Поз.
Артикул
Описание
11
VALVE BETWEEN FEED LINE AND HEAT EXCHANGER
14
HOSE TO ELEMENT AT FRONT SEAT
41
SHEET METAL SCREW
44
SPRING WASHER ALTERNATOR CONNECTION D+
65
HOSE FROM ENGINE TO HEAT EXCHANGER
80
CLAMP PRESSURE REGULATOR
80
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
83
CLAMP , Replaced By: N000000000667
86
HOSE FEED,BETWEEN ENGINE AND WATER FAUCET, 042 011568 EXCEPT FOR 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 045 009131 EXCEPT FOR 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 046 000986 EXCEPT FOR 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
89
CLAMP , Replaced By: N000000000667
110
HOSE , 042 011568 EXCEPT FOR 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 045 009131 EXCEPT FOR 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 046 000986 EXCEPT FOR 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
113
SEAL
146
CLAMP , Replaced By: N000000000667
