Поз.
Артикул
Описание
74
LINE , Replaced By: A1234207228
74
LINE , Replaced By: A1234209428
74
LINE FROM MASTER CYLINDER TO FRONT HYDRAULIC UNIT,F039532
74
LINE FROM BRAKE POWER REGULATOR TO LEFT FRONT WHEEL
74
LINE FROM MASTER CYLINDER TO ADAPTER FITTING, 000 193701 003 097469 086 006508 093 007717 102,103 209243 183 013349 190 020074 193 000014 200 006559 283 001514 INAPPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
77
LINE FROM MASTER CYLINDER TO REAR HYDRAULIC UNIT, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532 NOT FOR R.S.A.
77
LINE FROM MASTER CYLINDER TO REAR HYDRAULIC UNIT
77
LINE FROM BRAKE POWER REGULATOR TO LEFT FRONT WHEEL
77
LINE FROM BRAKE POWER REGULATOR TO LEFT FRONT WHEEL,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
77
LINE FROM DISTRIBUTOR TO REAR LEFT BRAKE HOSE
77
LINE , Replaced By: A1234209528
80
LINE FROM HYDRAULIC UNIT TO LEFT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039531
80
LINE , Replaced By: A1234206728
80
LINE , Replaced By: A1234206528
80
LINE FROM HYDRAULIC UNIT TO LEFT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532 TO BE ADAPTED DURING ASSEMBLY
83
LINE FROM HYDRAULIC UNIT TO RIGHT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532
83
LINE , Replaced By: A1244205528
83
LINE , Replaced By: A1264208728
83
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
89
LINE , Replaced By: A1234207228
89
LINE FROM MASTER CYLINDER TO ADAPTER FITTING, 000 193701 003 097469 086 006508 093 007717 102,103 209243 183 013349 190 020074 193 000014 200 006559 283 001514 INAPPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
89
LINE FROM MASTER CYLINDER TO FRONT RIGHT BRAKE HOSE, INAPPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
92
ADAPTER FITTING BETWEEN THE LINES
95
LINE FROM ADAPTER FITTING TO DISTRIBUTOR, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
98
DAMPING STRIP BRAKE LINE TO LEFT FRONT WHEELHOUSE PANEL
101
SHIM BRAKE LINE TO LEFT FRONT WHEELHOUSE PANEL
101
SHIM , Replaced By: A2023280084
104
LOOM TIE TO MOUNT PLASTIC PIPING
107
CLAMP BRAKE LINE TO LEFT FRONT WHEELHOUSE PANEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532
110
BRACKET , Replaced By: A6674280840
110
BRACKET BRAKE LINE TO FIRE WALL
113
BRACKET BRAKE LINE TO FIRE WALL
116
HOSE BRAKE LINE TO FIRE WALL
