Поз.
Артикул
Описание
38
CALIPER LEFT,TEVES,LESS LINING, 012 FROM CHASSIS 054903, 014 FROM CHASSIS 043168, 015 FROM CHASSIS 002581
51
BLEEDER VALVETEVES
56
PROTECTIVE CAP , Replaced By: A0004217187
56
PROTECTIVE CAP ,5 962906
57
PISTON
63
SPRING TEVES
63
SPRING , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS: 005,017 016535 015 223409 105,107,108,117,119 033807 110 421313 114 000010 115 228811, Replaced By: A0004211791
64
DOWEL PIN TEVES
67
BRAKE PAD PARTS KIT, 108.016 080479 108.018 086711 108.057,058 003382 109.018 005896 109.056 007251 111.026,027 004432
67
BRAKE PAD , Replaced By: A0014207920
68
REPAIR KIT CALIPER TEVES
74
BRAKE ANCHOR PLATE ,043 000817
77
SEAL RING
78
SEAL RING
79
GASKET
80
SCREW
81
TOOTHED WASHER LEVER TO AIR SPRING VALVE,K 186867
82
NUT
82
NUT , Replaced By: N304032008006
83
BRAKE SHOE RANGE OF DELIVERY
84
SCREW BRAKE SHOE ADJUSTMENT
85
BUSHING
95
REPAIR KIT TURNBUCKLE, 002124
96
SPRING
96
SPRING , Replaced By: A9109931310
97
SPRING , 043 FROM CHASSIS 000817
99
SPRING BRAKE SHOES TO COVER PLATES
100
BEARING HOUSING LEFT
102
CYLINDRICAL PIN
103
SCREW
104
LOCK WASHERTO 001 154 49 02, 000 154 80 01
105
GREASE NIPPLE LOCK ANGLE SENSOR
106
BRACKET BRAKE HOSE, LEFT
110
THRUST WASHER 2.9 MM AS REQUIRED
114
REPAIR KIT
115
BRAKE SUPPORT LEFT
118
PROTECTIVE PLATE LEFT
122
BRACKET , 003549
123
BRACKET
126
SCREW , Replaced By: N304017006034
126
SCREW COVER PLATE TO COVER PLATE M 6 X 10
127
LOCK WASHER LINE MOUNTING
128
SCREW
129
SCREW AUXILIARY FRAME MOUNTING M12X1.5X52
130
LOCK
131
SPACER WASHER 0.1 MM AS REQUIRED
137
LINE FROM PRESSURE RETAINING VALVE TO BRAKE POWER REGULATOR 230 MM
138
RETAINING SPRING BRAKE HOSE TO BRACKET
139
BUFFER
140
CLAMP
141
SCREW , 018 FROM CHASSIS 004750, 056 FROM CHASSIS 002081
145
NUT ,A 057455, 341.023,027,032,034,036,038,041,042,043,044,045 FROM IDENT NO. A 057456 SEE SPARE PARTS LIST 713.0, MF 859A 077314, 341.116 FROM IDENT NO. A 077315 SEE SPARE PARTS LIST 713.0, MF 859
147
REPAIR KIT SUSPENSION
999
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
999
NUT SWITCH TO FLOOR PLATE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
999
STRAP AIR HOSE TO ELBOW AND TO INTAKE CASE 570 MM, ORDER BY THE METER
999
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
999
LOOM TIE ALTERNATOR BREATHING
999
LOOM TIE HAND PUMP
999
SCREW PUMP TO BRACKET
999
SHEET METAL SCREW VALVE TO WINDOW SILL
999
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
999
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
999
SEAL RING. SEALING RING CLUTCH BOOSTER,CONNECTION: "10"
999
NUT BRAKE STAY TO BEARING HOUSING
999
SCREW
999
NUT
999
NUT
999
NUT BALL PIVOT TO LEVER
999
SCREW COVER PLATE TO BRACKET
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
999
SCREW STRAP TO BRACKET
999
SCREW
999
SCREW , Replaced By: N000912006064
999
SPRING WASHER , Replaced By: N000137008212
999
LOCK WASHER ANGLE DRIVE TO BRACKET
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
COTTER PIN LEVER TO SUPPORT
999
COTTER PIN BRAKE SHOE TO BRAKE ANCHOR,4 138316 FROM IDENT NO. 4 138317 SEE UNIT MICROFICHE,MODEL 730.702
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN ROD TO INTERMEDIATE LEVER
999
COTTER PIN
999
BANJO UNION
999
DAMPING STRIP BRAKE LINE TO SIDE MEMBER
999
RETAINER , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
RUBBER BUFFER , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SHACKLE
999
BUSHING , FROM CHASSIS: 010 068872 110 174249
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SPACER TUBE , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SPACER WASHER 1.00 MM AS REQUIRED
999
SPACER WASHER 0.75 MM AS REQUIRED
999
SPACER WASHER 0.5 MM AS REQUIRED
999
BRACKET RIGHT
999
BEARING SHELL , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
THRUST WASHER 3.2 MM AS REQUIRED
999
THRUST WASHER 3.1 MM AS REQUIRED
999
THRUST WASHER 3.0 MM AS REQUIRED
999
RUBBER BUFFER , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SHIM
999
GUIDE , 000,001,010 FROM CHASSIS,ALSO INSTALLED ON,SEE FOOTN.2,100,101,110 FROM CHASSIS 099642,ALSO INSTALLED ON,SEE FOOTN.3,EXCEPT FOR 099892
999
SCREW , UP TO CHASSIS: 023 101126 072 103733 073 106943, Replaced By: A1152950172, +001N000137008202, +001N000933008131
999
BRAKE SUPPORT RIGHT
999
BRAKE CABLE , Replaced By: A1094200885, +001A1145860142
999
BRAKE CABLE , Replaced By: A1094200785, +001A1145860142
999
PROTECTIVE PLATE RIGHT, 018 FROM CHASSIS 003549
999
GUIDE
999
BEARING HOUSING RIGHT
999
FLANGE
999
CYLINDER PIN. PIN
999
PROTECTIVE PLATE RIGHT
999
LINE RIGHT FROM WHEEL CYLINDER TO CONNECTOR
999
BRAKE MASTER CYLINDERBENDIX
999
SENDER UNIT TEVES, REAR SUPPLY CHAMBER, UP TO CHASSIS: 005,017 009971 015 215193 105,107,108,117,119 017585 110 413856 115 218099
999
REPAIR KIT BRAKE MASTER CYLINDER BENDIX
999
REPAIR KIT
999
RESERVOIR TEVES, THREE-CHAMBER, FROM CHASSIS: 017 009972 117 017586 UP TO CHASSIS: 017 062832, FEDERAL, EXCEPT FOR: 059499,060650,061519,061527,062799. 017 062926, CALIFORNIA, EXCEPT FOR 048629,060112,062772 114 029141, EXCEPT FOR: 002250,003131,016950,026317,026334,026513,027268,027269,027272,027281,027513,027518,027822,027824, 028251,029032,029113,029121,029128. 117 10/50 102742, EXCEPT FOR: 098668,099672,100535,100850,100851,101663,102380,102507,102622,102708,102717. 117 12/52 102758, EXCEPT FOR: 088215,099223,099235,099370,099371,099673,100542,101165,101171,101246,102475,102643,102651,102724.
999
BRAKE MASTER CYLINDER "TEVES", 012 UP TO CHASSIS 058443 EXCEPT FOR, SEE FOOTNOTE 46, 014 UP TO CHASSIS 045293 EXCEPT FOR, SEE FOOTNOTE 47
999
CALIPER RIGHT,TEVES,LESS LINING, IN PAIRS OPTIONAL WITH, 000,001,004,010,016 FROM CHASSIS 189499,002,003,005,011,017 FROM CHASSIS 033000,100,101,104,110,116 FROM CHASSIS 355414
999
CALIPER LEFT,LESS PAD ASSEMBLIES, TEVES, IN PAIRS OPTIONAL W/000 421 73 98,BENDIX, FROM CHASSIS: 010 094997 110 244251
999
CALIPER RIGHT,BENDIX,LESS LINING, IN PAIRS OPTIONAL WITH
999
CALIPER LEFT,BENDIX,LESS LINING, IN PAIRS OPTIONAL WITH
999
CALIPER , 024,025 FROM CHASSIS 005158, Replaced By: A0024215598, +001A0004206620
999
CALIPER , Replaced By: A0024215598, +001A0004206720
999
CALIPER , 000,001,004,010,016 FROM CHASSIS 189499,002,003,005,011,017 FROM CHASSIS 033000,100,101,104,110,116 FROM CHASSIS 355414, Replaced By: A0014218298, +001A0004206720
999
CALIPER , Replaced By: A0014210398, +001A0004206720
999
CALIPER , Replaced By: A0014210298, +001A0004206720
999
SEAL RING
999
DOWEL PINBENDIX
999
DOWEL PIN , Replaced By: A0009912660, +001A0004210573
999
LOCKING CAP
999
REPAIR KIT COMPRESSED AIR CYLINDER TO 001 431 72 14,BOSCH,4 600879-4 628861
999
SEAL RINGBENDIX
999
SEAL RING
999
FILLER CAP BUTTRESS THREAD
999
RESERVOIR
999
STRAINER
999
SPRING , 012 UP TO CHASSIS 040645, 014 UP TO CHASSIS 032395
999
SPRING , 088167
999
CALIPER , Replaced By: A0014210398, +001A0004206720
999
CALIPER , Replaced By: A0014210298, +001A0004206720
999
PISTON
999
SPRING
999
LOCKBENDIX
999
PROTECTIVE PLATE
999
LOCK , Replaced By: A0004210573
999
SPRING , 005,007,008,015,017 203606 011 014721
999
LOCK , Replaced By: A0004210573
999
CALIPER RIGHT
999
BLEEDER VALVEBENDIX
999
CALIPER ,043,044 002839, Replaced By: A0004204783, +001A0005862242
999
CALIPER , 043 FROM CHASSIS 002839, Replaced By: A0004204683, +001A0004207120
999
CALIPER , 012 UP TO CHASSIS 054902, 014 UP TO CHASSIS 043167, Replaced By: A0004204683, +001A0004207120
999
CALIPER , 002838, Replaced By: A0004204683, +001A0004207120
999
BRAKE ANCHOR PLATE , 012 UP TO CHASSIS 040645, 014 UP TO CHASSIS 032395, Replaced By: A1084200117, +006A1083570071, +002A1084230092, +006N006797008120
