Поз.
Артикул
Описание
5
FUEL TANK SHEET METAL VERSION, 059607(WHC: WDB) 904078(WHC: VAG)
5
FUEL TANK , Replaced By: A4604700501, +001A4604710309
5
FUEL TANK , Replaced By: A4604700701
9
FUEL TANK , Replaced By: A4604701201
9
FUEL TANK , CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION
13
FUEL STRAINER
13
SCREW PLUG , Replaced By: A1104700486
15
SEAL RING
17
EXTENSION BETWEEN FUEL TANK AND FILLER NECK 215 MM, 059607(WHC: WDB) 904078(WHC: VAG)
19
EXTENSION CONNECTION OF FUEL TANKS
21
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
21
CLAMP LINE MOUNTING 60-80X12MM
21
CLAMP , Replaced By: A0059972990
21
CLAMP , Replaced By: N000000000675
23
CLAMP , Replaced By: N000000000673
23
CLAMP HOSE TO RETARDER 60-80X13 MM
25
FUEL FILLER CAP. FILLER CAP LESS BREATHING, LESS KEYS, LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
25
FUEL FILLER CAP. FILLER CAP LESS BREATHING, LESS KEYS, LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
25
FUEL FILLER CAP WITH VENT, WITH 2 KEYS, LOCK UNDEFINED HUF, 055661(WHC: WDB) 903740(WHC: VAG)
25
FUEL FILLER CAP WITH VENT, LESS KEYS, LOCK DEFINED HUF, STATE LOCK NUMBER WHEN ORDERING 055661(WHC: WDB) 903740(WHC: VAG)
27
SEAL RING
29
KEYTO 000 471 67 30, STATE LOCK NUMBER WHEN ORDERING
33
FILLER NECK
33
FILLER NECK , 020700 (WHC: WDB) 900088 (WHC: VAG)
35
FILLER NECK
44
WASHER COMPRESSED AIR LINE TO BRACKET
44
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
47
SENDER UNIT ,013873
53
SENDER UNIT FUEL TANK
53
SENDER UNIT ,013874 059607(WHC: WDB) 904078(WHC: VAG)
56
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
59
FUEL STRAINER
59
FUEL STRAINER
65
PROTECTIVE PLATE AT TANK, 059607(WHC: WDB) 904078(WHC: VAG)
68
COVERING HEAT INSULATION FUEL TANK TO A 461 470 00 04
71
RUBBER MOUNTING RADIATOR BRACING,TOP,003020
74
SHIM345X35 MM
77
SHIM RIGHT FUEL TANK, 059608(WHC: WDB) 904079(WHC: VAG)
77
SHIM LEFT TO A 461 470 00 04
86
STRAP FUEL TANK MOUNTING, 059607(WHC: WDB) 904078(WHC: VAG)
89
STRAP FUEL TANK MOUNTING, 059608(WHC: WDB) 904079(WHC: VAG)
92
SPRING , 120 023429 123 010750 126 011171 130 017637
95
WASHER EXHAUST MUFFLER TO STRAP
95
WASHER , Replaced By: N000125008443
98
NUT BRACKET TO BATTERY/APPARATUS SUPPORT,5 579088
101
STOP AT CONSOLE FRAME
104
SCREW PUMP TO BRACKET
104
SCREW , Replaced By: N304017006016
107
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
107
WASHER COMPRESSED AIR LINE TO BRACKET
110
NUT OIL TANK TO BRACKET
110
NUT , Replaced By: N913002006009
