Поз.
Артикул
Описание
54
LINE FROM CLUTCH BOOSTER,CONNECTION "10",TO DISTRIBUTOR,CONNECTION: "20"
55
UNION NUT LINE CONNECTION, Replaced By: N000000006239
55
UNION NUT LINE CONNECTION
56
SEAL CONE LINE CONNECTION
56
GLAND , Replaced By: A0019901967
57
HOSE , Replaced By: A0009872827
57
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
58
CONNECTOR , Replaced By: A0019904078
58
CONNECTOR RELEASE BEARING LUBRICATION
59
SEAL RING CONNECTOR 11.8X2 MM
59
SEAL RING , Replaced By: A0229973948
60
FITTING BULKHEAD FITTING,CONNECTION: "10"
62
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
63
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
84
BRACKET CLUTCH LINE TO TRANSMISSION
86
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
86
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
86
CLAMP ,K 147121, Replaced By: N000000000319
86
CLAMP LINE MOUNTING
89
SCREW COVER PLATE TO COVER PLATE M 6 X 12
89
SCREW PUMP TO BRACKET
89
SCREW , Replaced By: N304017006016
92
NUT BALL PIVOT TO LEVER
92
NUT PUMP TO BRACKET
999
NUT STRAP TO BRACKET
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
WASHER , Replaced By: N006902011102
999
BRACKET CLUTCH LINE
999
WASHER , Replaced By: N006902011100
