Поз.
Артикул
Описание
5
CROSS MEMBER FRONT
11
GUSSET PLATE , Replaced By: A6203120987
11
GUSSET PLATE , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3873122087
11
GUSSET PLATE
11
GUSSET PLATE FRONT LEFT, TO BE ADAPTED DURING ASSEMBLY
15
SHIM SUPPORT TO SIDE MEMBER
23
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
23
SCREW , Replaced By: N308676012026
29
WASHER
35
COUPLING PIN FOR COUPLING MOUTH
38
SEALING CORD FOR COUPLING MOUTH
41
LOCKING SPRING TO SECURE COUPLING PIN
44
SCREW , Replaced By: N304017008034
44
SCREW BRACKET TO CROSS CONNECTION STRUT
47
WASHER , Replaced By: N000125008443
47
WASHER EXHAUST MUFFLER TO STRAP
50
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
53
NUT
57
FRONT SPRING BRACKET FRONT
59
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
59
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
62
NUT , Replaced By: N910113016001
62
NUT CONSOLE TO SUPPORT
65
PLATE HELPER SPRING
72
REAR SUBFRAME REAR
74
RUBBER MOUNTING
74
RUBBER MOUNTING
80
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
81
SCREW BEARING BRACKET TO SIDE MEMBER M 14X1.5X28
82
NUT , Replaced By: N910113014001
82
NUT BRACKET TO SIDE MEMBER
84
CROSS MEMBER
85
BRACKET LEFT AND RIGHT
85
BRACKET , Replaced By: A6163120040
86
REINFORCEMENT CROSS MEMBER AT REAR SPRING REAR BRACKET
92
SCREW , Replaced By: N308676014008
92
SCREW ROD TO TRANSFER CASE M 14X65
92
SCREW MOUNTING TO CONSOLE M 14X35
92
SCREW , Replaced By: N308676014013
92
SCREW REAR SPRING REAR BRACKET AND STRUT TO SIDE MEMBER
95
NUT STEERING SUPPORT TO FRAME
95
NUT , Replaced By: N910113014000
