Поз.
Артикул
Описание
5
ORNAMENTAL COVER LEFT REAR DOOR
5
ORNAMENTAL COVER RIGHT REAR DOOR
11
PAD RIGHT
11
PAD LEFT
14
TREENAIL BRACKET TO FIRE WALL, Replaced By: A6399980185
14
TREENAIL BRACKET TO FIRE WALL
14
TREENAIL REAR DOOR,A 298520
17
SCREW REAR DOOR,A 298520
17
SHEET METAL SCREW
20
SPRING RIGHT
20
SPRING LEFT
21
INSULATION , Replaced By: A1407350798
21
SEAL
23
COVER WINDOW FRAME,RIGHT, A 192208 EXCEPT FOR A 159651 - A 192207 WITH CODE 856NO.9A84I NO.5A98I NO.8E78I NO.8E88I NO.8E88I NO.6B52I NO.3B32I NO.7C23I
23
COVER WINDOW FRAME,LEFT, A 192209 ALSO INSTALLED ON A 159651 - A 192207 WITH CODE 856NO.9A84I NO.5A98I .......I NO.8E78I NO.8F94I .......I .......I NO.7C23I
26
COVER WINDOW STAYBAR TO REAR DOOR, A 192209 ALSO INSTALLED ON A 159651 - A 192207 WITH CODE 856NO.9A84I NO.5A98I .......I NO.8E78I NO.8F94I .......I .......I NO.7C23I
29
SHELL REAR DOOR,BOTTOM,BEHIND PANELLING 530 MM, TO BE ADAPTED DURING ASSEMBLY
29
SEAL , Replaced By: A1407270887
30
INSULATION CENTRAL RIGHT
30
INSULATION CENTRAL LEFT
31
INSULATION REAR RIGHT
31
INSULATION REAR LEFT
35
PANELLING LEFT REAR DOOR,USED WITH VELOURS TRIM,NO.9A88I NO.5B01I NO.8E94I NO.8F17I NO.8F31I NO.6B54I NO.3B35I NO.7C29I I
35
PANELLING RIGHT REAR DOOR, USED WITH VELOURS TRIM,NO.9A88I NO.5B01I NO.8E94I NO.8F17I NO.8F31I NO.6B54I NO.3B35I NO.7C29I I
35
PANELLING RIGHT REAR DOOR, USED WITH LEATHER TRIM,NO.9A84I NO.5A98I NO.8E78I NO.8F19I NO.8F33I NO.6B52I NO.3B32I NO.7C12I I
35
PANELLING LEFT REAR DOOR, USED WITH LEATHER TRIM,NO.9A84I NO.5A98I NO.8E78I NO.8F19I NO.8F33I NO.6B52I NO.3B32I NO.7C12I I
38
PANELLING BOTTOM LEFT,NO.7088I NO.5072I NO.8E42I NO.8F18I NO.8F32I NO.6130I NO.3107I NO.7124I
38
PANELLING BOTTOM RIGHT,NO.7088I NO.5072I NO.8E42I NO.8F18I NO.8F32I NO.6130I NO.3107I NO.7124I
44
PANELLING LEFT REAR DOOR,CENTRAL, USED WITH LEATHER TRIM,NO.9A84I NO.5A98I NO.8E78I NO.8F19I NO.8F33I NO.6B52I NO.3B32I NO.7C12I I
44
PANELLING RIGHT REAR DOOR,CENTRAL, USED WITH VELOURS TRIM,NO.9A88I NO.5B01I NO.8E94I NO.8F17I NO.8F31I NO.6B54I NO.3B35I NO.7C29I I
44
PANELLING LEFT REAR DOOR,CENTRAL, USED WITH VELOURS TRIM,NO.9A88I NO.5B01I NO.8E94I NO.8F17I NO.8F31I NO.6B54I NO.3B35I NO.7C29I I
44
PANELLING RIGHT REAR DOOR,CENTRAL, USED WITH LEATHER TRIM,NO.9A84I NO.5A98I NO.8E78I NO.8F19I NO.8F33I NO.6B52I NO.3B32I NO.7C12I I
59
SCREW CENTER PANELLING AT DOOR TRIM PANEL
80
HANDLE RIGHT REAR DOOR, A 192208 EXCEPT FOR A 159651 - A 192207 WITH CODE 856NO.9045I NO.5070I NO.8310I NO.8E88I NO.8E88I NO.6121I NO.3111I NO.7C23I
80
HANDLE LEFT REAR DOOR, A 192208 EXCEPT FOR A 159651 - A 192207 WITH CODE 856NO.9045I NO.5070I NO.8310I NO.8E88I NO.8E88I NO.6121I NO.3111I NO.7C23I
83
NUT COMPRESSED AIR LINE MOUNTING,5 908243
86
BUSHING (LOCKING KNOB),DOOR LOCKING MECHANISM, A 328811 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 328810 WITH CODE 807NO.9051I NO.5076I .......I NO.8316I NO.8F88I .......I .......I NO.7102I
87
CLIP , Replaced By: A0079889978
87
CLIP DOOR PANELLING
88
SEAL555 MM, TO BE ADAPTED DURING ASSEMBLY
89
SCREW DOOR PANELLING
89
SCREW FOR ADJUSTING FIXED WINDOW
90
LOCK. NUT , Replaced By: A0039941745
90
NUT RETAINER ARMREST,REAR DOOR
90
LOCK
91
WASHER FUSE TO FUSE BOX
92
LOCK , Replaced By: A1269941345
93
SHEET METAL SCREW BRACKET TO CAB 4,2X13
94
PLUG , ONLY REPLACEABLE BY THE SET, Replaced By: A0019881535, +002A0019881535
94
CAP REAR SIDE MEMBER
96
GARNISH MOULDING RIGHT REAR DOOR
96
GARNISH MOULDING LEFT REAR DOOR
98
NUT BOTTOM GARNISH MOULDING TO REAR DOOR, REAR, 000 074246 003 036142 EXCEPT FOR 035979,036029 007 033468 102 053529 103 053849 105 068456 ALSO INSTALLED ON 068265,068282
101
COVER ELECTRIC SEAT ADJUSTER,RIGHT
101
COVER ELECTRIC SEAT ADJUSTER,RIGHT
101
COVER ELECTRIC SEAT ADJUSTER,LEFT
101
COVER ELECTRIC SEAT ADJUSTER,LEFT
119
COVER USED WITH ONE SWITCH
119
COVER
119
COVER USED WITH TWO SWITCHES
122
NUT RETAINER DRIVE TO REAR PILLAR
128
CLIP MOUNTING PLATE TO FIRE WALL
131
SCREW GRAB HANDLE TO INNER PART
134
NUT BOTTOM GARNISH MOULDING TO REAR DOOR, REAR, 000 074246 003 036142 EXCEPT FOR 035979,036029 007 033468 102 053529 103 053849 105 068456 ALSO INSTALLED ON 068265,068282
134
NUT , Replaced By: A1239901750
137
BRACKET ON INTERIOR PLATE,GRAB HANDLE AREA, RIGHT
137
BRACKET ON INTERIOR PLATE,GRAB HANDLE AREA, LEFT
138
BLIND RIVET GRAB HANDLE BRACKET TO INTERIOR PLATE, A 328811 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO A 328810 WITH CODE 807
138
RIVET , Replaced By: A0039902497
140
NUT RETAINER
143
SCREW
155
ASHTRAY REAR DOOR, LESS CIGAR LIGHTER
158
CIGAR LIGHTER
158
CIGAR LIGHTER , Replaced By: A0008201053
161
COVERING
164
SCREW
