Поз.
Артикул
Описание
5
FRONT SPRING 12-LEAF
10
SPRING LEAFNO.1
15
BUSHING FRONT
15
BUSHING FRONT
20
SPRING LEAFNO.2
25
SPRING LEAFNO.3
25
SPRING LEAF , Replaced By: A6593210713
30
SPRING LEAFNO.4
30
SPRING LEAF , Replaced By: A6593210714
35
SPRING LEAFNO.5
35
SPRING LEAF , Replaced By: A6593210615
40
SPRING LEAFNO.6
40
SPRING LEAF , Replaced By: A6593210616
45
SPRING LEAFNO.7
45
SPRING LEAF , Replaced By: A6593210617
50
SPRING LEAFNO.8
50
SPRING LEAF , Replaced By: A6593210618
55
SPRING LEAFNO.9
55
SPRING LEAF , Replaced By: A6593210619
60
SPRING LEAFNO.10
65
SPRING LEAF , Replaced By: A6593210421
70
SPRING LEAFNO.12
70
SPRING LEAF , Replaced By: A6593210422
70
SPRING LEAF , Replaced By: A3873210122
75
SCREW (SPRING BOLT)
75
SCREW , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 269038, Replaced By: A3873210071
80
NUT STEERING SUPPORT TO FRAME
80
NUT , Replaced By: N910113014000
85
SPRING CLAMP SPRING EYE,FRONT AND REAR,5 1933955 533057
85
SPRING CLAMP , Replaced By: A6203240433
85
SPRING CLAMP ,5 193394, Replaced By: A6203240733, +001N000963012011
85
SPRING CLAMP , Replaced By: A0023219233
90
SCREW FOR SPRING CLAMPS
90
SCREW FOR SPRING CLAMPS,5 484789
90
SCREW , Replaced By: N308765012007
95
WASHER FOR SPRING CLAMPS
100
NUT STRAP TO SUPPORT
105
SHACKLE PIN PARTS KIT
105
REPAIR KIT , Replaced By: A3953200165
105
REPAIR KIT , Replaced By: A3955860332
105
SHACKLE PIN , Replaced By: A3955860332
105
SHACKLE PIN , Replaced By: A3955860332
110
SHACKLE FRONT SPRING
110
SHACKLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 354866, Replaced By: A3873200162
115
BUSHING FRONT
115
BUSHING FRONT
120
SHACKLE PIN PARTS KIT
120
REPAIR KIT , Replaced By: A3953200265
120
REPAIR KIT , Replaced By: A3955860232
120
SHACKLE PIN , Replaced By: A3955860232
120
SHACKLE PIN , Replaced By: A3955860232
125
GREASE NIPPLE
130
WASHER AS REQUIRED 4.00 MM
130
WASHER AS REQUIRED 4.20 MM
130
WASHER AS REQUIRED 4.30 MM
135
SEAL RING SPRING SUSPENSION
140
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
145
WASHER RADIATOR TO RUBBER MOUNTING
145
WASHER , Replaced By: N000125010532
150
NUT STRAP TO BRACKET
150
NUT , Replaced By: N910113010000
155
SHIM FRONT SPRINGS TO FRONT AXLE
155
SHIM FRONT SPRINGS TO FRONT AXLE
155
SHIM FRONT SPRINGS TO FRONT AXLE
155
SHIM FRONT SPRINGS TO FRONT AXLE
160
PIN , Replaced By: A6573310074
165
RUBBER BUFFER SPRING STOP
165
RUBBER BUFFER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 389516, Replaced By: A6553310044
170
PLATE FRONT SPRINGS TO FRONT AXLE
170
PLATE , Replaced By: A6483310026
170
PLATE FRONT SPRINGS TO FRONT AXLE
170
SPACER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 389516, Replaced By: A6483310026
175
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
175
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
175
U-BOLT , Replaced By: A3873310925
185
NUT REAR SPRING TO REAR AXLE
185
NUT , Replaced By: N308674020000
185
NUT , Replaced By: N308673020002
195
RUBBER BUFFER SPRING STOP TO FRAME BOTTOM SIDE
200
SPACER RING SPRING STOP TO FRAME BOTTOM SIDE
205
SCREW
210
NUT STRAP TO BRACKET
210
NUT , Replaced By: N910113010000
215
BEARING RIGHT
215
BEARING LEFT
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE4 707618, Replaced By: A3875860232
999
SCREW SHACKLE TO CONSOLE
