Поз.
Артикул
Описание
5
PIPE SOCKET BELOW AIR/WATER DUCT
5
PIPE SOCKET BELOW AIR/WATER DUCT
5
PIPE SOCKET , Replaced By: A2028300525
5
PIPE SOCKET , Replaced By: A2028300425
8
AIR DUCT AIR/WATER DUCT
8
AIR DUCT AIR/WATER DUCT
11
VALVE WATER DRAIN
14
SEAL
17
CLIP
20
RIVET AIR/WATER DUCT TO CROSS MEMBER, 1B63
23
SEAL AIR/WATER DUCT
26
SEAL AIR/WATER DUCT
29
COVERING
29
COVERING
32
SEAL RIGHT
33
FILTER
35
COVERING BELOW WIPER GEARING HEAD,CENTRAL
35
COVERING BELOW WIPER GEARING HEAD,CENTRAL
38
LOCK
41
SHEET METAL SCREW WATER BAFFLE TO CROSS MEMBER,A 166302
41
SHEET METAL SCREW WATER BAFFLE TO CROSS MEMBER,A 166302
44
LOCK PROTECTIVE GRILLE
47
SHEET METAL SCREW WATER BAFFLE TO CROSS MEMBER,A 166302
47
SHEET METAL SCREW WATER BAFFLE TO CROSS MEMBER,A 166302
50
FASTENER BUTTON , Replaced By: A0019889581
50
FASTENER BUTTON CABLE DUCT
50
FASTENER BUTTON INSULATION TO PARTITION PANEL,RIGHT
53
SCREEN RIGHT AIR/WATER DUCT
53
SCREEN LEFT AIR/WATER DUCT
56
SCREEN LEFT AIR/WATER DUCT
56
SCREEN RIGHT AIR/WATER DUCT
