OM 601 - 601.913 - 14 INTAKE AND EXHAUST MANIFOLDS

  • Поз.
    Артикул
    Описание
  • 8
    HOSE
  • 9
    HOSE
  • 9
    HOSE , Replaced By: A1170780281
  • 11
    PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
  • 23
    HOSE , ORDER BY THE METER
  • 29
    PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
  • 35
    LINE. HOSE FROM VACUUM CONTROL VALVE TO PASSENGER COMPARTMENT 4 MM, ORDER BY THE METER
  • 45
    HOSE FROM STEERING LOCK TO VACUUM PUMP LINE 830 MM
  • 56
    DASHPOT
  • 59
    LINE VACUUM LINE, ORDER BY THE METER313762
  • 75
    DISTRIBUTOR HEATING AND FUEL CONSUMPTION INDICATOR
  • 77
    BRANCH-OFF FITTING
  • 78
    NOZZLE ELECTRIC CHANGE-OVER VALVE AND PRESSURE CONVERTER, CALIFORNIA FROM MODEL YEAR'84 UP TO END OF MODEL YEAR'84
  • 79
    STRAINER
  • 80
    HOSE MASTER SWITCH AND VACUUM SWITCH 40 MM, 023 164780 033 066774 123 158077 130 172061
  • 81
    HOSE VENTING FOR EXHAUST-GAS TURBOCHARGER VALVE 35 MM, ORDER BY THE METER
  • 82
    CONNECTOR , UP TO ENGINE 602.962 12/52,22/62 007728 EXCEPT FOR 007701,007702,007716-007718,007722-007726
  • 83
    HOSE *** 30 MM
  • 85
    DASHPOT. STRAINER VACUUM LINE
  • 92
    INSULATING HOSE5 X 0.6 MM, ORDER BY THE METER
  • 92
    INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
  • 92
    INSULATING HOSE16X1 MM, ORDER BY THE METER
  • 92
    INSULATING HOSE BLACK 12 X 0,8 MM
  • 101
    VALVE
  • 101
    VALVE VACUUM CONTROL VALVE
  • 101
    VALVE , Replaced By: A1403000833, +001A1162760929
  • 102
    CLAMPING PIECE VACUUM CONTROL VALVE TO INJECTION PUMP
  • 104
    COMBINATION BOLT BRACKET TO RADIATOR, 763829 P 000001
  • 105
    HOSE VACUUM PUMP, ORDER BY THE METER
  • 111
    BRANCH-OFF FITTING VACUUM PUMP, ONLY USED WITH AIR POLLUTION CONTROL
  • 112
    BRANCH-OFF FITTING CENTRAL LOCKING MECHANISM PUMP,RIGHT
  • 119
    BRANCH-OFF FITTING INCREASE IN TRANSMISSION SHIFT POINT & 2 SELECTION PROGRAMS, F 140421 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM F 140422 WITH CODE 806
  • 122
    THROTTLE
  • 131
    PRESSURE CONVERTER
  • 134
    COVERTO 123 300 05 33
  • 137
    SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
  • 137
    SHEET METAL SCREW , Replaced By: N007981004252
  • 999
    LOCKING CAP
  • 999
    HOSE , Replaced By: A1179970982
  • 999
    GROMMET
