Поз.
Артикул
Описание
5
ELECTRIC CABLE INBOARD,WITH TEMPMATIK,F 194662
5
CABLE HARNESS INBOARD,WITH TEMPMATIK,F 194663
8
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
9
COVERTO 011 545 10 28
14
PIN BUSHING HOUSING BIPOLAR
16
ROUND PIN BUSHING4 MM2
19
PIN BUSHING HOUSING BIPOLAR
20
COVERTO 010 545 10 28
23
PIN BUSHING HOUSING MIRROR ADJUSTMENT SWITCH, 6-POLE
24
COVERTO 010 545 11 28
29
PIN BUSHING HOUSING CONTROL UNIT
32
PIN BUSHING HOUSING INSTRUMENT CLUSTER,15-POLE
33
COVERTO 010 545 04 28
36
PIN BUSHING HOUSINGTO 014 545 64 28
37
COVER LIGHT SWITCH
59
PIN BUSHING HOUSING RELAY CLUSTER
62
PIN BUSHING HOUSING LAMP CONTROL
69
PIN BUSHING HOUSING FANFARE SWITCH
70
ROUND PIN BUSHING2.5 MM2
72
PIN BUSHING HOUSING CONTROL UNIT OF COMFORT CONTROL
72
PIN BUSHING HOUSING SOLENOID VALVE,F 051968
76
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
92
PIN BUSHING HOUSING STEERING COLUMN MOUNTED CABLE HARNESS, 14-POLE
93
COVERTO 009 545 23 28
96
PIN BUSHING HOUSING IGNITION/STARTING SWITCH,7-POLE
97
COVERTO 009 545 73 28,
100
PIN BUSHING HOUSING HEADLAMP,WIPER MOTOR,BLOWER SWITCH
103
PIN BUSHING HOUSING BIPOLAR
109
PIN BUSHING HOUSING 4-POLE, BLOWER MOTOR
109
PLUG TRIPLE
113
PIN BUSHING HOUSING 4-POLE
114
COVER
117
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
118
COVERTO 006 545 81 28
121
PIN BUSHING HOUSING 12-POLE
122
COVERTO 009 545 26 28
123
PIN BUSHING HOUSING REFRIGERANT COMPRESSOR
127
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
134
PLUG HOUSING MAIN CABLE HARNESS
135
COVERTO 011 545 10 28
136
PLUG PIN
145
PIN BUSHING RADIO SET
147
CABLE SHOE. PIN BUSHING PRESSURE SWITCH
148
INSULATING SLEEVETO 000 546 43 40
149
INSULATING SLEEVETO 000 546 83 40
151
GROMMET
153
GROMMET BRANCH-OFF TO WINDSHIELD WIPER
154
GROMMET , ONLY WITH AIR CONDITIONING AUTOMATICS
155
SOCKET
155
SOCKET
158
BULB , Replaced By: N000000001061
158
BULB LIGHTING OF LEFT AND RIGHT OPERATING UNITS AND BLOWER SWITCH
161
FASTENER BUTTON ELECTRIC CABLE TO FIRE WALL
170
SHEET METAL SCREW BRACKET TO CAB
176
SCREW PUMP TO BRACKET
179
SPRING WASHER LICENSE PLATE TO BRACKET
182
BRACKET ELECTRIC CABLE TO HEATING WATER HOSE
209
SOCKET-TERMINAL STRIP BIPOLE, TERMINAL 58D
212
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
215
LOCK WASHER T-FITTING TO BRACKET
