Поз.
Артикул
Описание
1
GETRIEBE VOLLSYNCHRONISIERT MIT KUPPLUNGSGEHAUSE
2
TRANSMISSION CASE. TRANSMISSION HOUSING
5
GEAR
6
BUSHING
7
REVERSE IDLER SHAFT
10
LEVER
12
SCHALTKLAUE. COLLAR
13
VORGELEGEWELLE MIT. COUNTERSHAFT WITH KEY
14
KEY
15
VORGELEGERAD 24 ZAHNE FUR 3. GANG
16
VORGELEGERAD 28 ZAHNE FUR 4. GANG
19
SPACER WASHER , Replaced By: A6022630352
20
WASHER
21
ANTRIEBSWELLE MIT. DRIVE SHAFT WITH KEY
22
PASSFEDER
23
SCHRAUBENRAD 19 ZAHNE. HELICAL GEAR, 19 TEETH ON DRIVE SHAFT
24
OIL RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
25
SPACER RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
29
AUSGLEICHSCHEIBE, 0,3-MM. AUSGLEICHSCHEIBE 0,3 MM WAHLWEISE FUR ANTRIEBSWELLE AN GETRIEBEGEHAUSE
30
SNAP RING , Replaced By: A1232620494
33
MAIN SHAFT UP TO TRANSMISSION 7502165
34
KEY
35
SYNCHRONIZER BODY FOR 1ST AND 2ND GEAR, Replaced By: A1112600545
36
SYNCHRONIZER BODY. SYNCHRONIZING BODY
37
REPLACED BY 180 993 41 01 ONLY EXCHANGEABLE IN SETS UP TO TRANSMISSION 7518100, Replaced By: A1809934101
39
FOLLOWER. MITNEHMER 12,2 X 13 MM AB GETRIEBE-NR. 00555/53 MIT AUSNAHME VON 00871--01000/53
40
REPLACED BY 111 262 03 23 FOR 1ST AND 2ND GEAR, Replaced By: A1112620323
41
SYNCHRONIZING RING FOR THIRD SPEED AND FOURTH SPEED
42
THRUST WASHER 7.90 MM
43
THRUST WASHER 4.40 MM
44
SCHRAUBENRAD 25 ZAHNE FUR 2. GANG
45
ROLLER ASSEMBLY
46
SCHRAUBENRAD 25 ZAHNE. HELICAL GEAR, 25 TEETH FOR 3RD GEAR
47
THRUST WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
48
SYNCHRONIZER BODY FOR THIRD SPEED AND FOURTH SPEED FROM TRANSMISSION NO. 02750/53
49
SYNCHRONIZER BODY. SYNCHRONIZER
50
REPLACED BY 180 993 41 01 ONLY EXCHANGEABLE IN SETS UP TO TRANSMISSION 7518100, Replaced By: A1809934101
52
FOLLOWER. MITNEHMER 12,2 X 13 MM AB GETRIEBE-NR. 00555/53 MIT AUSNAHME VON 00871--01000/53
53
, Replaced By: A1112620423
54
SYNCHRONIZING RING FOR THIRD SPEED AND FOURTH SPEED
55
GROOVED NUT
56
LOCK
57
ROLLER ASSEMBLY
58
SCHRAUBENRAD 28 ZAHNE FUR 1. GANG
59
ROLLER ASSEMBLY , Replaced By: A0019816910
60
THRUST WASHER 3.80 MM
61
BALL BEARING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359, Replaced By: A0029810625
63
SPACER WASHER 0.10 MM
64
WORM GEAR. HELICAL GEAR (FOR SPEEDOMETER DRIVE)
65
GETRIEBEGEHAUSEDECKEL. TRANSMISSION HOUSING COVER, FRONT
66
SEAL RING
67
KUGELBOLZEN. BALL PIN FOR RELEASE FORK
71
LOCKING PLATE FOR TRANSMISSION CASE COVER, FRONT AT TRANSMISSION CASE
72
TRANSMISSION CASE. GEAR CASE COVER, REAR
73
PLUG
74
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
75
GASKET , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
76
SHAFT FOR TACHOMETER DRIVE
77
GESCHWINDIGKEITSMESSER-ANTRIEBSRAD 16 ZAHNE
80
GASKET FOR TRANSMISSION HOUSING COVER, REAR
82
LOCKING PLATE FOR TRANSMISSION CASE COVER, FRONT AT TRANSMISSION CASE
83
COLLAR SCREW. SCREW CASE COVER TO TRANSMISSION
85
THREE-ARM FLANGE. THREE-WAY FLANGE, 90-MM HOLE CIRCLE ON MAIN SHAFT, Replaced By: A1112620045
86
GROOVED NUT
87
LOCK
88
SCREW PLUG , Replaced By: A0009972632
999
ROLLER ASSEMBLY
999
THRUST WASHER , Replaced By: A1202621362
999
THRUST WASHER 4.50 MM
999
THRUST WASHER , Replaced By: A1202621562
999
THRUST WASHER , NOT USED
999
THRUST WASHER , Replaced By: A1202621862
999
THRUST WASHER AS REQUIRED
999
THRUST WASHER , Replaced By: A1202622062
999
THRUST WASHER AS REQUIRED
999
SPACER WASHER INTERMEDIATE BEARING
999
SPACER WASHER , Replaced By: A6022630252
999
SPACER WASHER , Replaced By: A6022630452
999
SPACER WASHER 0.20 MM
999
SPACER WASHER AS REQUIRED 0.1 MM
999
SPACER WASHER 0.2 MM
999
SPACER WASHER 0.3 MM
999
SPACER WASHER 0.30 MM
999
SNAP RING AS REQUIRED 1.9 MM
999
SNAP RING , Replaced By: A1369940935
999
SNAP RING 2.05 MM
999
AUSGLEICHSCHEIBE, 0,4-MM STARK WAHLWEISE FUR ANTRIEBSWELLE AN GETRIEBEGEHAUSE
999
AUSGLEICHSCHEIBE, 0,5-MM STARK WAHLWEISE FUR ANTRIEBSWELLE AN GETRIEBEGEHAUSE
999
AUSGLEICHSCHEIBE, 0,6-MM. SPACER WASHER, 0.6-MM THICK OPTIONAL DRIVE SHAFT TO TRANSMISSION CASE
999
AUSGLEICHSCHEIBE, 0,7-MM. SPACER WASHER, 0.7-MM THICK OPTIONAL DRIVE SHAFT TO TRANSMISSION CASE
999
THRUST WASHER 3.90 MM
999
THRUST WASHER 4.00 MM
999
THRUST WASHER 4.10 MM
999
THRUST WASHER AS REQUIRED 4.20 MM
999
THRUST WASHER AS REQUIRED 4.30 MM
999
THRUST WASHER 4.40 MM
999
THRUST WASHER 4.50 MM
999
SYNCHRONIZING RING FOR FIRST GEAR
999
ABSTANDHULSE AB GETRIEBE-NR. 55 00739
