Поз.
Артикул
Описание
10
FUEL TANK , Replaced By: A4634710098, +001A4614700104
10
FUEL TANK , Replaced By: A4604700801
10
FUEL TANK SHEET METAL VERSION, 059607(WHC: WDB) 904078(WHC: VAG)
10
FUEL TANK , Replaced By: A4604701001, +001A4614700004
10
FUEL TANK , Replaced By: A4604701201
10
FUEL TANK
10
FUEL TANK , CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION
20
FUEL TANK REAR RIGHT 15 L,008340
20
FUEL TANK REAR RIGHT 15L, 055661 903740
20
FUEL TANK
20
FUEL TANK REAR RIGHT, 055662 903941
20
FUEL TANK REAR RIGHT 15L, 055661 903740
20
FUEL TANK REAR RIGHT, 055661 903740
20
FUEL TANK REAR RIGHT, 055662 903941
20
FUEL TANK REAR RIGHT 15L, 055662 903941
20
FUEL TANK REAR RIGHT 15 L,008340 055661 903740
20
FUEL TANK REAR RIGHT, 055662 903941
20
FUEL TANK REAR RIGHT 15L
20
FUEL TANK REAR RIGHT, 055661 903740
20
FUEL TANK REAR RIGHT 15 L,008339
20
FUEL TANK REAR RIGHT 15 L,008339
20
FUEL TANK REAR RIGHT 15L, 055662 903941
21
SEAL RING
22
SCREW PLUG , Replaced By: A1114700686
22
SCREW PLUG , Replaced By: A1114700586
22
FUEL STRAINER
24
FUEL TANK REAR LEFT
24
FUEL TANK REAR LEFT 15 L
28
FILLER CAP LOCKABLE
32
SCREW FILLER CAP
34
FILLER CAP
34
FILLER CAP
34
FILLER CAP
36
CHAIN
38
BREATHER PIPE12X1 MM, 021498 900088
40
CLAMP LEAK LINE TO CONNECTOR AT ENGINE
44
BRACKET ADDITIONAL TANK,LEFT
44
BRACKET ADDITIONAL TANK,LEFT
50
BRACKET ADDITIONAL TANK,RIGHT
50
BRACKET ADDITIONAL TANK,RIGHT
52
BRACKET ADDITIONAL TANK,RIGHT
56
SCREW , Replaced By: N304017006018
56
SCREW COVER PLATE TO COVER PLATE M 6 X 12
60
WASHER COMPRESSED AIR LINE TO BRACKET
60
WASHER , Replaced By: N009021006208
64
SPRING WASHER LICENSE PLATE TO BRACKET
68
NUT BALL PIVOT TO LEVER
68
NUT L.H. THREAD
72
SCREW , Replaced By: A2209840429
72
SCREW PANELLING TO BUMPER
76
EXTENSION , Replaced By: A4604730209
76
EXTENSION , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A4604730309
76
EXTENSION , Replaced By: A4604730509
76
EXTENSION CONNECTION OF FUEL TANKS
84
CLAMP HOSE TO RETARDER 60-80X13 MM
84
CLAMP , Replaced By: N000000000673
92
CLAMP , Replaced By: A0059972990
92
CLAMP , Replaced By: N000000000675
92
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
94
FUEL STRAINER
94
FUEL STRAINER
96
FUEL STRAINER
97
FUEL STRAINER
98
EXTENSION FUEL STRAINER SCREEN
98
EXTENSION FUEL STRAINER SCREEN
99
SEAL RING FUEL STRAINER SCREEN SEALING
101
SCREW
102
LOCK WASHER STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET
104
HOSE ADDITIONAL FUEL TANK, ORDER BY THE METER
104
HOSE BREATHER LINE 1060 MM, ORDER BY THE METER
104
HOSE , Replaced By: A1124761226
112
CLAMP
117
LOOM TIE LINE MOUNTING 280 MM
120
PROTECTOR , Replaced By: A4604750346
120
PROTECTIVE PLATE FUEL TANK
120
PROTECTIVE PLATE , Replaced By: A4604700448
121
GROMMET
121
GROMMET
122
GUIDE SIGN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 658987 F 932311, Replaced By: A1245849517
122
GUIDE SIGN REFUELLING PLATE, IN GERMAN
123
GUIDE SIGN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 658987 F 932311, Replaced By: A1245849617
123
GUIDE SIGN REFUELLING PLATE, IN GERMAN
123
CONDENSER
124
FUNNEL , Replaced By: A1694700029
205
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
210
T-FITTING FUEL TANK BREATHING,008339
215
SCREW , Replaced By: A2209840429
215
SCREW PANELLING TO BUMPER
220
COUNTERSUNK WASHER PULLS TO FABRIC RETAINING RAILS AT FOLDING TOP PILLARS
225
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
230
BRACKET
230
BRACKETTO 601 500 16 03,601 500 27 03
999
SEAL RING SPEEDOMETER DRIVE
999
SCREW FILLER CAP
999
FILLER NECK
999
FUEL TANK PARTS KIT, CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION
999
FUEL TANK PARTS KIT, CONVERSION TO PLASTIC FUEL TANK POSSIBLE WITH MANUFACTURER'S CONFIRMATION ORDER ADDITIONALLY: A 463 476 24 26
999
HOSE BETWEEN T-FITTING AND BREATHER VALVE
999
PROTECTIVE PLATE AT TANK, 059607(WHC: WDB) 904078(WHC: VAG)
999
FILLER NECK
999
FUEL TANK , Replaced By: A4604701201
999
BREATHER
999
FUEL FILLER CAP. FILLER CAP LESS BREATHING, LESS KEYS, LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
999
FILLER NECK
999
STRAP , Replaced By: A4634700340
999
FUEL TANK , Replaced By: A4604700701
999
HOUSING
999
FUEL TANK BRACKET TO FRAME
999
DAMPING STRIP40.5X18X18 MM
999
HOSE FROM RETURN LINE TO FUEL TANK, 059608(WHC: WDB) 904079(WHC: VAG)
999
CONNECTOR FROM FUEL TANK TO FUEL TANK,008339
999
INTERMEDIATE PIECE FUEL TANK BREATHING,008339
