Поз.
Артикул
Описание
8
GEAR 41 TEETH
13
TRANSFER CASE , Replaced By: A4622800200
13
TRANSFER CASE WITH P.T.O., 023958 900273 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
13
TRANSFER CASE WITH P.T.O., 023959 900274 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
20
P.T.O. , 023958 900273
20
P.T.O. , 023959 900274
32
HOUSING
32
HOUSING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO TRANSMISSION 027056, Replaced By: A4602800530
32
HOUSING , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 023958, Replaced By: A4602800430, +001A4602820465
40
SHIFTING ROD , 023958 900273
40
SHIFTING ROD , 023959 900274
48
SEAL RING
56
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
64
SHIFT LEVER
72
LOCK PLATE LEVER TO STRUT
80
SLIDE
88
DRIVEN SHAFT
96
SNAP RING
104
GEAR 45 TEETH
112
SPACER WASHER
120
GROOVED BALL BEARING
128
GROOVED BALL BEARING ON DRIVE END
136
THRUST WASHER
150
COVER CASE COVER
158
SEAL RING , Replaced By: A0079978247
161
SEAL RING
166
SEAL RING , Replaced By: A0079977847
169
SEAL RING
174
SCREW COVER TO P.T.O. CASE
182
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
182
SPRING WASHER , Replaced By: N000137008212
190
COUPLING FLANGE
198
NUT FLANGE TO SHAFT
198
NUT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4602820272
206
BALL
214
SPRING
222
SCREW
230
SEAL RING FUEL LINE TO FEED PUMP
238
OIL THROWER , 023958 900273
238
OIL THROWER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4602820365
241
OIL THROWER , 023959 900274
246
WASHER , Replaced By: N000433010510
254
LOCK RING
262
SCREW 3/2-WAY VALVE TO BRACKET
262
SCREW , Replaced By: N304014008009
270
SCREW , Replaced By: N304017008040
270
SCREW BRACKET TO SIDE MEMBER
278
CONICAL SPRING WASHER CHARGING AIR INTERCOOLER TO RADIATOR
286
CYLINDRICAL PIN
286
CYLINDRICAL PIN , Replaced By: N000007010102
999
WASHER , Replaced By: N000125008443
999
STUD P.T.O. TO TRANSFER CASE
999
SPACER TUBE
999
COVER
