Поз.
Артикул
Описание
152
REAR AXLE TUBE LEFT
155
REAR AXLE TUBE RIGHT
157
BUSHING
161
VALVE
167
CAP , 012 FROM CHASSIS 031025, 014 FROM CHASSIS 025411
219
BOOT
221
BOOT SPLIT
226
CLIPTO 343 357 00 22
259
SCREW BRACKET TO SIDE MEMBER
265
BRAKE DISC
283
PIN , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
287
SPACER TUBE AS REQUIRED 25.6 MM
287
SPACER TUBE , Replaced By: A1803511653
287
SPACER TUBE AS REQUIRED 25.8 MM
287
SPACER TUBE AS REQUIRED 25.0 MM
287
SPACER TUBE
287
SPACER TUBE AS REQUIRED 25.4 MM
293
SPACER WASHER 2.0 MM
295
SPACER WASHER 2.0 MM
295
SPACER WASHER , Replaced By: A1803511452
299
SPACER RING
304
RUBBER RING
306
PIN
307
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
309
NUT
311
LOCK
313
EXPANSION PLUG
316
SCREW PLUG
317
LOCK
318
GREASE NIPPLE LOCK ANGLE SENSOR
320
GREASE NIPPLE
322
RUBBER MOUNTING , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
324
SUPPORT
327
GROOVED PIN
329
SCREW
331
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
333
THRUST ARM LEFT
335
RUBBER MOUNTING
337
PIVOT PIN
339
WASHER
342
SNAP RING
345
SPACER RING
348
SCREW
350
LOCK
353
RUBBER MOUNTING REAR SUBFRAME MOUNTING
354
PAD SCREW COLLAR TO AXLE HOUSING, 011,017 FROM CHASSIS 004977
356
SCREW PISTON ON TRAILING AXLE
358
LOCK WASHERROCKINGER TYP 59 G140,59 G150
360
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
361
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
365
ROD
367
NUT SPRING BOLT
369
BRACKET
371
RUBBER MOUNTING
373
BRACKET
375
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
375
SCREW , Replaced By: N304017010028
377
SPRING WASHER STEERING COLUMN BRACKET TO CAB
379
SCREW NEGATIVE CABLE TO SIDE MEMBER, 032,033,040,041,132,133,140,141 FROM CAB 1606715
380
SPRING WASHER CAB FLOOR
380
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
382
CUP
384
RUBBER BUFFER
386
CUP
388
NUT , Replaced By: N308673012002
388
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
390
NUT
395
RUBBER MOUNTING
396
MOUNTING PLATE
399
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
403
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
407
NUT
411
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
415
NUT BRACKET TO SIDE MEMBER,K 035196
415
NUT , Replaced By: N308673014001
999
CLAMP REAR AXLE HOUSING
999
CLAMP REAR AXLE TUBE
999
SCREW PIPE CLAMP
999
SCREW , Replaced By: N304017008021
999
WASHER MOUNTING PLATE TO BODY FLOOR
999
SNAP RING 2.55 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.45 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.35 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.25 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
THRUST WASHER AS REQUIRED 1.70 MM
999
THRUST WASHER AS REQUIRED 1.60 MM
999
THRUST WASHER AS REQUIRED 1.50 MM
999
THRUST WASHER AS REQUIRED 1.40 MM
999
LOCK
999
LOCK
999
LOCK
999
LOCK
999
SPACER WASHER , Replaced By: A1803513152
999
SPACER WASHER AS REQUIRED 3.1 MM
999
SPACER WASHER AS REQUIRED 2.8 MM
999
SPACER WASHER , Replaced By: A1803513052
999
SPACER WASHER AS REQUIRED 2.7 MM
999
SPACER WASHER AS REQUIRED 2.6 MM
999
SPACER WASHER 3.0 MM
999
SPACER WASHER 2.5 MM
999
SPACER WASHER 2.4 MM
999
SPACER WASHER 2.3 MM
999
SPACER WASHER 2.2 MM
999
SPACER WASHER 2.1 MM
999
SPACER WASHER AS REQUIRED 1.8 MM
999
SPACER WASHER AS REQUIRED 1.7 MM
999
SPACER WASHER AS REQUIRED 1.6 MM
999
SPACER WASHER , Replaced By: A1123531152
999
SPACER WASHER AS REQUIRED 2.1 MM
999
SPACER WASHER 2.0 MM AS REQUIRED
999
SPACER WASHER 1.9 MM AS REQUIRED
999
RING GEAR AND PINION
999
SCREW
999
AXLE HOUSING
999
REPAIR KIT
999
THRUST ARM RIGHT
999
FLANGE
999
BRACKET RIGHT
999
BRACKET LEFT
999
RING REPAIR SIZE
999
DIFFERENTIAL CASE
999
REAR AXLE
999
REAR AXLE , Replaced By: A1083500103
999
AXLE HOUSING REAR AXLE HOUSING WITH DIFFERENTIAL 1:3.69, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SEAL RING
999
TAPERED ROLLER BEARING
999
TAPERED ROLLER BEARING
