Поз.
Артикул
Описание
10
FRONT FENDER RIGHT
10
FRONT FENDER LEFT
10
FRONT FENDER RIGHT
10
FRONT FENDER LEFT
12
FRONT FENDER FRONT LEFT
14
FRONT FENDER FRONT LEFT
16
FASTENING PLATE LEFT FRONT FENDER
20
BRACKET RIGHT FENDER
22
RUBBER BUSHING
30
FENDER WIDENING LEFT, X 20724020130228 TO BE PAINTED PRIOR TO INSTALLATION
30
FENDER WIDENING RIGHT, TO BE PAINTED PRIOR TO INSTALLATION
30
PANELING LEFT FRONT FENDER WIDENING
30
PANELING RIGHT FRONT FENDER, TO BE PAINTED PRIOR TO INSTALLATION
38
EDGE GUARD BOTTOM LEFT, 20131125
40
SEAL RIGHT FRONT FENDER WIDENING, X 19271120110531
50
ANGLE LEFT FRONT FENDER WIDENING
60
ANGLE LEFT FRONT FENDER WIDENING
65
PLATE INNER LEFT FENDER
70
HEXAGON HEAD BOLT. SCREW POWER CYLINDER TO BRACKET
70
SCREW FROM BACK-UP LAMP TO REAR CROSS MEMBER
78
WASHER BRACKET TO BATTERY CASE BRACKET
80
LOCK WASHER BRACKET TO STEERING COLUMN END
90
NUT IN CASE OF SUBSEQUENT INSTALLATION
120
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
120
WASHER
130
ANGLE MUD APRON,LEFT
130
ANGLE ON FENDER PANELING, OUTSIDE RIGHT
140
SCREW COVER PLATE TO BRACKET
141
WASHER COMPRESSED AIR LINE TO BRACKET
141
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
142
HEXALOBULAR BOLT BASIC MODULE AT SUPPORT M6X16,01.08.08
142
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
144
WASHER IN EQUIPMENT BOX
146
WASHER IN EQUIPMENT BOX
146
WASHER COMPRESSED AIR LINE TO BRACKET
148
NUT BRACKET TO REAR PANEL
148
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
160
PANELING RIGHT FRONT LIGHTING UNIT
160
PANELING RIGHT HEADLAMP
160
PANELING LEFT FRONT LIGHTING UNIT
165
BRACKET ATTACHMENT HEADLAMP
170
LOCK INTERIOR LAMP TO REAR PILLAR
180
SHEET METAL SCREW BRACKET TO SUPPORT
190
GRILLE LEFT FRONT LIGHTING UNIT
190
GRILLE RIGHT FRONT LIGHTING UNIT
190
GRILLE LEFT FRONT LIGHTING UNIT
190
GRILLE RIGHT FRONT LIGHTING UNIT
200
GRILLE RIGHT BLINKER LAMP
201
TAPPING SCREW
202
WASHER MAIN MUFFLER SUSPENSION
202
WASHER
203
WASHER
204
NUT HOOK TO BRACKET
205
TAPPING SCREW. SHEET METAL SCREW REAR BUMPER
206
TAPPING SCREW
206
TAPPING SCREW SIDE REFLECTORS,K 057592
207
LOCK FUEL LINE
208
BRACKET PROTECTIVE GRILLE
209
HEXALOBULAR BOLT ELECTRICAL COMPARTMENT M5X25
210
LOCK INTERIOR LAMP TO REAR PILLAR
210
FUSE PROTECTIVE GRILLE TO BUMPER
220
LOCK , 023 143356 033 058518 123 130757 130 149560
230
BEARING , NO.7C01INO.8303I.......I.......I.......I....... I
235
TAPPING SCREW CENTRAL HOUSING TO BRACKET 3.5X22,F 029921
235
TAPPING SCREW
240
CLAMP
250
TAPPING SCREW BRACKET MOUNTING 3.5X25
250
TAPPING SCREW. SHEET METAL SCREW3.5X22
255
TAPPING SCREW
260
TAPPING SCREW
265
SUPPORT BEARING PROTECTIVE GRILLE, LEFT, 9007QFT461A3000 BLACK
270
GRILLE AIR INLET
270
GRILLE COOLING AIR OUTLET
325
WASHER PUMP TO CONSOLE
330
COVER INNER FENDER,FRONT RIGHT
330
COVER FRONT LEFT
360
GROMMET
370
BRACKET LEFT REAR FENDER WIDENING
380
LOCK INTERIOR LAMP TO REAR PILLAR
382
LOCK , Replaced By: A1239942045
384
TAPPING SCREW INSTRUMENT PANEL ON WAIST RAIL 4.2X19
384
TAPPING SCREW GLOVE COMPARTMENT TO INSTRUMENT PANEL
392
SPACER RING WHEELHOUSE COVERING
394
SLEEVE WHEELHOUSE COVERING
400
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
410
WASHER COMPRESSED AIR LINE TO BRACKET
420
NUT SPRING-LOADED PUSH ROD
422
BRACKET LEFT REAR FENDER WIDENING
422
BRACKET WHEELHOUSE COVERING
424
LOCK INTERIOR LAMP TO REAR PILLAR
426
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
428
TAPPING SCREW MOUNTING, WHEELHOUSE COVER
430
SCREW PUMP TO BRACKET M 6X20
430
SCREW LICENSE PLATE TO BRACKET
436
WASHER COMPRESSED AIR LINE TO BRACKET
438
NUT HEATING PIPE TO BRACKET
440
COVER RIGHT REAR WHEELHOUSE
440
COVER REAR LEFT
490
SCREW REAR WINDOW FRAME ON PLATE, BOTTOM
492
SPACER DISK BRACKET TO WHEELHOUSE
495
PLUG AIR INTAKE PIPE
500
SCREW CABLE HARNESS MOUNTING
