Поз.
Артикул
Описание
5
ELECTRIC MOTOR PANE WIPER BOSCH
5
ELECTRIC MOTOR PANE WIPER SWF
5
ELECTRIC MOTOR , Replaced By: A1248200808
5
ELECTRIC MOTOR , Replaced By: A1248208942
5
ELECTRIC MOTOR , Replaced By: A1248200708
8
CAP WIPER MOTOR BOSCH
8
CAP WIPER MOTOR SWFTO 124 820 89 42
9
PLUG HOUSING
10
COVER
11
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
12
SCREW COVER PLATE TO BRACKET
15
SPRING WASHER LICENSE PLATE TO BRACKET
18
GEARINGSWF, TO BE ADAPTED DURING ASSEMBLY UP TO END OF MODEL YEAR '93
18
GEARINGBOSCH, TO BE ADAPTED DURING ASSEMBLY
18
GEARING , Replaced By: A1248202407, +001A1248204344
18
GEARING , Replaced By: A1248202307
18
GEARING , Replaced By: A1248202307
21
SEAL NOT FOR USE WITH AIR CONDITIONER
21
SEAL ONLY FOR USE WITH AIR CONDITIONER
23
SEAL
25
CAP WIPER SYSTEM MOUNTING PLATE TO FRONT PANEL CENTER
27
LOCK PLATE LEVER TO STRUT
30
LOOM TIE
33
LINKAGEBOSCH
33
LINKAGESWF
33
LINKAGE , Replaced By: A1248200341
36
NUT BRACKET TO PARTITION PANEL,1.9.89 B 065822 F 122353
39
NUT BRACKET TO SUPPORT AND TO END PIECE
42
TOOTHED WASHER BRACKET TO EXHAUST PIPE BRACKET
45
BRACKET WIPER SYSTEM TO COWL
48
BUFFER OIL TANK
51
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
51
NUT , Replaced By: N910112006001
51
NUT , Replaced By: N913023006001
54
CLIP WIPER SYSTEM TO COWL
57
PAD WIPER SYSTEM TO COWL
60
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
63
WIPER ARMBOSCH,F 171151
63
WIPER ARMSWF,F 171150
63
WIPER ARMBOSCH,A 685884 NO.9123, Replaced By: A1248204044, +001A1248200845
63
WIPER ARM ,F 050189F 067349, Replaced By: A1248203844, +001A1248200945
69
CAP , Replaced By: A1248240349
69
CAPSWF,F 050188
69
CAP ,F 171150 NO.7126
75
WIPER BLADEBOSCH,A 685884
75
WIPER BLADE
78
WIPER RUBBER
81
SCREW WIPER ARM TO WIPER ROD
