Поз.
Артикул
Описание
5
LINE , Replaced By: A1234209428
5
LINE FROM BRAKE POWER REGULATOR TO LEFT FRONT WHEEL
11
LINE FROM DISTRIBUTOR TO REAR HEIGHT CONTROL VALVE
11
LINE , Replaced By: A1234206328
22
LINE , Replaced By: A4604206128
22
LINE , Replaced By: A1234205328
22
LINE FROM DISTRIBUTOR TO REAR LEFT BRAKE HOSE, FROM CHASSIS: 005,007,008,015,017 154396 011 022325 060 018681 062 013421
33
TEST CONNECTION , Replaced By: A0004317531
33
TEST CONNECTION AT DISTRIBUTOR
33
TEST CONNECTION , Replaced By: A0004318731
37
DISTRIBUTOR
39
SEAL RING FITTING TO AXLE HOUSING
44
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
44
LINE , Replaced By: A1234206028
44
LINE , Replaced By: A4604202228
55
LINE , Replaced By: A1234205228
55
LINE FROM PRESSURE RETAINING VALVE TO BRAKE POWER REGULATOR 230 MM
55
LINE FROM DISTRIBUTOR TO REAR LEFT BRAKE HOSE
66
TEST CONNECTION , Replaced By: A0004318731
66
TEST CONNECTION , Replaced By: A0004317531
66
TEST CONNECTION AT DISTRIBUTOR
70
DISTRIBUTOR
72
SEAL RING FITTING TO AXLE HOUSING
74
BLEEDER VALVE TEST CONNECTION
77
BRACKET FRONT TEST CONNECTION, 029789 900767
88
SCREW COVER PLATE TO BRACKET
99
NUT BALL PIVOT TO LEVER
99
NUT PUMP TO BRACKET
99
NUT , Replaced By: N913004006001
110
SPRING WASHER LICENSE PLATE TO BRACKET
121
LINE FROM HYDRAULIC UNIT TO LEFT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532 TO BE ADAPTED DURING ASSEMBLY
121
LINE , Replaced By: A6014201528
121
LINE , Replaced By: A1234206728
132
LINE , Replaced By: A1234206328
132
LINE FROM DISTRIBUTOR TO REAR HEIGHT CONTROL VALVE
143
TEST CONNECTION REAR
154
SPACER RING
157
TEST CONNECTION , Replaced By: A0004318731
157
TEST CONNECTION , Replaced By: A0004317531
157
TEST CONNECTION AT DISTRIBUTOR
160
DISTRIBUTOR
163
SEAL RING FITTING TO AXLE HOUSING
999
DISTRIBUTOR REAR, UP TO IDENT NO. 009261 ALSO INSTALLED IN 009569,009619,009647-009649,009651,009654,009683,009887,009895,009896,009924,009925,009940,009951, 009952,009978,010005,010081,010578.
999
DISTRIBUTOR , Replaced By: A0004284224
999
SCREW PLUG
999
LINE , Replaced By: A4604206328
999
LINE , Replaced By: A6014201528
999
LINE
999
LINE
999
LINE
999
LINE
999
LINE
