Поз.
Артикул
Описание
65
GASKET CASE TO TRANSMISSION CASE
65
GASKET , Replaced By: A0002713480
68
SEAL RING CASE TO TRANSMISSION CASE
71
ELEMENT CASE TO TRANSMISSION CASE
74
ELEMENT CASE TO TRANSMISSION CASE
77
WASHER EXHAUST MUFFLER TO STRAP
77
SPACER WASHER , Replaced By: N000125008443
80
SCREW , Replaced By: N000000001448
80
HEXALOBULAR BOLT. SCREWM 8X45
83
SEAL RING PNEUMATIC VALVE
86
SCREW PLUG, FILLING HOUSING,BOTTOM
86
SCREW PLUG , Replaced By: N000000000648
89
SEALING RING. SEAL RING ENGINE BREATHING
92
SCREW PLUGTO 000 553 03 05,000 553 18 05,
95
RESERVOIR , Replaced By: A0002700546
95
RESERVOIR , Replaced By: A0002700446
95
RESERVOIR RETARDER ACCUMULATOR
98
COVER
104
COVER
110
PIPE
113
PIPE
113
PIPE , Replaced By: A0002712696
116
PISTON
122
SEAL RING
125
SEAL RING
128
PISTON GUIDE
131
STUD
134
WASHER EXHAUST MUFFLER TO STRAP
134
WASHER , Replaced By: N000125008443
137
NUT , Replaced By: N913004008001
146
SEAL RING RESERVOIR TO OIL COOLER HOUSING
149
WASHER EXHAUST MUFFLER TO STRAP
149
SPACER WASHER , Replaced By: N000125008443
152
SCREWM 8X50
155
VALVE (SOLENOID VALVE)
158
SEAL RING LINE CONNECTION
161
SCREW PLUG , Replaced By: A0029973430
161
SCREW PLUG
164
SEAL RING SOLENOID VALVE TO OIL COOLER HOUSING
167
SPACER WASHER , Replaced By: N000125008443
167
WASHER EXHAUST MUFFLER TO STRAP
170
SCREW VALVE TO BRACKET M 8X55
170
SCREW , Replaced By: N304017008043
173
BRACKET , Replaced By: A0002710388
173
COVERING RETARDER ACCUMULATOR
176
SPACER WASHER , Replaced By: A0002710152, +001A0002710352
176
SPACER WASHER RETARDER ACCUMULATOR, AS REQUIRED 0.80 MM
176
SPACER WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
176
SPACER WASHER RETARDER ACCUMULATOR 2.00 MM
176
SPACER WASHER , Replaced By: A4602840352
176
SPACER WASHER , Replaced By: A4602840352
176
SPACER WASHER , Replaced By: A4602840352
176
SPACER WASHER , Replaced By: A4602840352
176
SPACER WASHER , Replaced By: A4602840552
179
WASHER , Replaced By: A4602840352
179
WASHER , Replaced By: A4602840352
179
WASHER , Replaced By: A4602840352
179
SPACER WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
179
WASHER BRACKET TO RETARDER ACCUMULATOR 1.20 MM
179
WASHER BRACKET TO RETARDER ACCUMULATOR 0.80 MM
179
WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
179
WASHER RETARDER ACCUMULATOR, AS REQUIRED 1.00 MM
182
WASHER EXHAUST MUFFLER TO STRAP
182
SPACER WASHER , Replaced By: N000125008443
185
SCREW BRACKET TO CROSS CONNECTION STRUT
188
NUT
191
SEAL RING OIL LINE
