Поз.
Артикул
Описание
5
FUEL TANK , Replaced By: A4604701201
5
FUEL TANK SHEET METAL VERSION, 059607(WHC: WDB) 904078(WHC: VAG)
5
FUEL TANK , CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION
8
FUEL STRAINER
8
FUEL STRAINER
11
SEAL RING
14
SENDER UNIT ,013874 059607(WHC: WDB) 904078(WHC: VAG)
17
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
20
EXTENSION BETWEEN FUEL TANK AND FILLER NECK 215 MM, 059607(WHC: WDB) 904078(WHC: VAG)
23
CLAMP , Replaced By: N000000000675
23
CLAMP , Replaced By: A0059972990
23
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
26
FUEL FILLER CAP. FILLER CAP LESS BREATHING, LESS KEYS, LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
29
SEAL RING
44
SEAL RING
101
PROTECTIVE PLATE AT TANK, 059607(WHC: WDB) 904078(WHC: VAG)
107
SHIM345X35 MM
119
STRAP FUEL TANK MOUNTING, 059607(WHC: WDB) 904078(WHC: VAG)
122
SPRING , 120 023429 123 010750 126 011171 130 017637
125
WASHER , Replaced By: N000125008443
125
WASHER EXHAUST MUFFLER TO STRAP
128
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
128
NUT , Replaced By: N913004008001
999
FUEL TANK PARTS KIT, CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION ORDER ADDITIONALLY: A 463 476 24 26
