Поз.
Артикул
Описание
1
DRIVER'S DOOR, SHELL, LEFT WITH HINGE AND MOUNTING HOLES FOR MOUNTING OF ORNAMENTAL BAR
2
DRIVER'S DOOR, SHELL, RIGHT WITH HINGE AND MOUNTING HOLES FOR MOUNTING OF ORNAMENTAL BAR
5
HINGE, TOP FOR LEFT DRIVER'S DOOR
6
HINGE, TOP FOR RIGHT DRIVER'S DOOR
7
HINGE BOLT
8
SPACER, TOP 0.8 MM THICK OPTIONAL
9
HINGE, BOTTOM FOR LEFT DRIVER'S DOOR
10
HINGE, BOTTOM FOR RIGHT DRIVER'S DOOR
11
HINGE BOLT
12
SPACER, BOTTOM 0.8-MM THICK OPTIONAL
17
PIN-TYPE LOCK WITH REMOTE CONTROL, DESIGN LEFT FOR LEFT DRIVER'S DOOR
18
PIN-TYPE LOCK WITH REMOTE CONTROL, DESIGN RIGHT FOR RIGHT DRIVER'S DOOR
19
LOCK WITHOUT REMOTE CONTROL, DESIGN LEFT FOR LEFT DRIVER'S DOOR
20
LOCK WITHOUT REMOTE CONTROL, DESIGN RIGHT FOR RIGHT DRIVER'S DOOR
21
REMOTE CONTROL FOR LEFT DRIVER'S DOOR
22
REMOTE CONTROL FOR RIGHT DRIVER'S DOOR
23
ABDECKKAPPE LINKS UBER SCHLOSS AN FONDTUR
24
ABDECKKAPPE RECHTS. COVER CAP, RIGHT OVER LOCK AT DRIVER'S DOOR
30
DOOR HANDLE, LOCKABLE, CHROM.-PLATED FOR LEFT DRIVER'S DOOR WHEN ORDERING STATE LOCK NO.
31
DOOR HANDLE, NOT LOCKABLE, CHROM.-PLATED FOR RIGHT DRIVER'S DOOR
32
ROSETTE LINKS FUR TURGRIFF AN FAHRERTUR
33
ROSETTE RECHTS. ESCUTCHEON, RIGHT FOR RIGHT DRIVER'S DOOR FOR DOOR HANDLE, LOCKABLE, AT DRIVER'S DOOR
34
GUMMIUNTERLAGE FUR TURGRIFF SIEHE TAFEL 94 BILD NR. 35
35
SCHEIBE WAHLWEISE FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
36
INNENDRUCKER
37
ROSETTE VERCHROMT FUR INNENDRUCKER
38
ABSTANDROHR FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
39
SCHEIBE WAHLWEISE FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
40
AUFSTECKBUCHSE ZWISCHEN SPEZIALSCHRAUBE UND TURGRIFF
41
SICHERUNGSSCHRAUBE. LOCKING SCREW SPECIAL SCREW FOR DOOR HANDLE
42
SCHLIESSOSE
43
UNTERLEGPLATTE WAHLWEISE FUR SCHLIESSOSE AN KASTENSAULE
44
COVER PLAT, CHROM.-PLATED ON CATCH OPENING, REAR
45
DOOR BRAKE IN FRONT WALL
46
DOOR RETAINING STRAP
47
GUMMIPUFFER. RUBBER BUFFER FOR DOOR RETAINING STRAP
48
PLATTE FUR TURHALTER
49
SPRING RELEASE SPRING AT DOOR, FRONT
50
TURZIEHGRIFF VERCHROMT. TURZIEHGRIFF
57
WINDOW RUN, REAR, LEFT
61
FENSTERPRESSER AUSSEN. WINDOW PRESSER, EXTERIOR
62
FENSTERPRESSER INNEN LINKS
63
FENSTERPRESSER INNEN. WINDOW PRESSER, INTERIOR, RIGHT
64
JOINT WINDOW LIFTER, LEFT FOR CRANKING DEVICE
65
JOINT WINDOW LIFTER, RIGHT FOR CRANKING DEVICE
68
KURBEL VERCHROMT. KURBEL FUR FENSTER SIEHE AUCH TAFEL 94 BILD NR. 24
69
BOLZEN. CYLINDRICAL PIN FOR WINDOW CRANK DELIVERED TOGETHER WITH CRANK, NOT MOUNTED
70
ROSETTE VERCHROMT. ESCUTCHEON WITH PRESSURE SPRING AND SLEEVE TO WINDOW CRANK
75
CRANK WINDOW, LEFT
76
CRANK WINDOW, RIGHT
77
WINDOW LIFTING RAIL, LEFT
78
WINDOW LIFTING
79
ABDICHTUNGSGUMMI 925-MM. GUMMIPROFIL 545 MM LANG BEI BESTELLUNG LANGE ANGEBEN
80
GLASSPANE, LEFT FOR DRIVER'S DOOR, 4.5 MM THICK
81
GLASSPANE, RIGHT FOR DRIVER'S DOOR, 4.5 MM THICK
82
EINGLASUNGSGUMMI 850-MM LANG BEI BESTELLUNG LANGE ANGEBEN
83
WINDOW FRAME, CHROM. -PLATED FOR DRIVER'S DOOR
84
FUHRUNGSBACKEN. GUIDE JAW
87
GUIDE JAW
110
WINDOW MOULDING, LEFT FOR DRIVER'S DOOR WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
111
WINDOW MOULDING, RIGHT FOR DRIVER'S DOOR WHEN ORDERING STATE BODY NO. AND SUBMIT SAMPLE
112
COVER PLATE, LEFT AT WINDOW CHUTE, TOP DELIVERED WITHOUT CHROM.-PLATING, MUST BE FITTED
113
COVER PLATE, RIGHT AT WINDOW CHUTE, TOP DELIVERED WITHOUT CHROM.-PLATING, MUST BE FITTED
120
DEFLECTOR PANE, LEFT
121
DEFLECTOR PANE, RIGHT
122
SUPPORTING FRAME, LEFT, CHROM. -PLATED FOR DEFLECTOR PANE
123
SUPPORTING FRAME, RIGHT, CHROM. -PLATED FOR DEFLECTOR PANE
127
DEFLECTOR PANE, LEFT
128
DEFLECTOR PANE, RIGHT
129
WINDOW FRAME, LEFT, CHROM.-PLATED
130
WINDOW FRAME, RIGHT, CHROM. -PLATED
131
GUMMIPROFIL 700 MM LANG BEI BESTELLUNG LANGE ANGEBEN
132
ZWISCHENLAGE GUMMI SCHWARZ ZWISCHEN VORREIBER LINKS UND RECHTS
133
GLASSPANE, LEFT FOR DEFLECTOR PANE 4.5 MM THICK
134
GLASSPANE, RIGHT FOR DEFLECTOR PANE 4.5 MM THICK
135
VORREIBER LINKS. LATCH, LEFT FOR DEFLECTOR PANE CHROM.-PLATED
136
VORREIBER RECHTS FUR DREHFENSTER
137
ACHSE FUR VORREIBER AN FENSTERRAHMEN
138
SPRING WASHER TURN BUCKLE AT WINDOW
139
WASSERRINNE LINKS FUR DREHFENSTER
140
WASSERRINNE RECHTS. GUTTER, RIGHT FOR DEFLECTOR WINDOW
141
RUBBER FRAME, LEFT FOR DEFLECTOR PANE
142
RUBBER FRAME, RIGHT FOR DEFLECTOR PANE
143
ABDICHTUNGSGUMMI 290-MM LANG BEI BESTELLUNG LANGE ANGEBEN
144
MOUNTING, BOTTOM, LEFT. LAGER UNTEN LINKS
145
MOUNTING, BOTTOM, RIGHT. LAGER UNTEN RECHTS
146
LAGERTEIL OBEN
147
ARRETIERWINKEL LINKS
148
ARRETIERWINKEL RECHTS
149
WASHER
150
WINDOW RUN PROFIL-NR. 000 985 05 30
999
PAD, 0.5 MM THICK. ZWISCHENLAGE 0,5 X 13 X 50
999
PAD, 0.3 MM THICK FOR WINDOW LIFTER AT CRANK OPERATED WINDOW
999
SPACER, TOP 1.5 MM THICK OPTIONAL
999
SPACER, BOTTOM 1.5-MM THICK OPTIONAL
999
UNTERLEGPLATTE WAHLWEISE FUR SCHLIESSOSE AN KASTENSAULE
999
SCHEIBE WAHLWEISE FUR TURGRIFF UNVERSCHLIESSBAR AN FONDTUR
999
SCHEIBE. WASHER FOR DOOR HANDLE, NOT LOCKABLE, AT REAR DOOR
999
FILZSTREIFEN 270 MM LANG. STRIP
999
HINGE BOLT. SCHARNIERBOLZEN 8,2 O 65-MM LG. FUR SCHARNIER UNTEN FUR REPARATURAUSFUHRUNG
999
HINGE BOLT FOR HINGE, TOP FOR REPAIR DESIGN
999
SCHLUSSEL. KEY, CHROM.-PLATED SAME LOCK LIKE DOOR HANDLE AND TANK ROOM LOCK
