Поз.
Артикул
Описание
3
BATTERY
5
BOTTOM , 000,001,010 FROM CHASSIS 130558
9
MOUNTING FRAME , 000,001,010 FROM CHASSIS 130558
11
CLAMPING SCREW
15
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
17
NUT BATTERY MOUNTING
17
NUT CYLINDER TO BRACKET TO0002902112
19
POSITIVE CABLE , 000,001,010 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 25, 100,101,110 FROM CHASSIS 099642 ALSO INSTALLED ON, SEE FOO TNOTE 12, EXCEPT FOR 099892
21
NEG. CABLE
23
NEG. CABLE FROM SIDE MEMBER TO ENGINE
27
BOOT
27
BOOT , Replaced By: A1165460135
28
CLAMP TO MOUNT MAIN CABLE HARNESS
29
CLAMP MAIN CABLE HARNESS TO LEFT SIDE PART
34
HOSE20 MM
39
GROMMET LINE MOUNTING 10.0 MM
45
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
45
PLUG
45
PLUG
47
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
47
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
49
PLUG TRIPLE
49
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
49
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
52
PLUG , Replaced By: A0065458128, +008A0035452626, +001A0095452028
52
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
57
PLUG HEATER UNIT, 201.023,024 A219649 F091790 201.034 A201729 F108104
60
CABLE SHOE
65
GROMMETD5/26
67
GROMMET
70
PROTECTIVE TUBE
75
PLUG
105
SWITCH (FOOT DIMMER SWITCH) BOSCH, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
107
RUBBER RING FOOT DIMMER SWITCH TO TOEBOARD, 000,001,010 FROM CHASSIS 120054-130557, 100,101,110 FROM CHASSIS 016787-225647
109
CLIP WIRE CABLE TO AIR CLEANER
112
CLIP PLUG TO REAR PILLAR
115
BRACKET MAIN CABLE HARNESS TO BODY
120
BRACKET CABLE CONNECTOR, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
124
BRACKET AT INSTRUMENT PANEL, 000,001,010 FROM CHASSIS 130558, 100,101,110 FROM CHASSIS 225648
128
GROMMET BLINKER LAMP BRANCH-OFF
131
PLUG WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM,5 255829
134
PLUG TRIPLE
134
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
134
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
137
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
137
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
140
PLUG , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0065458028, +006A0015453726, +001A0095453028
140
PIN BUSHING HOUSING 4-POLE
143
CLIP TAIL LAMP CABLE HARNESS, 000,001,010 FROM CHASSIS 078810, 100,101,110 FROM CHASSIS 123760
147
CLIP
151
CABLE HARNESS IN STEERING COLUMN JACKET TUBE, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
154
PLUG 7-POLE, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
157
BOOT HEATER PLUGS
160
GROMMET ,D 314239
284
HORN335 HZ
284
HORN335 HZ
304
BRACKET ,303364
307
SCREW PLUG SOCKET TO FRAME
309
NUT PUMP TO BRACKET
315
BOOT HEATER PLUGS
321
REGULATOR AND CUT-OUT ,4 477130
321
REGULATOR AND CUT-OUT , Replaced By: A0021547406
999
CLAMP , 000,001,010 FROM CHASSIS 130558, 100,101,110 FROM CHASSIS 225648
999
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
999
SHEET METAL SCREW , Replaced By: N914031005208
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
LOOM TIE , Replaced By: A0009974390
999
CLAMP BREATHER LINE TO REAR AXLE
999
GROMMET LINE PASSAGE AT SIDE MEMBER 24 MM,5 473494
999
BRACKET MAIN CABLE HARNESS TO REGULATOR BRACKET, 000,001,010 FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9, 100,101,110 FROM CHASSIS 099642-225647 ALSO INSTALLE D ON, SEE FOOTNOTE 43, EXCEPT FOR 099892 NO LONGER AVAILABLE
999
CLIP STARTING MOTOR BRANCH-OFF
999
CLIP MAIN CABLE HARNESS TO FRONT CROSS MEMBER, 10,50/12,52, 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 17, 10,50, 100,101,110 UP TO CHASSIS 099641 EXCEPT FOR,SEE FOOTNOTE 12, ALSO INSTALLED ON 099892
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
CLAMP , Replaced By: A3449957120
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
CLAMP BRAKE LINE TO FIRE WALL, 000 130186 003 066451 007 053318 083 002304 086 001762 093 001874 102,103 113215 105 135079 183 004049 190 005029
999
CLAMP , Replaced By: A1239950222
999
CLAMP MAIN CABLE HARNESS TO LEFT WHEEL ARCH PANEL, NO LONGER AVAILABLE
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW , Replaced By: N007981004233
999
SHEET METAL SCREW ELECTRIC CABLE MOUNTING
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
CLIP MAIN CABLE HARNESS TO BODY
999
CLIP
999
CLIP FLEXIBLE SHAFT TO WHEELHOUSE, 086 007397 093 010089 183 NOT FOR SWEDEN 028930 183 SWEDEN F 001867 ALSO INSTALLED ON 028960 190 030466 ALSO INSTALLED ON 030442 193 005964 280 NOT FOR SWITZERLAND 009681 ALSO INSTALLED ON 009608,009626-009679 280 SWITZERLAND 009208 283 NOT FOR SWITZERLAND 019905 ALSO INSTALLED ON 019489,019510,019514,019524,019528-019534,019541,019543,019548-019550,019554-019575,019587,019590, 019593,019603,019604,019613,019614,019625-019638,019646,019649-019712,019715-019814,019821,019830- 019894,019899,019901. 283 SWITZERLAND F 000423 ALSO INSTALLED ON 021312,F 000333
999
CLIP CABLE HARNESS TO ROOF RAIL
999
CLIP
999
CLIP MAIN CABLE HARNESS TO RIGHT WHEEL ARCH PANEL
999
SEALING CORD MAIN CABLE HARNESS TO SIDE MEMBER, NO LONGER AVAILABLE
999
EDGE GUARD SECTION SEAT, Replaced By: A0019872272
999
EDGE GUARD SECTION , Replaced By: A0029873572
999
CLIP
999
SHEET METAL SCREW COVERING TO REINFORCEMENT
999
NUT RETAINER FOOT DIMMER SWITCH TO TOEBOARD, 000,001,010 UP TO CHASSIS 012053, 100,101,110 UP TO CHASSIS 016786
999
NUT RETAINER FOOT DIMMER SWITCH TO TOEBOARD, 000,001,010 UP TO CHASSIS 012053, 100,101,110 UP TO CHASSIS 016786
999
SCREW FOOT DIMMER SWITCH TO TOEBOARD, 000,001,010 UP TO CHASSIS 012053, 100,101,110 UP TO CHASSIS 016786
999
INSULATION , TO 000 545 04 12, 000 545 08 12 NO LONGER AVAILABLE
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
SCREW ELECTRIC CABLE TO FUSE BOX
999
FUSE , Replaced By: A0015457534
999
FUSEA16
999
SWITCH (FOOT DIMMER SWITCH)
999
TOOTHED WASHER OVERLOAD PROTECTOR TO TERMINAL BOARD
999
SCREW ELECTRIC CABLE TO FUSE BOX
999
SWITCHBOSCH
999
LIGHT SWITCH , Replaced By: A0005452004, +001A1105451137, +001A1105450272
999
LIGHT SWITCH , Replaced By: A0005452004, +001A1105451137, +001A1105450272
999
CABLE SHOE DOOR CONTACT SWITCH
999
PIN BUSHING HOUSING 3-POLE,4 483482
999
GROMMET BACK-UP LIGHT
999
GROMMET ELECTRIC CABLE THRU ROOF PANELLING
999
GROMMET ADDITIONAL CABLE HARNESS
999
GROMMET , 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
999
CABLE SHOE CABLE TO ALTERNATOR, NO LONGER AVAILABLE
999
PLUG 12-POLE, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
999
PLUG , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0065458028, +006A0015453726, +001A0095453028
999
PLUG 4-POLE
999
CABLE HARNESS , 000,001 FROM CHASSIS 130558
999
CABLE HARNESS , FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9
999
CABLE HARNESS , 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25
999
CABLE HARNESS , 000,001 FROM CHASSIS 130558
999
CABLE HARNESS , FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9
999
CABLE HARNESS , 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25
999
CABLE HARNESS , 000,001 FROM CHASSIS 130558 010 FROM CHASSIS 130558
999
CABLE HARNESS , FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9
999
CABLE HARNESS , 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25
999
CABLE HARNESS , 000,001 FROM CHASSIS 130558 010 FROM CHASSIS 130558
999
CABLE HARNESS , FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9
999
CABLE HARNESS , 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021005205
999
SHEET METAL SCREW OIL LINE MOUNTING
999
GROUND STRAP FROM ENGINE BLOCK TO RADIATOR
999
GROUND STRAP
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
999
SPACER TUBE BRACKET TO FIRE WALL
999
SHEET METAL SCREW , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
999
CLAMP
999
CLAMP , Replaced By: A3449957120
999
NUT RETAINER LICENSE PLATE TO BRACKET
999
NUT RETAINER , Replaced By: A0019906791
999
NUT RETAINER REGULATOR AND CUT-OUT, FOR VEHICLES HAVING LOW CAB 344 ON CAB 344
999
SCREW CLAMP MOUNTING M 6X16
999
SCREW , Replaced By: N000000001146
999
NUT RETAINER NEGATIVE CABLE TO FRAME, 000,001,010 FROM CHASSIS 009195 EXCEPT FOR, SEE FOOTNOTE 27, 100,101,110 FROM CHASSIS 012800 EXCEPT FOR, SEE FOOTNOTE 28
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW , Replaced By: N304017008016
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
NUT CYLINDER TO BRACKET TO0002902112
999
SCREW LINES UNDER FUEL TANK
999
GROUND STRAP FROM ENGINE TO FRAME, 000,001,010 UP TO CHASSIS 009194 ALSO INSTALLED ON, SEE FOOTNOTE 27, 100,101,110 UP TO CHASSIS 012799 ALSO INSTALLED ON, SEE F OOTNOTE 28
999
NEG. CABLE FROM BATTERY TO ENGINE, 000,001,010 UP TO CHASSIS 009194 ALSO INSTALLED ON, SEE FOOTNOTE 27, 100,101,110 UP TO CHASSIS 012799 ALSO INSTALLED ON, SEE F OOTNOTE 28
999
NEG. CABLE FROM BATTERY TO ENGINE, 000,001,010 UP TO CHASSIS 009194 ALSO INSTALLED ON, SEE FOOTNOTE 27, 100,101,110 UP TO CHASSIS 012799 ALSO INSTALLED ON, SEE F OOTNOTE 28
999
POSITIVE CABLE , 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25, 100,101,110 UP TO CHASSIS 099641 EXCEPT FOR, SEE FOOTNOTE 12, AL SO INSTALLED ON 099892
999
CLAMPING SCREW , 000,001,010 FROM CHASSIS 011696-130557, 100,101,110 FROM CHASSIS 099642
999
CLAMPING SCREW , 000,001,010 FROM CHASSIS 011696-130557, 100,101,110 FROM CHASSIS 099642
999
MOUNTING FRAME
999
MOUNTING FRAMETO 000 541 74 01, ON SPECIAL REQUEST, HIGH-CAPACITY BATTERY 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25
999
MOUNTING FRAME , FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9
999
MOUNTING FRAME , 000,001,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 25
999
FLOOR
999
FLOOR
999
BOTTOM , FROM CHASSIS 064106-130557 ALSO INSTALLED ON, SEE FOOTNOTE 9
999
BOTTOM , FROM CHASSIS 011696-064105 EXCEPT FOR, SEE FOOTNOTE 9
999
BOTTOM , 011695
999
BATTERY ACID BOTTLE SETTO 001 541 79 01
999
BATTERY ACID BOTTLE SET , Replaced By: A0009891315
999
BATTERY12V/70AH, ON LP1313(352)FROM CHASSIS 601004 WITH THE EXCEPTION OF 601006,601009,601010,601017,601018,601024 ALSO INSTALLED ON 600917,600 992,600993,600996-999,601001,601002 CONTINUED ON 014
999
BATTERY ACID BOTTLE SETTO 001 541 79 01
999
BATTERY ACID BOTTLE SET , Replaced By: A0009891315
999
BATTERY , Replaced By: A0035413301, +001A1085400123
999
CLIP
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
NUT TACHOGRAPH TO BRACKET
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
GROMMET TACHOGRAPH OR SPEEDOMETER
999
CLIP HOSE TO CAB,4 238841
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
CLIP CABLE HARNESS TO ROOF RAIL
999
GROMMET TACHOGRAPH OR SPEEDOMETER
999
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
999
CABLE HARNESS IN STEERING COLUMN JACKET TUBE, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647 U.S. VERSION
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
LOCK WASHER T-FITTING TO BRACKET
999
SCREW BRACKET MOUNTING
999
SHEET METAL SCREW
999
BRACKET TAIL LAMP CABLE HARNESS TO WHEEL ARCH PANEL REAR, 000,001,010 FROM CHASSIS 130558, 100,101,110 FROM CHASSIS 225648
999
CLIP STARTING MOTOR BRANCH-OFF
999
GROMMET 34 MM
999
CABLE HARNESS TAIL LAMP CABLE HARNESS, 000,001,010 FROM CHASSIS 155700, 100,101,110 FROM CHASSIS 274273, 002,003,011 FROM CHASSIS 013948
999
CABLE HARNESS TAIL LAMP CABLE HARNESS, 000,001,010 FROM CHASSIS 130558-155699, 100,101,110 FROM CHASSIS 225648-274272, 002,003,011 UP TO CHASSIS 013947
999
CABLE HARNESS TAIL LAMP CABLE HARNESS, 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
