Поз.
Артикул
Описание
85
CABLE HARNESS ELECTRONIC AIR POLLUTION CONTROL
85
CABLE HARNESS ELECTRONIC AIR POLLUTION CONTROL
86
CABLE HARNESS AIR POLLUTION CONTROL
89
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
90
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
91
PLUG
91
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
92
COVERTO 011 545 10 28
93
ROUND PIN BUSHING4 MM2
96
PLUG HOUSING MAIN CABLE HARNESS
98
COVERTO 011 545 10 28
110
PIN BUSHING HOUSING 4-POLE
110
PLUG , Replaced By: A0055451328
110
PLUG , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0065458028, +006A0015453726, +001A0095453028
111
COVER
120
PLUG , Replaced By: A0095452628, +012A0035452626, +001A0095452428
120
PIN BUSHING HOUSING 12-POLE
121
COVERTO 009 545 26 28
122
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
122
ROUND PIN BUSHING , Replaced By: A0035452626
124
PLUG , Replaced By: A0095454028, +002A0015453826, +001A0095454128
124
PLUG HOUSING
125
PLUG SOCKET , Replaced By: A0015453526
125
PIN BUSHING , Replaced By: A0015454426
125
ROUND PIN BUSHING , Replaced By: A0035452626
125
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
125
ROUND PIN BUSHING4 MM2
128
PIN BUSHING HOUSING ELECTRIC CHANGE-OVER VALVE
129
COVERTO 008 545 08 28,008 545 09 28
130
ROUND PIN BUSHING4 MM2
131
PLUG HOUSING BIPOLAR
132
PLUG PIN , 107.042 L.H.D. A 005252 107.042 R.H.D. A 007245 123. L.H.D. A 154544,F 019237 123. R.H.D. A 118487,F 020926
132
PLUG PIN , Replaced By: A0135457928
156
PIN BUSHING HOUSING CONTROL UNIT
157
COVERTO 010 545 00 28
158
ROUND PIN BUSHING2.5 MM2
158
PIN BUSHING , Replaced By: A0025459926
160
GROMMET
161
GROMMET ELECTRIC CABLE THRU FIRE WALL
161
GROMMET
210
CLAMP BRAKE HOSE
211
BRACKET LINE MOUNTING 11 MM
211
CLAMP , Replaced By: A0004760436
212
PROTECTIVE PLATE
213
WASHER , Replaced By: N009021006208
213
WASHER COMPRESSED AIR LINE TO BRACKET
214
SHEET METAL SCREW VALVE TO WINDOW SILL
215
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
216
NUT CYLINDER TO BRACKET TO0002902112
216
NUT BATTERY MOUNTING
217
SCREW , Replaced By: N304017006034
217
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
GROMMET , Replaced By: A0005460937
999
GROMMET OVER STARTING CABLE AND MAIN CABLE HARNESS
999
GROMMET
999
INSULATING HOSE
999
RELAY , 107.042 011569 ALSO INSTALLED ON 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 107.045 009132 ALSO INSTALLED ON 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 046 009987 ALSO INSTALLED ON 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
999
PART NAME MISSING. PLUG , Replaced By: A0125450328, +014A0015453826, +001A0095455728
999
PLUG
999
PLUG
999
LOCK
999
POSITIVE CABLE
999
CABLE HARNESS
999
CAP DIAGNOSIS BOX
999
CABLE HARNESS
999
CABLE HARNESS
999
ELECTRIC CABLE
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS
