Поз.
Артикул
Описание
5
TRIM BUMPER FRONT BUMPER, A 10483520090930800 TO BE PAINTED PRIOR TO INSTALLATION 9999QFT251L9000 COLORLESS
5
TRIM BUMPER FRONT BUMPER, A 10483520090930800 TO BE PAINTED PRIOR TO INSTALLATION 9999QFT251L9000 COLORLESS
5
TRIM BUMPER FRONT BUMPER, A 10483520090930800 TO BE PAINTED PRIOR TO INSTALLATION 9999QFT251L9000 COLORLESS
5
TRIM BUMPER FRONT BUMPER, A 10483520090930800 TO BE PAINTED PRIOR TO INSTALLATION 9999QFT251L9000 COLORLESS
11
COVER TOWING EYE TOWING EYE
12
CAP HEADLAMP WIPER,RIGHT
12
CAP HEADLAMP WIPER,LEFT
15
SPRING HEADLAMP CLEANING SYSTEM
20
FRAME INSIDE PART, A 11496520100722801
20
BASIC MOUNTING FOR BUMPER FRONT BUMPER, A 10483520090930800
20
BASIC MOUNTING FOR BUMPER INSIDE PART, A 11496520100722801
30
ENERGY-ABSORBING UNIT CENTRAL, A 11496520100722801
30
IMPACT ABSORBER CENTRAL, A 11496520100722801
30
IMPACT ABSORBER CENTRAL, A 10483520090930800
30
IMPACT ABSORBER CENTRAL, A 10483520090930800
30
ENERGY-ABSORBING UNIT CENTRAL, A 11496520100722801
40
IMPACT ABSORBER LEFT, A 10483520090930800
40
IMPACT ABSORBER LEFT, A 11496520100722801
40
IMPACT ABSORBER LEFT, A 10483520090930800
40
ENERGY-ABSORBING UNIT LEFT, A 11496520100722801
50
ENERGY-ABSORBING UNIT RIGHT, A 11496520100722801
50
IMPACT ABSORBER RIGHT, A 11496520100722801
50
IMPACT ABSORBER RIGHT, A 10483520090930800
50
IMPACT ABSORBER RIGHT, A 10483520090930800
70
BLIND RIVET AT COVERING
80
LOCK NUT. LOCK PANELLING TO BUMPER
90
HOLDDOWN CLIP INTERIOR PART TO PANELLING, A 10483520090930800
100
ELECTRICAL WIRING HARNESS PARKTRONIC SYSTEM, A 10483520090930800
100
WIRING HARNESS PARKTRONIC SYSTEM, A 11496520100722801
120
INTERMEDIATE LAYER ADHESIVE TAPE
150
DISTANCE SENSOR , TO BE PAINTED PRIOR TO INSTALLATION
150
DISTANCE SENSOR PARKTRONIC SYSTEM, E 02900020071206808 TO BE PAINTED PRIOR TO INSTALLATION
160
SPACER RING SENSOR
160
SPACER RING PARKTRONIC SYSTEM, A 55589720030630804 E 02000020070101804 A 97499920070630 E 06000020080901809
202
COVER BUMPER AREA DAYTIME RUNNING LAMP AND FOG LAMP, RIGHT, A 10483520090930800
202
COVER BUMPER AREA DAYTIME RUNNING LAMP AND FOG LAMP, LEFT, A 10483520090930800
204
COVER BUMPER AREA RIGHT LED DAYTIME RUNNING LIGHT, A 10483520090930800
204
COVER BUMPER AREA LEFT LED DAYTIME RUNNING LIGHT, A 10483520090930800
210
CHROMIUM COVER RIGHT INSIDE
210
ORNAMENTAL MOLDING CHROMIUM COVER, RIGHT
210
CHROMIUM COVER RIGHT OUTSIDE
210
CHROMIUM COVER LEFT OUTSIDE
210
CHROMIUM COVER LEFT INSIDE
210
ORNAMENTAL MOLDING CHROMIUM COVER, LEFT
220
COVER BUMPER AREA LEFT LED DAYTIME RUNNING LIGHT, A 11994820100930801
220
COVER BUMPER AREA RIGHT LED DAYTIME RUNNING LIGHT, A 10483520090930800
220
ORNAMENTAL MOLDING LEFT LED DAYTIME RUNNING LIGHT, A 11496520100722801
220
ORNAMENTAL MOLDING RIGHT LED DAYTIME RUNNING LIGHT, A 11496520100722801
230
SHEET METAL SCREW BRACKET TO FIRE WALL
240
LOCK NUT BRACKET TO RIGHT FRONT SIDE MEMBER ST 4.8/2.5-5.0 MM
350
INTERMEDIATE LAYER FASTENING, BUMPER TO RIGHT FENDER, A 11496520100722801
350
INTERMEDIATE LAYER FASTENING, BUMPER TO LEFT FENDER, A 10483520090930800
350
INTERMEDIATE LAYER RIGHT, A 10483520090930800
350
INTERMEDIATE LAYER FASTENING, BUMPER TO LEFT FENDER, A 11496520100722801
420
GRILLE BUMPER FRONT CENTER, A 11496520100722801
420
PROTECTIVE GRILLE BUMPER FRONT CENTER, A 10483520090930800
490
BOLT FRONT BUMPER MOUNTING M6X45
495
STOP PLUG HOLLOW SCREW, A 11496520100722801
500
NUT FASTENING FOR LINING, A 10483520090930800
510
SCREW LICENSE PLATE TO BRACKET
520
WASHER COMPRESSED AIR LINE TO BRACKET
550
COVER BUMPER AREA UNDERRUN PROTECTION, A 10483520090930800
560
RIVET COVERING TO SIDE MEMBER
570
INTERMEDIATE LAYER FASTENING, BUMPER TO LEFT FENDER, A 10483520090930800
570
INTERMEDIATE LAYER RIGHT, A 10483520090930800
575
BLIND RIVET WITH PAN HEAD
580
BRACKET RIGHT, A 10483520090930800
580
BRACKET LEFT, A 10483520090930800
585
SCREW LICENSE PLATE TO BRACKET
590
WASHER COMPRESSED AIR LINE TO BRACKET
595
BOLT THREADED CONNECTION, NOZZLE TUBE TO INSTRUMENT PANEL 4X12
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOLDING FRONT, A 10483520090930800
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOLDING FRONT, A 20130227
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
COVER FRONT
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOLDING FRONT, A 10483520090930800
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOULDING FRONT, A 11496520100722801
600
LICENSE PLATE MOLDING ADDITIONAL, A 20130227
600
LICENSE PLATE MOULDING FRONT
610
LOCK NUT. LOCK PANELLING TO BUMPER
620
PAN HEAD SCREW. SCREW GROUND CONNECTION
630
CLIP-TYPE NUT BUMPER ON FENDER K40, A 10483520090930800
640
BOLT LICENCE PLATE TRIM
640
SHEET METAL SCREW ORNAMENTAL COVER TO BUMPER
