Поз.
Артикул
Описание
8
TORSION BAR STABILIZER,D 012296
11
BUSHING
17
BEARING BRACKET HOLE SPACING: 100 MM
18
BEARING SHELL TORSION BAR BEARING
23
GROMMET STABILIZER
23
GROMMET STABILIZER
32
SCREW BELL HOUSING TO ENGINE
35
WASHER GROUND CABLE
38
HEXAGON HEAD BOLT. SCREW GUSSET PLATE TO FRAME M14 X 1.5 X 70
41
WASHER
47
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
95
ROD (ARTICULATED ROD)
116
SHOCK ABSORBER FRONT
122
RUBBER MOUNTING
125
BUSHING
134
RUBBER MOUNTING , UP TO IDENT-NO.: LB887910 ALSO INSTALLED IN: LB887915,LB887936,LB888020,LB888023,LB888026* FROM IDENT-NO.: SEE STANDARD MICROFICHE EXCEPT:LB887915,LB887936,LB888020,LB888023,LB888026*
137
SPACER TUBE , UP TO IDENT-NO.: LB887910 ALSO INSTALLED IN: LB887915,LB887936,LB888020,LB888023,LB888026* FROM IDENT-NO.: SEE STANDARD MICROFICHE EXCEPT:LB887915,LB887936,LB888020,LB888023,LB888026*
138
BEARING BRACKET
147
SCREW BATTERY CASE
153
NUT , Replaced By: N910113014000
156
SPACER TUBE SHOCK ABSORBER TO UPPER BEARING BRACKET,D 204382
157
SCREW SHOCK ABSORBER TO UPPER BEARING BRACKET,D 204382
161
NUT , Replaced By: N910113016001
164
CONSOLE FRONT SHOCK ABSORBERS
167
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
170
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
173
WASHER SUPPORT TO FRAME,D 127794
176
SCREW SHOCK ABSORBER TO BRACKET
179
LOCK WASHER TRANSMISSION TO BELL HOUSING
