Поз.
Артикул
Описание
1
DRIVER'S DOOR, SHELL, RIGHT WITH HINGE
3
THREADED PLATE FOR DOOR HINGE
4
SLEEVE FOR BOTTOM DOOR HINGE THREADED PLATES AT SHELLS NO LONGER INSTALLED
5
DOOR BRAKE, RIGHT. DOOR BRAKE WITH THREADED PLATE FOR DRIVER'S DOOR, RIGHT
6
FIXING RAIL, RIGHT FOR DOOR SEALING RUBBER, BOTTOM
7
TIGHTENING STRUT
8
DOOR HINGE, RIGHT
9
HINGE BOLT
10
GREASE NIPPLE
12
SHIM 1 MM THICK FOR DOOR HINGE OPTIONAL
16
CATCH NOSE LOCK, RIGHT OPTIONAL WITH MAKE "KIEKERT" OR "BOMORO" STATE MAKER'S NAME WHEN ORDERING FROM CHASSIS 7515628
25
PULL ROD, RIGHT FROM INNER LOCK TO DOOR LOCK
26
MOLDED PIECE , 043 002979
27
LOCKING SPRING MAKE "KIEKERT" OR "BOMORO" STATE CHASSIS NO. AND MAKER'S NAME WHEN ORDERING FROM CHASSIS NO. 65 06796
28
PULL ROD, RIGHT FROM LOCK TO INNER OPERATION FROM CHASSIS 7502487
29
COVERING FOR INNER LOCK FROM CHASSIS 7502487
30
INNER LOCK, RIGHT FOR DOOR LOCK
31
ESCUTCHEON (FOR INNER LOCK), FROM CHASSIS 7500412
32
PLATE FOR INNER LOCK
33
COVER PLATE, LEFT AND RIGHT BETWEEN LOCK AND DOOR LINING
34
GUIDE ANGLE FOR INNER LOCK
35
INNER OPERATION, RIGHT
36
ESCUTCHEON INNER HANDLE MECHANISM AT REAR DOOR, INNER PLATE COMMANDE
37
DOOR HANDLE, OUTSIDE, LEFT, LOCKABLE FOR LEFT DRIVER'S DOOR FROM CHASSIS 7515628
38
DOOR HANDLE, OUTSIDE, RIGHT, LOCKABLE
41
PIN
42
PUSH BUTTON WITH CYLINDRICAL LOCK AND PRESSURE ROD FROM CHASSIS 7515628
44
RING FOR PUSH BUTTON IN HANDLE, CAST PART
45
GROOVED RING DISTANCE RING FOR PUSH BUTTON IN HANDLE, CAST PART STATE CHASSIS NO. WHEN ORDERING
46
SQUARE SNAP RING
47
PRESSURE SPRING, OUTSIDE. PRESSURE SPRING FOR PUSH BUTTON TO HANDLE
49
WASHER
50
RUBBER PAD UNDER DOOR HANDLE, RIGHT, REAR FROM CHASSIS NO. 45 18977
51
RUBBER PAD, LEFT AND RIGHT, FRONT DOOR HANDLE AT REAR DOOR
54
RETAINING DOOR STRAP
56
RUBBER BUFFER
57
BRACKET FOR DOOR RETAINING STRAP
65
DEFLECTOR WINDOW, RIGHT
66
SUPPORTING FRAME FOR DEFLECTOR WINDOW, RIGHT
67
SEALING FRAME FOR DEFLECTOR WINDOW, RIGHT
68
DEFLECTOR WINDOW, RIGHT WITHOUT SUPPORTING FRAME AND SEALING FRAME WITH TURNBUCKLE
69
LATCH, RIGHT. TURNBUCKLE, RIGHT FROM CHASSIS 8506928, UP TO CHASSIS 8506927, SPECIAL REQUEST, DEFLECTOR WINDOW
70
SHAFT FOR TURNBUCKLE TO WINDOW FRAME FROM CHASSIS 8506928, UP TO CHASSIS 8506927, SPECIAL REQUEST, DEFLECTOR WINDOW
71
SPRING WASHER TURN BUCKLE AT WINDOW
72
MOUNTING, BOTTOM, RIGHT
73
WASHER DOOR HINGE,TOP RIGHT
74
MOUNTING PIN, TOP, RIGHT
75
STOP FOR TURNBUCKLE, RIGHT
76
RUBBER MOULDING, 260-MM LONG FOR SUPPORTING FRAME ORDER BY THE METER
77
WASHER
78
WASHER FOR DEFLECTOR WINDOW AT SEAT, BOTTOM SPECIAL REQUEST - DEFLECTOR WINDOW
79
SEALING SECTION , Replaced By: A0009851830
80
WASHER DOOR HINGE,TOP RIGHT
81
RUBBER WASHER FOR DEFLECTOR WINDOW AT DOOR FRAME, BOTTOM
85
WINDOW RUN, RIGHT LOCK SIDE
86
CRANK WINDOW, LEFT AND RIGHT WITHOUT GUIDE JAWS
88
GUIDE JAW FROM CHASSIS 6510183
89
WINDOW LIFTING RAIL, RIGHT FROM CHASSIS 6508805
90
STOP RAIL FOR CRANK WINDOW
91
SPACER ROLLER BETWEEN LIFTING RAIL AND FIXING RAIL AND GLASS PANE
92
STOP ANGLE
93
HOSE26 MM, ORDER BY THE METER
94
PARALLEL ARM WINDOW LIFTER WITH SWING JOINT FOR DRIVER'S DOOR, RIGHT FROM CHASSIS 6508805
95
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
96
SEALING RAIL INSIDE AND OUTSIDE AT WINDOW GAP
97
CLIP WITH HOOK. CLIP WITH HOCK FOR SEALING RAIL
98
WINDOW CRANK FROM CHASSIS 002430
99
BOLZEN. CYLINDRICAL PIN FOR WINDOW CRANK DELIVERED TOGETHER WITH CRANK, NOT MOUNTED
100
ROSETTE VERCHROMT. ESCUTCHEON WITH PRESSURE SPRING AND SLEEVE TO WINDOW CRANK
105
BINDING RAIL, HINGE SIDE, RIGHT FOR FIXING DOOR LINING
106
BINDING RAIL, BOTTOM, RIGHT FOR FIXING DOOR LINING
107
COVER LID, RIGHT LOCK SIDE, WILL BE DELIVERED NOT CHROMIUM PLATED, HAS TO BE FITTED
108
COVER LID, RIGHT UPPER PART FROM CHASSIS 7515628, IS DELIVERED NOT CHROMIUM-PLATED, HAS TO BE FITTED
109
ORNAMENTAL BAR, RIGHT AT SILL, WILL BE DELIVERED NOT CHROMIUM PLATED, HAS TO BE FITTED
110
CLIP. SPREADER CLIP FOR ORNAMENTAL BAR, LATERAL AT SILL EDGE, BODY REAR END
111
ORNAMENTAL BAR, RIGHT BELOW SILL (CHROMIUM-PLATED)
112
SPREADER CLAMP FOR ORNAMENTAL BAR TO REAR DOOR, BOTTOM
114
COTTER, RIGHT FOR CATCH NOSE LOCK FROM CHASSIS 7515628
118
SHIM 1.0 MM THICK. SHIM, 1.00 MM THICK COTTER AT CENTER PILLAR
119
SEALING FRAME FOR DRIVER'S DOOR, RIGHT
120
WINDOW MOULDING, RIGHT STATE ENCLOSE SAMPLE OF VENEER WHEN ORDERING
121
CLIP WITH BARB. CLIP WITH HOCK
122
ORNAMENTAL BAR, RIGHT FOR WINDOW MOULDING
123
FIXING CLAMP. SPREADER CLIP FOR ORNAMENTAL BAR AT WINDOW MOULDING
124
COVER PLATE, FRONT, RIGHT AT WINDOW MOULDING, IS DELIVERED NOT CHROMIUM-PLATED, HAS TO BE FITTED
125
WEATHER STRIP, 710-MM LONG AT FRONT WALL PILLAR, BOTTOM STATE COLOUR WHEN ORDERING
126
WEATHER STRIP, 580-MM LONG AT CENTER PILLAR, REAR STATE COLOUR WHEN ORDERING
130
DOOR LINING, RIGHT WITH ARM REST STATE COLOUR WHEN ORDERING AND ENCLOSE SAMPLE OF ARM REST WOOD FROM CHASSIS 7515628
132
SPRING FOR DOOR POCKET
133
LOOP
134
POCKET HANDLE
135
LENS-HD.COUNTERSUNK NUT. COUNTERSUNK LENS-HD. NUT FOR DOOR HANDLE AND STRING AT COVER
136
SEALING RAIL, RIGHT AT FRONT WALL PILLAR
137
SEALING RUBBER, LEFT AND RIGHT, 359-MM LONG AT TOP FRAME, FRONT ORDER BY THE METER
138
SEALING RAIL, RIGHT AT TOP FRAME, FRONT
139
SEALING RUBBER, LEFT AND RIGHT, 359-MM LONG AT TOP FRAME, FRONT ORDER BY THE METER
140
SEALING RAIL AT TOP FRAME, REAR, RIGHT
141
SEALING RUBBER, LEFT AND RIGHT, 359-MM LONG AT TOP FRAME, FRONT ORDER BY THE METER
142
SEALING RAIL, RIGHT AT TOP PILLAR
143
WINDOW SEAL, RIGHT AT TOP PILLAR
999
PAD, 0.5 MM THICK. ZWISCHENLAGE 0,5 X 13 X 50
999
MOUNTING, BOTTOM, RIGHT. LAGER UNTEN RECHTS
999
PAD, 0.3 MM THICK FOR WINDOW LIFTER AT CRANK OPERATED WINDOW
999
MOUNTING, BOTTOM, LEFT. LAGER UNTEN LINKS
999
HEX. HEAD SCREW(HINGE PLATES TO DOOR FRAMEWORK)
999
DOOR BRAKE, RIGHT. DOOR BRAKE WITH THREADED PLATE FOR DRIVER'S DOOR, RIGHT, Replaced By: A1217200243
999
DOOR BRAKE, LEFT. DOOR BRAKE WITH THREADED PLATE FOR DRIVER'S DOOR LEFT, Replaced By: A1217200143
999
INNER OPERATION, LEFT FROM CHASSIS 7502487
999
COVER LID, LEFT UPPER PART FROM CHASSIS 7515628, IS DELIVERED NOT CHROMIUM-PLATED, HAS TO BE FITTED
999
COVER LID, LEFT LOCK SIDE FROM CHASSIS 7515628, IS DELIVERED NOT CHROMIUM-PLATED, HAS TO BE FITTED
999
BINDING RAIL, BOTTOM, LEFT FOR FIXING DOOR LINING
999
BINDING RAIL, HINGE SIDE, LEFT FOR FIXING DOOR LINING
999
ANTISQUEAK, BITUMINOUS FELT CARDBOARD, 3-MM THICK)
999
ORNAMENTAL BAR, LEFT FOR WINDOW MOULDING
999
WINDOW SEAL, LEFT AT TOP PILLAR
999
SEALING RAIL, LEFT AT TOP PILLAR
999
SEALING RAIL AT TOP FRAME, REAR, LEFT
999
SEALING RAIL, LEFT AT TOP FRAME, FRONT
999
SEALING RAIL, LEFT AT FRONT WALL PILLAR
999
STOP FOR TURNBUCKLE, LEFT FROM CHASSIS 6510820, UP TO CHASSIS 6510819 BORE MOUNTING HOLE FOR HOLDING FRAME, FRONT
999
SEALING FRAME FOR DEFLECTOR WINDOW, LEFT FROM CHASSIS 6510820, UP TO CHASSIS 6510819 BORE MOUNTING HOLE FOR HOLDING FRAME, FRONT
999
PARALLEL ARM WINDOW LIFTER WITH SWING JOINT FOR DRIVER'S DOOR, LEFT FROM CHASSIS 6508805
999
COVER PLATE, FRONT, LEFT AT WINDOW MOULDING, IS DELIVERED NOT CHROMIUM-PLATED, HAS TO BE FITTED
999
FELT STRAP, CENTER FOR LINKAGE, INNER LOCK FELT, 4 MM THICK
999
FELT STRAP, REAR FOR LINKAGE, INNER HANDLE (FELT, 4 MM THICK)
999
SHIM 1.5 MM THICK. SHIM 1.50 MM THICK OPTIONAL FOR DOOR HINGE
999
HEX.-HD. SCREW FOR DOOR HINGE AT DOOR, TOP AND BOTTOM
999
FIXING RAIL, LEFT FOR DOOR SEALING RUBBER, BOTTOM
999
CATCH NOSE LOCK, LEFT. DOOR LOCK, LEFT CATCH NOSE LOCK MAKE "KIEKERT" OPTIONAL WITH MAKE "BOMORO", STATE MAKER'S NAME WHEN ORDERING
999
CATCH NOSE LOCK, RIGHT OPTIONAL WITH MAKE "KIEKERT" OR "BOMORO" STATE MAKER'S NAME WHEN ORDERING FROM CHASSIS 7515628
999
CATCH NOSE LOCK, LEFT UP TO CHASSIS 9503507 OPTIONAL MAKE "KIEKERT" WITH MAKE "BOMORO" STATE MAKER'S NAME WHEN ORDERING, APPLICATION OF CATCH NOSE LOCK CHASSIS 8502710, 02713, 02715, 02716, 02721, 02882, 02883, 02884, 02886, 02903, 02949, 02958, 02959, 02961, 02981, 03026, 03035, 03043, 03073, 03079, 03103, 03106, 03110, 03120, 03129, 03279, 03290, 03299, 03442, 03448, 03462, 03464, 03465, 03467, 03470, 03527, 03533, 03534, 03537, 03561, 03606, 03615, 03618, 03980, 03987, 03994, 04024
999
, Replaced By: A301807200405
999
, Replaced By: A301807200305
999
, Replaced By: A301807200405
999
, Replaced By: A301807200305
999
, Replaced By: A301807200405
999
, Replaced By: A301807200305
999
, Replaced By: A301807200405
999
, Replaced By: A301807200305
999
REINFORCEMENT, RIGHT , NO LONGER DELIVERED AS SPARE PART
999
PULL ROD, LEFT FROM LOCK TO INNER OPERATION FROM CHASSIS 7502487
999
REINFORCEMENT, LEFT , NO LONGER DELIVERED AS SPARE PART
999
DOOR LINING, LEFT WITH ARM REST STATE COLOUR WHEN ORDERING AND ENCLOSE SAMPLE OF ARM REST WOOD FROM CHASSIS 7515628
999
DEFLECTOR WINDOW, LEFT
999
COTTER, LEFT FOR CATCH NOSE LOCK
999
GUTTER, RIGHT AT DRIVER'S DOOR, LOCK SIDE FROM CHASSIS 7506482, AS SPARE PART NO LONGER DELIVERED
999
INNER LOCK, LEFT , FROM CHASSIS 7500412
999
PULL ROD, LEFT FROM INNER LOCK TO DOOR LOCK
999
GUTTER, LEFT AT DRIVER'S DOOR, LOCK SIDE, NO LONGER DELIVERED AS SPARE PART
999
WINDOW MOULDING, LEFT STATE ENCLOSE SAMPLE OF VENEER WHEN ORDERING
999
WINDOW LIFTING RAIL, LEFT
999
WINDOW RUN, LEFT LOCK SIDE
999
SUPPORTING FRAME FOR DEFLECTOR WINDOW, LEFT FROM CHASSIS 6510820, UP TO CHASSIS 6510819 BORE MOUNTING HOLE FOR HOLDING FRAME, FRONT
999
DRIVER'S DOOR, SHELL, LEFT WITH HINGE
999
ORNAMENTAL BAR, LEFT BELOW SILL
999
SEALING FRAME FOR DRIVER'S DOOR, LEFT
999
DEFLECTOR WINDOW, LEFT WITHOUT SUPPORTING FRAME AND SEALING FRAME WITH TURNBUCKLE
999
DOOR HINGE, LEFT
999
ORNAMENTAL BAR, LEFT AT SILL, IS DELIVERED NOT CHROMIUM-PLATED, HAS TO BE FITTED
999
RETAINING DOOR STRAP , NO LONGER DELIVERED AS SPARE PART
999
RETAINING DOOR STRAP , Replaced By: A1807200016
999
MOUNTING, BOTTOM, LEFT
999
SHIM 1.2 MM THICK FOR DOOR HINGE OPTIONAL
999
MOUNTING PIN, TOP, LEFT
999
SHIM 2.0 MM THICK. SHIM 2.00 MM THICK OPTIONAL FOR DEFLECTOR WINDOW AT DOOR FRAME, BOTTOM
999
SHIM 1.5 MM THICK OPTIONAL FOR DEFLECTOR WINDOW AT DOOR FRAME, BOTTOM
999
AUSGLEICHSCHEIBE. SHIM 1.0 MM THICK OPTIONAL FOR DEFLECTOR WINDOW AT DOOR FRAME, BOTTOM, Replaced By: A0009841755
999
DOOR BRAKE, LEFT
999
SLIDE , Replaced By: A1155860072
999
HANDLE, CAST PART, RIGHT WITHOUT PUSH BUTTON AND WITHOUT CYLINDRICAL LOCK, NO LONGER DELIVERED AS SPARE PART
999
HANDLE, CAST PART, LEFT WITHOUT PUSH BUTTON AND WITHOUT CYLINDRICAL LOCK FROM CHASSIS 7515628, AS SPARE PART NO LONGER DELIVERED
999
RING FOR PUSH-BUTTON IN HANDLE, CAST PART
999
LATCH, LEFT. TURNBUCKLE, LEFT FROM CHASSIS 8506928, UP TO CHASSIS 8506927, SPECIAL REQUEST, DEFLECTOR WINDOW
999
WINDOW CRANK UP TO CHASSIS 002429
999
RUBBER PAD, LEFT, REAR FOR DOOR HANDLE, NOT LOCKABLE, AT REAR DOOR
999
FIXING PIN AT HANDLE FRONT MAKE "BOMORO" STATE CHASSIS NO. AND MAKER'S NAME WHEN ORDERING UP TO CHASSIS NO. 45 06757
999
SHIM 1.5 MM THICK. SHIM, 1.50 MM THICK FOR COTTER AND FIXING PLATE AT CENTER PILLAR
999
SHIM 0.5 MM THICK. SHIM OPTIONAL LOCK BOLT AT BODY REAR END
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
RUBBER BUFFER
999
WELT, 12 MM LONG. SUPPORTING WELT, 1220-MM LONG RUBBER, BLACK WHEN ORDERING STATE LENGTH
999
WASHER
999
WINDOW GUIDE. WINDOW RUN, FLEXIBLE, 1,870-MM LONG ORDER BY THE METER FROM CHASSIS 8503299 FROM CHASSIS 8503298 SPECIAL REQUEST
999
WASHER
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
WASHER CLEARANCE LAMP ON BRACKET
999
FELT STRAP, FRONT, 40X1, 25-MM LONG ORDER BY THE METER
999
KEY WITH LETTER "T", STATE LETTER AND NUMBER OF LOCK WHEN ORDERING
999
KEY, S-D LOCK FOR DOOR, LUGGAGE COMPARTMENT LID AND REAR MUDGUARD FLAP WHEN ORDERING STATE NUMBER OF LOCK, IS STAMPED AT REAR FIXING O
