Поз.
Артикул
Описание
1
PUMP , Replaced By: A1158690121
6
RESERVOIR
10
BRACKET , Replaced By: A1138600014
17
NOZZLE , 012 UP TO CHASSIS 073976, 016 UP TO CHASSIS 019440, 018 UP TO CHASSIS 019098, 019 UP TO CHASSIS 019405
18
LOCK , 012 UP TO CHASSIS 073976, 016 UP TO CHASSIS 019440, 018 UP TO CHASSIS 019098, 019 UP TO CHASSIS 019405
19
HOSE RESERVOIR DE-AERATION,4 238841 ORDER BY THE METER
20
GROMMET CAB ROOF
21
LOOM TIE , Replaced By: A0009974390
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
NUT BALL PIVOT TO LEVER
999
SCREW BRACKET TO AIR INTAKE PIPE
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER , FROM CHASSIS: 005,007,008,015,017 10/50,12/52 009573, ALSO INSTALLED ON: 009319,009323,009404,009444,009449,009450,009454-009456,009458,009459,009461-009472,009475-009477, 009479-009494,009496-009571. 010 10/50,12/52 013397, ALSO INSTALLED ON: 013289,013348,013354,013356,013358,013361-013367,013370-013381,013384-013388,013390-013395. 005,007,008,015,017 20/60,22/62 012727 010 20/60,22/62 015672
999
PUMP
999
BRACKET
999
PLATE , 016 UP TO CHASSIS 000424
999
GROMMET , Replaced By: A0009972081
999
RESERVOIR , Replaced By: A0008692520, +001A1158600169
999
RESERVOIR , Replaced By: A0008692120, +001A1158600169
999
HOLDER , 016 UP TO CHASSIS 000424
