SHIELD
70
WASHER COMPRESSED AIR LINE TO BRACKET
70
WASHER , Replaced By: N009021006208
71
NUT BALL PIVOT TO LEVER
72
SCREW
75
WASHER
79
NUT BALL PIVOT TO LEVER
999
COVER
999
COVER
999
RIVET , Replaced By: A0009906092
999
BACKREST LESS COVER
999
REAR SEAT BACKREST , Replaced By: A1159200830
999
SEAT CUSHION (COMPLETE,BUT LESS COVER)
999
CUSHION FRAME , Replaced By: A1159201022, +001A1159200150
999
REAR SEAT CUSHION LEATHER, FROM CHASSIS: 010 111536, ALSO INSTALLED ON: 111524,111526,111528,111529,111531,111532,111543. 110 294598, ALSO INSTALLED ON: 293636,293758,293945,294045,294236,294237,294238,294336,294337,294449,294452,294456,294461-294465, 294467,294470,294473-294476,294478,294480,294483,294484,294487,294489,294490,294492,294493,294495- 294497,294499-294506,294509-294519,294521-294528,294538-294541,294543,294560,294562,294596. 017,117 000001
999
BACKREST LEATHER, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 010 111536, ALSO INSTALLED ON: 111524,111526,111528,111529,111531,111532,111543. 110 294598, ALSO INSTALLED ON: 293636,293758,293945,294045,294236,294237,294238,294336,294337,294449,294452,294456,294461-294465, 294467,294470,294473-294476,294478,294480,294483,294484,294487,294489,294490,294492,294493,294495- 294497,294499-294506,294509-294519,294521-294528,294538-294541,294543,294560,294562,294596. 017,117 000001
999
PAD , Replaced By: A1159200150
999
COVER
999
FOLDING ARMREST , STATE COLOR NUMBER WHEN ORDERING
999
FOLDING ARMREST COMPLETE,BUT LESS COVER
999
WASHER , 023 008549 033 008598 123 004824 130 007629
999
SCREW , 023 008549 033 008598 123 004824 130 007629
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT BATTERY MOUNTING
