Поз.
Артикул
Описание
3
DRIVER'S DOOR, SHELL, LEFT WITH HINGE AND MOUNTING HOLES FOR MOUNTING OF ORNAMENTAL BAR
4
DRIVER'S DOOR, SHELL, RIGHT WITH HINGE AND MOUNTING HOLES FOR MOUNTING OF ORNAMENTAL BAR
5
HINGE, TOP FOR LEFT DRIVER'S DOOR
6
HINGE, TOP FOR RIGHT DRIVER'S DOOR
7
HINGE BOLT
8
SPACER, TOP 0.8 MM THICK OPTIONAL
9
HINGE, BOTTOM FOR LEFT DRIVER'S DOOR
10
HINGE, BOTTOM FOR RIGHT DRIVER'S DOOR
11
HINGE BOLT
12
SPACER, BOTTOM 0.8-MM THICK OPTIONAL
15
AIR NOZZLE FOR LEFT DRIVER'S DOOR PARTS ARE DELIVERED WITHOUT BEING CHROM.-PLATED, MUST BE FITTED
16
AIR NOZZLE FOR RIGHT DRIVER'S DOOR PARTS ARE DELIVERED WITHOUT BEING CHROM.-PLATED, MUST BE FITTED
17
PIN-TYPE LOCK WITH REMOTE CONTROL, DESIGN LEFT FOR LEFT DRIVER'S DOOR
18
PIN-TYPE LOCK WITH REMOTE CONTROL, DESIGN RIGHT FOR RIGHT DRIVER'S DOOR
19
LOCK WITHOUT REMOTE CONTROL, DESIGN LEFT FOR LEFT DRIVER'S DOOR
20
LOCK WITHOUT REMOTE CONTROL, DESIGN RIGHT FOR RIGHT DRIVER'S DOOR
21
REMOTE CONTROL FOR LEFT DRIVER'S DOOR
22
REMOTE CONTROL FOR RIGHT DRIVER'S DOOR
23
ABDECKKAPPE LINKS UBER SCHLOSS AN FONDTUR
24
ABDECKKAPPE RECHTS. COVER CAP, RIGHT OVER LOCK AT DRIVER'S DOOR
30
DOOR HANDLE, LOCKABLE, CHROM.-PLATED FOR LEFT DRIVER'S DOOR WHEN ORDERING STATE LOCK NO.
31
DOOR HANDLE, NOT LOCKABLE, CHROM.-PLATED FOR RIGHT DRIVER'S DOOR
32
ROSETTE LINKS FUR TURGRIFF AN FAHRERTUR
33
ROSETTE RECHTS. ESCUTCHEON, RIGHT FOR RIGHT DRIVER'S DOOR FOR DOOR HANDLE, LOCKABLE, AT DRIVER'S DOOR
34
GUMMIUNTERLAGE FUR TURGRIFF SIEHE TAFEL 94 BILD NR. 35
35
SCHEIBE WAHLWEISE FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
36
INNENDRUCKER
37
ROSETTE VERCHROMT FUR INNENDRUCKER
38
ABSTANDROHR FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
39
SCHEIBE WAHLWEISE FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
40
AUFSTECKBUCHSE ZWISCHEN SPEZIALSCHRAUBE UND TURGRIFF
41
SICHERUNGSSCHRAUBE. LOCKING SCREW SPECIAL SCREW FOR DOOR HANDLE
42
SCHLIESSOSE
43
UNTERLEGPLATTE WAHLWEISE FUR SCHLIESSOSE AN KASTENSAULE
44
COVER PLAT, CHROM.-PLATED ON CATCH OPENING, REAR
45
DOOR BRAKE IN FRONT WALL
46
DOOR RETAINING STRAP
47
GUMMIPUFFER. RUBBER BUFFER FOR DOOR RETAINING STRAP
48
PLATTE FUR TURHALTER
49
SPRING RELEASE SPRING AT DOOR, FRONT
50
TURZIEHGRIFF VERCHROMT. TURZIEHGRIFF
55
WINDOW RUN, FRONT, LEFT, CHROM.-PLATED
56
WINDOW RUN, FRONT, RIGHT, CHROM.-PLATED
58
WINDOW RUN, REAR, RIGHT
59
WINDOW RUN, REAR, LEFT
60
WINDOW RUN, REAR, RIGHT
61
FENSTERPRESSER AUSSEN. WINDOW PRESSER, EXTERIOR
62
FENSTERPRESSER INNEN LINKS
63
FENSTERPRESSER INNEN. WINDOW PRESSER, INTERIOR, RIGHT
66
JOINT WINDOW LIFTER, LEFT FOR CRANKING DEVICE
67
JOINT WINDOW LIFTER, RIGHT FOR CRANKING DEVICE
68
KURBEL VERCHROMT. KURBEL FUR FENSTER SIEHE AUCH TAFEL 94 BILD NR. 24
69
BOLZEN. CYLINDRICAL PIN FOR WINDOW CRANK DELIVERED TOGETHER WITH CRANK, NOT MOUNTED
70
ROSETTE VERCHROMT. ESCUTCHEON WITH PRESSURE SPRING AND SLEEVE TO WINDOW CRANK
90
ORNAMENTAL MOULDING, LEFT FOR DRIVER'S DOOR, TOP CHROM.-PLATED
91
ORNAMENTAL MOULDING, RIGHT FOR DRIVER'S DOOR, TOP CHROM.-PLATED
92
WINDOW RUN, FRONT, 670-MM LONG, HINGE SIDE PROFIL-NR. 000 985 05 30
93
WINDOW RUN, TOP AND REAR, 1310-MM LONG, LOCK SIDE PROFIL-NR. 000 985 05 30
94
ABDICHTKODER 30 MM LANG. ABDICHTKODER 340 MM LANG BEI BESTELLUNG FARBE, LANGE UND AUFBAU-NUMMER ANGEBEN FUR SCHUTZKAPPE AN FONDTUR
95
CRANK WINDOW, LEFT
96
CRANK WINDOW, RIGHT
97
GLASSPANE FOR DRIVER'S DOOR, LEFT 4.5 MM THICK
98
GLASSPANE FOR DRIVER'S DOOR, RIGHT 4.5 MM THICK
99
WINDOW LIFTING RAIL, LEFT
100
WINDOW LIFTING
101
SUPPORTING RAIL, LEFT
102
SUPPORTING RAIL, RIGHT
103
ABDICHTUNGSGUMMI 925-MM. GUMMIPROFIL 545 MM LANG BEI BESTELLUNG LANGE ANGEBEN
104
SPACER , Replaced By: A0009870842
114
WINDOW MOULDING, LEFT, EDGE WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
115
WINDOW MOULDING, RIGHT, EDGE WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
116
WINDOW MOULDING, FRONT, LEFT WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
117
WINDOW MOULDING, FRONT, RIGHT WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
118
WINDOW MOULDING, BENT, LEFT WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
119
WINDOW MOULDING, BENT, RIGHT WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
132
ZWISCHENLAGE GUMMI SCHWARZ ZWISCHEN VORREIBER LINKS UND RECHTS
135
VORREIBER LINKS. LATCH, LEFT FOR DEFLECTOR PANE CHROM.-PLATED
136
VORREIBER RECHTS FUR DREHFENSTER
137
ACHSE FUR VORREIBER AN FENSTERRAHMEN
138
SPRING WASHER TURN BUCKLE AT WINDOW
147
ARRETIERWINKEL LINKS
148
ARRETIERWINKEL RECHTS
149
WASHER
155
DEFLECTOR PANE, LEFT COMPL. AT DRIVER'S DOOR, FRONT, HINGE SIDE
156
DEFLECTOR PANE, RIGHT COMPL. AT DRIVER'S DOOR, FRONT, HINGE SIDE
157
SUPPORTING FRAME, LEFT FOR RUBBER FRAME
158
SUPPORTING FRAME, RIGHT FOR RUBBER FRAME
159
DEFLECTOR PANE, LEFT
160
DEFLECTOR PANE, RIGHT
161
WINDOW FRAME, LEFT CHROM.-PLATED
162
WINDOW FRAME, RIGHT CHROM.-PLATED
163
GUMMIPROFIL 700 MM LANG BEI BESTELLUNG LANGE ANGEBEN
165
GLASSPANE, LEFT FOR DEFLECTOR PANE 4.5 MM THICK
166
GLASSPANE, RIGHT FOR DEFLECTOR PANE 4.5 MM THICK
171
WASSERRINNE LINKS FUR DREHFENSTER
172
WASSERRINNE RECHTS. GUTTER, RIGHT FOR DEFLECTOR WINDOW
175
RUBBER FRAME, LEFT FOR DEFLECTOR PANE, DRIVER'S DOOR
176
RUBBER FRAME, RIGHT FOR DEFLECTOR PANE, DRIVER'S DOOR
177
LAGER UNTEN LINKS. SEAT, BOTTOM, LEFT
178
LAGER UNTEN RECHTS. SEAT, BOTTOM, RIGHT
999
SCHLUSSEL. KEY, CHROM.-PLATED SAME LOCK LIKE DOOR HANDLE AND TANK ROOM LOCK
999
HINGE BOLT FOR HINGE, TOP FOR REPAIR DESIGN
999
HINGE BOLT. SCHARNIERBOLZEN 8,2 O 65-MM LG. FUR SCHARNIER UNTEN FUR REPARATURAUSFUHRUNG
999
SCHEIBE. WASHER FOR DOOR HANDLE, NOT LOCKABLE, AT REAR DOOR
999
SCHEIBE WAHLWEISE FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
999
UNTERLEGPLATTE WAHLWEISE FUR SCHLIESSOSE AN KASTENSAULE
999
SPACER, BOTTOM 1.5-MM THICK OPTIONAL
999
SPACER, TOP 1.5 MM THICK OPTIONAL
