Поз.
Артикул
Описание
7
DOOR SHELL RIGHT,001020
11
HINGE TOP RIGHT
17
HINGE BOTTOM RIGHT, 001228
21
ROLLER
24
PIN
28
LOCK PLATE
33
GREASE NIPPLE
36
PAD
40
PLATE , FROM CHASSIS 000728-001136
44
NUT RETAINER ,123 415950
44
NUT RETAINER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009909991
52
EDGING RIGHT,001020
55
PLATE
60
PLATE 2.0 MM 2.0 MM, TO BE ADAPTED DURING ASSEMBLY
66
INTERIOR HANDLE ASSEMBLY RIGHT, 000981
68
INTERIOR HANDLE ASSEMBLY RIGHT
71
CLIP
71
CLIP , Replaced By: A0069886378
75
LOCK PULL ROD TO DOOR LOCK
78
CLIP
78
CLIP , Replaced By: A0069886378
82
PULL ROD , 002082
85
LOCKING ROD , UP TO CHASSIS 001704 EXCEPT FOR 001695,001700,001702,001703
89
LOCK PULL ROD TO DOOR LOCK
92
SCREW
96
ESCUTCHEON RIGHT
100
SEAL
104
INSERT RIGHT
108
KNOB , 023 116973 033 048510 123 097280 130 120563
113
DOOR HANDLE RIGHT,001020
117
PAD RIGHT
121
SCREW DOOR HANDLE TO DOOR
124
DISC SPRING
127
SPRING
263
INSULATION
263
INSULATION
263
INSULATION , Replaced By: A1107270390
263
INSULATION , Replaced By: A1237270090
263
INSULATION , Replaced By: A2106820008
290
GARNISH MOULDING RIGHT
293
GARNISH MOULDING RIGHT, 001028
296
WASHER
296
WASHER , Replaced By: A1129900042
296
WASHER , Replaced By: A3019900042
300
ESCUTCHEON
308
GARNISH MOULDING RIGHT
311
GARNISH MOULDING RIGHT
314
FASTENER BUTTON
317
FASTENER BUTTON
317
GROMMET , Replaced By: A0019882081
317
FASTENER BUTTON , Replaced By: A0089970381
317
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
321
SCREW
324
ORNAMENTAL COVER RIGHT
328
ORNAMENTAL COVER RIGHT,001020
335
ORNAMENTAL COVER OUTSIDE RIGHT, 000429
339
COVER RAIL
999
LOCK PLATE CONSOLE TO REAR PANELLING,TOP
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
DUO CLIP , Replaced By: N912010005001
999
LOCK , UP TO CHASSIS: 005,007,008,015,017 207357 011 101648 060 102313 062 101808
999
LOCK PULL TO FASTENER
999
LOCK , Replaced By: N912002008003
999
SPRING WASHER , Replaced By: N000137010205
999
SPRING WASHER SHIFTING CYLINDER TO YOKE
999
SCREW PIPE CLAMP
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW LEVER TO SHAFT
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER , Replaced By: N009021006208
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021005205
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021004207
999
WOOD SCREW
999
WOOD SCREW
999
SCREW CHROMIUM PLATED, 000,001,004,010,UP TO CHASSIS 130557,100,101,104,110,UP TO CHASSIS 225647
999
SCREW
999
SCREW , UP TO CHASSIS 001704 EXCEPT FOR 001695,001700,001702,001703
999
SCREW
999
SCREW
999
SCREW VENTILATOR WINDOW TO RETAINING FRAME, TOP AND BOTTOM
999
SCREW , Replaced By: N000000001933
999
SCREW
999
SHEET METAL SCREW PANELLING TO ROOF RAIL
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW EDGING TO DOOR
999
SHEET METAL SCREW , Replaced By: N007981003214
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW
999
RIVET
999
TOOTHED WASHER , UP TO CHASSIS 088751 EXCEPT FOR 088472,088717,088725,088727,088732,088737,088739,088741,088742,088743,088745,088746-088750
999
TOOTHED WASHER CABLE TO FUSE BOX
999
SCREW SLOTTED GATE
999
SCREW INTERMEDIATE BEARING TO CAB FLOOR
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017006034
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017005002
999
SCREW , ON MODELS 111.024,025 UP TO CHASSIS 003544 WITH THE EXCEPTION OF,SEE FOOTNOTE 19
999
NUT CLAMP TO BRACKET
999
SPRING WASHER SHIFTING ROD TO BRACKET
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
LOCK WASHER TAIL LAMP TO BRACKET
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
SCREW
999
SCREW ARMREST TO DOOR LINING
999
SCREW FUSE BOX TO SIDE MEMBER,5 097182
999
LOCK , Replaced By: A1009940160
999
WASHER
999
WASHER , Replaced By: A1809900640
999
REPAIR KIT
999
SEAL INSIDE 4000 MM
999
MOLDED PIECE , Replaced By: A0029888378
999
SLIDE , Replaced By: A1155860072
999
REPAIR KIT , Replaced By: A1237200114
999
SLIDE , Replaced By: A1155860072
999
ADAPTER WINDOW RUN TO FRONT DOOR,TOP 1.0 MM
999
ADAPTER 0.5 MM WATER DEFLECTOR RAILS AND WINDOW RUNS TO TOP OF DOORS
999
INSERT , 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
ESCUTCHEON RIGHT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
ESCUTCHEON LEFT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
SCREW , UP TO CHASSIS: 000,002,010 083223 015 097126 100,102,103,110,112 212123 115 104333
999
ESCUTCHEON LEFT
999
INSERT LEFT
999
INTERIOR HANDLE ASSEMBLY LEFT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990
999
SEAL , Replaced By: A1157251298
999
PAD LEFT
999
INTERIOR HANDLE ASSEMBLY RIGHT, 000982001020
999
INTERIOR HANDLE ASSEMBLY LEFT, 000982 UP TO CHASSIS 001704 EXCEPT FOR 001695,001700,001702,001703
999
INTERIOR HANDLE ASSEMBLY LEFT, 000981
999
DOOR HANDLE OUTSIDE RIGHT AT FRONT DOOR
999
DOOR HANDLE OUTSIDE LEFT AT FRONT DOOR
999
DOOR HANDLE LEFT,001020
999
ORNAMENTAL COVER RIGHT FRONT DOOR,REAR
999
ORNAMENTAL COVER LEFT AT FRONT DOOR,REAR
999
ORNAMENTAL COVER , Replaced By: A1007281421
999
ORNAMENTAL COVER , Replaced By: A1007281321
999
ORNAMENTAL COVER OUTSIDE LEFT, 000430
999
GARNISH MOULDING LEFT
999
ORNAMENTAL COVER , Replaced By: A1007281421
999
ORNAMENTAL COVER , Replaced By: A1007281321
999
ORNAMENTAL COVER LEFT INSIDE AT SIDE DOOR, REAR, UP TO CHASSIS 001704 EXCEPT FOR 001695,001700,001702,001703
999
GARNISH MOULDING LEFT
999
ORNAMENTAL COVER LEFT
999
GARNISH MOULDING , Replaced By: A1007270682
999
GARNISH MOULDING LEFT
999
GARNISH MOULDING , Replaced By: A1007270482
999
GARNISH MOULDING , Replaced By: A1007270382
999
RAIL LEFT BOTTOM
999
RAIL , 000020
999
GLASS PANE LEFT
999
SPRING
999
ADAPTER 1 MM, 100001
999
MOUNTING TOP LEFT
999
SEAL LEFT
999
KNOB , 012 UP TO CHASSIS 058443 EXCEPT FOR,SEE FOOTNOTE 056,014 UP TO CHASSIS 045293 EXCEPT FOR,SEE FOOTNOTE 057
999
SPRING
999
PLATE , FROM CHASSIS 000728
999
PLATE , 000728
999
PLATE , Replaced By: A1007231111
999
PLATE , Replaced By: A1007231011
999
LOCKING ROD RIGHT
999
EDGING RIGHT BETWEEN DOOR LOCK AND DOOR LINING
999
LOCKING ROD LEFT
999
EDGING LEFT, FROM CHASSIS: 100.012,014,015,016 001021
999
PLATE , UP TO CHASSIS: 000,002,010 032736 EXCEPT FOR 026127-026384 015 030665 EXCEPT FOR 023687-023770 100,102,103,110,112 073207 EXCEPT FOR 057116-057347 115 033411 EXCEPT FOR 026238-026496
999
EDGING LEFT,001020
999
PAD , Replaced By: A1007230105
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT FRONT DOOR, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS 001029 ALSO INSTALLED ON 000996,001021,001024,001026. UP TO CHASSIS 001704 WITH THE EXCEPTION OF 001695,001700,001702,001703. 001695,001700,001702,001703.
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS 001029-001704 EXCEPT FOR 001695,001700,001702,001703
999
PANELLING RIGHT FRONT DOOR, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS 001029 ALSO INSTALLED ON 000996,001021,001024,001026. UP TO CHASSIS 001704 WITH THE EXCEPTION OF 001695,001700,001702,001703. 001695,001700,001702,001703.
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS 001029-001704 EXCEPT FOR 001695,001700,001702,001703
999
PANELLING RIGHT, STATE COLOR NUMBER WHEN ORDERING 000886-001028
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING 000886-001028
999
DOOR SHELL SHELL,RIGTH
999
DOOR SHELL SHELL,LEFT
999
DOOR SHELL LEFT, 001228 UP TO CHASSIS 001704 EXCEPT FOR 001695,001700,001702,001703
999
VENTILATOR WINDOW RIGHT, 000736
999
FASTENER LEFT
999
VENTILATOR WINDOW LEFT, 000736
999
DOOR SHELL , 000430-001227, Replaced By: A1007202405, +001A1007201237
999
DOOR SHELL , 000430-001020, Replaced By: A1007202305, +001A1007201137
999
PANELLING RIGHT FRONT DOOR, STATE COLOR NUMBER WHEN ORDERING R.H.D. UP TO CHASSIS 001028 EXCEPT FOR 000996,001021,001024,001026. L.H.D. UP TO CHASSIS 000885 EXCEPT FOR 000875,000877,000882-000884.
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING 12 UP TO CHASSIS 000885, 22 UP TO CHASSIS 001028
999
VENTILATOR WINDOW LEFT, 000736
999
HINGE BOTTOM LEFT, 001228
999
HINGE TOP LEFT
999
FASTENER , Replaced By: A1007201666
