Поз.
Артикул
Описание
459
TRANSMISSION CASE
460
BRACKET ,024695
461
SCREW PLUG
462
SEAL RING
464
SEAL RING
465
SEAL RING
466
HOUSING
467
SPRING
468
SCREW DISTRIBUTOR TO CAB
468
SCREW , Replaced By: N000933006151
469
SPRING WASHER LICENSE PLATE TO BRACKET
470
SWITCH
471
SEAL RING
472
SPRING WASHER ALTERNATOR CONNECTION D+
473
SCREW PLUG SOCKET
474
LEVER
475
CONTROL SHAFT , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
476
BUSHING , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
477
SPACER TUBE , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
478
SEAL RING , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
479
SCREW PLUG SOCKET TO COVERING
480
WASHER COVERING TO CYCLONE AIR TRAP
480
WASHER , Replaced By: N009021004207
481
SPRING WASHER ALTERNATOR CONNECTION D+
482
DETENT
483
SCREW COVERING
484
SPRING WASHER LICENSE PLATE TO BRACKET
485
LEVER , NO LONGER AVAILABLE
487
VALVE , Replaced By: A1092701089, +001A1152771758
487
VALVE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366
488
VALVE , Replaced By: A1092701189, +001A1152771758
488
VALVE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366
489
O-RING , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366
489
SEAL RING , Replaced By: A0169973448
490
SPRING
491
PIN AS REQUIRED 22 MM
493
PIN
494
LEVER
495
PIN
496
SPRING
497
SCREW
498
NUT
499
PISTON
501
PIN
502
SNAP RING
503
SPRING
504
COVER
505
SEAL RING
506
SNAP RING
507
LEVER
508
WASHER
509
LOCK PLATE
510
LEVER
511
BRAKE BAND
511
BRAKE BAND , Replaced By: A1162701762
512
SPRING , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
513
SPRING , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
514
PISTON , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
522
SEAL RING
523
SNAP RING
527
COVER
528
SNAP RING
531
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
531
SPRING WASHER , Replaced By: N000137008212
532
SCREW VALVE TO BRACKET
533
GASKET , Replaced By: A1152773380
533
GASKET
597
PISTON
600
VACUUM BOX
601
PIN 39.65 MM
602
SPRING ,020054
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228 UP TO CHASSIS: 000,002,010 111659 015 143499 100,102,103,110,112 295222 115 150669, Replaced By: A1152604539, +001A1152670114, +001A1152680172
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228 UP TO CHASSIS: 000,002,010 117631 015 154063 100,102,103,110,112 315098 115 161611, Replaced By: A1152604439, +001A1152670114, +001A1152680172
999
SHIFT LEVER , FROM CHASSIS: LESS POWER STEERING 000,002,010 20/60 088430 015 20/60 104519 100,102,103,110,112 20/60 225573 115 20/60 111936 FROM CHASSIS: WITH POWER STEERING 000,002,010 20/60 088396 015 20/60 104453 100,102,103,110,112 20/60 225471 115 20/60 111824 FROM CHASSIS: LESS POWER STEERING 000,002,010 22/62 087647 015 22/62 103137 100,102,103,110,112 22/62 222276 115 22/62 110305 FROM CHASSIS: WITH POWER STEERING 000,002,010 22/62 086764 015 22/62 101812 100,102,103,110,112 22/62 220495 115 22/62 109110 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227, Replaced By: A1152604539, +001A1152670114, +001A1152680550, +001A1152680172, +001N007346005000
999
SHIFT LEVER , FROM CHASSIS: LESS POWER STEERING 000,002,010 10/50 085059 015 10/50 099480 100,102,103,110,112 10/50 216012 115 10/50 106668 FROM CHASSIS: WITH POWER STEERING 000,002,010 10/50 086622 015 10/50 101629 100,102,103,110,112 10/50 220100 115 10/50 108872 FROM CHASSIS: LESS POWER STEERING 000,002,010 12/52 086675 015 12/52 101862 100,102,103,110,112 12/52 220490 115 12/52 109122 FROM CHASSIS: WITH POWER STEERING 000,002,010 12/52 083151 015 12/52 097115 100,102,103,110,112 12/52 211906 115 12/52 104334 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227, Replaced By: A1152604439, +001A1152680550, +001A1152680172, +001N007346005000
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 056142 015 060262 100,102,103,110,112 139361 115 065086 UP TO CHASSIS: LESS POWER STEERING 000,002,010 12/52 086674 015 12/52 101861 100,102,103,110,112 12/52 220489 115 12/52 109121 UP TO CHASSIS: WITH POWER STEERING 000,002,010 12/52 083150 015 12/52 097114 100,102,103,110,112 12/52 211905 115 12/52 104333, Replaced By: A1152604439, +001A1152681442, +001A1152680172
999
GASKET KIT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
LINE VACUUM
999
LINE , Replaced By: A1232700396
999
LINE LEFT
999
LINE , Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
999
GASKET KIT , Replaced By: A1142703301
999
FILTER RANGE OF DELIVERY COMPRISES:, 021,023 FROM TRANSMISSION 006751-009935, FROM TRANSMISSION 023011
999
PLUG , 014 FROM TRANSMISSION 000904, 015 FROM TRANSMISSION 006447
999
GROMMET OIL LINE TO CONVERTER HOUSING
999
SPRING , NO LONGER AVAILABLE 015 FROM TRANSMISSION 005208
999
SPRING OUTSIDE, NO LONGER AVAILABLE
999
SPRING
999
SPRING , NO LONGER AVAILABLE
999
SPRING
999
PIN REPAIR SIZE 5.5 MM, NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
999
BUSHING
999
PIN AS REQUIRED 82 MM
999
PIN AS REQUIRED 81 MM, 015 FROM TRANSMISSION 002756
999
PIN 37 MM AS REQUIRED
999
PIN AS REQUIRED 36 MM
999
INSULATING RING
999
INSULATING RING , NO LONGER AVAILABLE
999
GUARD PLATE , 015 FROM TRANSMISSION 005208
999
BOOT , Replaced By: A1152720692
999
SPACER WASHER AS REQUIRED 0.1 MM
999
SPACER WASHER , Replaced By: A1122720652
999
SPACER WASHER 0.15 MM
999
SPACER WASHER 0.20 MM
999
SPACER WASHER , Replaced By: A1122720052
999
SPACER WASHER AS REQUIRED 0.7 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
BUSHING
999
SPACER WASHER 0.5 MM
999
SPACER WASHER , Replaced By: A1122710052
999
SPACER WASHER0.1 MM, NO LONGER AVAILABLE
999
GASKET KIT
999
GASKET KIT , Replaced By: A1122701800
999
CLAMP , NO LONGER AVAILABLE
999
BRACKET
999
SCREW , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
PIN 26 MM,AS REQUIRED
999
PIN 25 MM,AS REQUIRED
999
PIN AS REQUIRED 24 MM
999
PIN AS REQUIRED 23 MM
999
OUTER DISC , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
OUTER DISC , 017664 EXCEPT FOR 015709-017194
999
OUTER DISC 2.0 MM
999
OUTER DISC
999
OUTER DISC
999
BOOT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
BOOT
999
BRACKET
999
GASKET
999
BRACKET
999
GASKET , Replaced By: A1092710180
999
PLANETARY CARRIER ,011777, Replaced By: A1152702643, +001A1152705425, +001A0049814110, +001A0029942641
999
LINE
999
GEAR INDICATOR , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
GEAR INDICATOR , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
SLOTTED GATE , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
SHIFTING TUBE , 016 FROM CHASSIS 054181, 018, 019 FROM CHASSIS 059142
999
SHIFTING TUBE , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326 016 UP TO CHASSIS 054180, 018, 019 UP TO CHASSIS 059141, Replaced By: A1092601682, +001A1099900338, +001N000934005004
999
SHIFTING TUBE , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326 016 UP TO CHASSIS 054180, 018, 019 UP TO CHASSIS 059141, Replaced By: A1092601382, +001A1099900238, +001N000934005004
999
BEARING BRACKET
999
AUTOMATIC TRANSMISSION , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
LINE , Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
999
LINE , FROM CHASSIS 036081, Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
999
VALVE BODY ASSEMBLY TO 108 270 06 07, NO LONGER AVAILABLE
999
OIL FILLER PIPE , FROM CHASSIS 003545
999
VALVE BODY ASSEMBLY , WITH 108 270 09 01: UP TO TRANSMISSION 033564 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE BODY ASSEMBLY TO 108 270 04 07, NO LONGER AVAILABLE
999
OIL FILLER PIPE
999
VALVE BODY ASSEMBLY , Replaced By: A1082700607
999
OIL FILLER PIPE , 012 FROM CHASSIS 019536, 014 FROM CHASSIS 016088
999
VALVE BODY ASSEMBLY TO 108 270 00 07, NO LONGER AVAILABLE
999
VALVE BODY ASSEMBLY , Replaced By: A1082700407
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 007281-056141 015 004404-060261 100,102,103,110,112 017471-139360 115 007979-065085, Replaced By: A1152604439, +001A1152670114, +001A1152680550, +001A1152680172, +001A1152691242, +001N007346005000
999
BOOT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTALLED ON SEE FOOTN.37 AND FOOTN.49
999
BEARING BRACKET , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
SHIFTING ROD , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
LEVER , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
SHIFTING ROD
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY
999
SPACER WASHER AS REQUIRED 0.2 MM, 015 FROM TRANSMISSION 005208
999
LOCK ,020254
999
OUTER DISC , Replaced By: A1092721826
999
HOSE , FROM CHASSIS: 010 043070 015 042951 110 101088 115 046326
999
HOSE FROM TRANSMISSION TO OIL COOLER
999
SEAL RING
999
SCREW BRACKET TO SIDE MEMBER,K 168169
999
SEAL RING ,031534
999
NEEDLE BEARING ,043589
999
SEAL RING
999
NEEDLE BEARING , Replaced By: A0059818110
999
NEEDLE BEARING , Replaced By: A0059818110
999
LOCK ,022986
999
NEEDLE BEARING ,011777
999
NUT RETAINER HEATER CASE TO FIRE WALL
999
NEEDLE
999
SOLENOID
999
SOLENOID , Replaced By: A0003040590
999
SOLENOID
999
BALL SOCKET , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
BALL SOCKET , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTNOTE 3, 018 UP TO CHASSIS
999
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT REPAIR SIZE
999
THREADED INSERT
999
NUT BATTERY CABLE
999
NUT
999
NUT BATTERY MOUNTING
999
SCREW , Replaced By: N304017010055
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW PIPE CLAMP
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW PUMP TO BRACKET
999
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
