Поз.
Артикул
Описание
5
ACCELERATOR PEDAL , Replaced By: A2203000204
5
ACCELERATOR PEDAL , Replaced By: A1293000004
5
ACCELERATOR PEDAL
8
NUT TRANSMITTER-RECEIVER AEG
11
PIN ACCELERATOR PEDAL TO LEVER
14
LEVER ACCELERATOR PEDAL, A 450374 F 505054
14
LEVER ACCELERATOR PEDAL, A 450374 F 505054
14
LEVER ACCELERATOR PEDAL,F 505053
14
LEVER ACCELERATOR PEDAL,F 505053
17
LEVER ,B 838715,J 003393 TO BE ADAPTED DURING ASSEMBLY
23
BEARING ACCELERATOR PEDAL BEARING,B 838715,J 003393
24
BEARING ACCELERATOR PEDAL BEARING,A 346276
26
CLIP CABLE TO BRACKET,5 318121
29
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
29
SCREW , WITH DIESEL ENGINE
29
COMBINATION BOLT , Replaced By: N304017006019, +001N000137006204
32
GASKET BEARING TO FIRE WALL
35
NUT RETAINER , Replaced By: A0019906791
38
SPRING ACCELERATOR PEDAL
38
SPRING ACCELERATOR PEDAL
59
WIRE CABLE , F 758208 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE TO F 758207 WITH CODE 809
59
WIRE CABLE , F 483847 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 436536, F 483848 WITH CODE 806
59
WIRE CABLE , Replaced By: A2083000230
59
WIRE CABLE , Replaced By: A2083000430
59
WIRE CABLE , F 483848 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 436535, F 483847 WITH CODE 807 F 758207 EXCEPT CODE 809 ALSO INSTALLED IN VEHICLE FROM F 758208 WITH CODE 808, Replaced By: A2023002830
59
WIRE CABLE , Replaced By: A2023002530
59
WIRE CABLE , Replaced By: A2023001530
59
WIRE CABLE , Replaced By: A2023000430
59
WIRE CABLE , F 483847 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 436536, F 483848 WITH CODE 806, Replaced By: A2023000130
59
WIRE CABLE , F 758208 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE TO F 758207 WITH CODE 809
59
WIRE CABLE , A 436536 F 483848 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 436535, F 483847 WITH CODE 807 A 653728 F 758207 EXCEPT CODE 809 ALSO INSTALLED IN VEHICLE FROM A 653729, F 758208 WITH CODE 808
59
WIRE CABLE , F 483847 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 436536, F 483848 WITH CODE 806
59
WIRE CABLE , A 436536 F 483848 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 436535, F 483847 WITH CODE 807 A 653728 F 758207 EXCEPT CODE 809 ALSO INSTALLED IN VEHICLE FROM A 653729, F 758208 WITH CODE 808
65
GUIDE
68
RUBBER BUFFER WIRE CABLE TO FIRE WALL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
71
CLIP ELECTRIC CABLE TO FIXTURE
77
BRACKET , A 470874 F 547166 A 519673 F 619720 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE FROM A 519674, F 619721 WITH CODE 807
77
BRACKET , Replaced By: A2103011540
80
SENDER UNIT
92
SCREW BRACKET ON LOAD SENSOR
100
SPRING AT REVERSING LEVER,A 346276
101
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
