Поз.
Артикул
Описание
14
SCREW , UP TO CHASSIS: 000,002,010 083223 015 097126 100,102,103,110,112 212123 115 104333
20
DOOR LOCK RIGHT
24
PULL ROD LEFT, 016 UP TO CHASSIS 081847, 018 UP TO CHASSIS 087991, 057,058 UP TO CHASSIS 004038 012,10/50,20/60 FROM CHASSIS 068090, 12/52,22/62 FROM CHASSIS 067638, 015 FROM CHASSIS 002715
29
LOCK PULL ROD TO DOOR LOCK
33
CLIP
33
CLIP , Replaced By: A0069886378
41
SPRING WASHER SHIFTING CYLINDER TO YOKE
45
SPACER RING
49
NUT RETAINER
52
NUT RETAINER , Replaced By: A3229900091
52
NUT RETAINER , Replaced By: A0009907191
55
EDGING RIGHT
59
LOCKING EYE RIGHT, FROM CHASSIS: 010 031987 ALSO INSTALLED ON: 026127-026384 110 071329 ALSO INSTALLED ON: 057116-057347
64
PLATE , UP TO CHASSIS: 000,002,010 032736 EXCEPT FOR 026127-026384 015 030665 EXCEPT FOR 023687-023770 100,102,103,110,112 073207 EXCEPT FOR 057116-057347 115 033411 EXCEPT FOR 026238-026496
67
PLATE
71
INTERIOR HANDLE ASSEMBLY RIGHT
75
NUT RETAINER , Replaced By: A3229900091
75
NUT RETAINER , Replaced By: A0009907191
78
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
81
ESCUTCHEON RIGHT
84
SEAL
88
INSERT RIGHT
91
KNOB , 023 116973 033 048510 123 097280 130 120563
95
DOOR CHECK
98
ROLLER , Replaced By: A3147230068
98
ROLLER
102
PIN
104
WASHER DOOR CHECK TO FRONT PANEL PILLAR
109
LOCK , Replaced By: N912001006001
114
DOOR HANDLE OUTSIDE RIGHT, 012 FROM CHASSIS 044562, 014 FROM CHASSIS 035569, 015 FROM CHASSIS 002425
117
PIN
120
DISC SPRING
124
PAD , 012 FROM CHASSIS 044562,014 FROM CHASSIS 035569, Replaced By: A1077661005
127
PAD REAR RIGHT, 012 FROM CHASSIS 044562, 014 FROM CHASSIS 035569, 015 FROM CHASSIS 002425
133
GLASS PANE
140
SEAL RIGHT
149
WINDOW STAYBAR RIGHT, 016 UP TO CHASSIS 032902, 018 UP TO CHASSIS 033678, 019 UP TO CHASSIS 040075
153
WINDOW RUN RIGHT
156
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
161
SEALING SECTION 2240 MM, ORDER BY THE METER
163
CLIP
167
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
167
SEAL , Replaced By: A1167250198
167
SEAL , Replaced By: A1157251298
172
WINDOW REGULATOR RIGHT, FROM CHASSIS: 010 046471 110 111771
174
SPRING
174
SPRING , Replaced By: A0007680734
203
RUBBER MOULDING
211
PAD , Replaced By: A1087680095
215
WASHER
221
SEALING RAIL 2200 MM
224
CLIP
229
CLIP , Replaced By: A1159880078
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK
999
LOCK , Replaced By: N912001006001
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW PUMP TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021004207
999
SCREW
999
SCREW
999
SCREW
999
SCREW
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW ,K 062140, Replaced By: N007985006580
999
SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW DOOR LINING TO REAR DOORS
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW
999
TOOTHED WASHER MASKED STOP LAMP
999
TOOTHED WASHER CABLE TO FUSE BOX
999
NUT BALL PIVOT TO LEVER
999
SCREW , Replaced By: N304017006034
999
SCREW COVER PLATE TO BRACKET
999
SCREW
999
WASHER
999
SCREW
999
COVERING , STATE COLOR NUMBER WHEN ORDERING
999
CRANK
999
COVERING , Replaced By: A1237600120
999
REPAIR KIT
999
SEAL INSIDE 4000 MM
999
MOLDED PIECE , Replaced By: A0029888378
999
COVERING REAR DOOR INTERIOR PLATE
999
SHELL , NO LONGER AVAILABLE
999
CLIP , 003030
999
CLIP , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 000,002,010 092933 015 112061 100,102,103,110,112 238351 115 118982, Replaced By: A1159881778
999
CLIP
999
INTERIOR HANDLE ASSEMBLY RIGHT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
999
INTERIOR HANDLE ASSEMBLY LEFT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
999
INTERIOR HANDLE ASSEMBLY RIGHT, UP TO CHASSIS: 000,002,010 083018 EXCEPT FOR 055487-055613 015 096864 EXCEPT FOR 059434-059645 UP TO CHASSIS: 100,102,103,110,112 211690 EXCEPT FOR 137775-138117 115 104054 EXCEPT FOR 064365-064536
999
INTERIOR HANDLE ASSEMBLY LEFT, UP TO CHASSIS: 000,002,010 083018 EXCEPT FOR 055487-055613 015 096864 EXCEPT FOR 059434-059645 UP TO CHASSIS: 100,102,103,110,112 211690 EXCEPT FOR 137775-138117 115 104054 EXCEPT FOR 064365-064536
999
DOOR LOCK LEFT,LESS DOOR INNER LOCK
999
PLATE 1.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
PLATE 0.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
LOCKING EYE LEFT
999
REPAIR KIT , Replaced By: A1237200114
999
SLIDE , Replaced By: A1155860072
999
WINDOW RETAINING RAIL
999
WASHER , Replaced By: A1087680113
999
GARNISH MOULDING TOP RIGHT
999
GARNISH MOULDING TOP LEFT
999
PAD RIGHT, 012 UP TO CHASSIS 054877 EXCEPT FOR, SEE GROUP 72 FOOTNOTE 12, 014 UP TO CHASSIS 043155 EXCEPT FOR, SEE GROUP 72 FOOTNOTE 13, 015 UP TO CHASSIS 002580
999
PAD LEFT, 019 UP TO CHASSIS 010646
999
GARNISH MOULDING AT DOOR EDGE,RIGHT
999
GARNISH MOULDING AT DOOR EDGE,LEFT
999
GLASS PANE CRANK OPERATED WINDOW, RIGHT
999
GARNISH MOULDING AT WINDOW MOULDING,LEFT
999
GLASS PANE CRANK OPERATED WINDOW,LEFT
999
PANELLING RIGHT AT DOOR EDGE, STATE COLOR AND CHASSIS NO.WHEN ORDERING
999
PANELLING LEFT AT DOOR EDGE, STATE COLOR AND CHASSIS NO.WHEN ORDERING
999
GARNISH MOULDING BEADED EDGE,RIGHT, 019 UP TO CHASSIS 010646
999
GARNISH MOULDING AT BEADED EDGE,LEFT, 019 FROM CHASSIS 010647
999
GARNISH MOULDING , Replaced By: A1097301880
999
GARNISH MOULDING , Replaced By: A1097301780
999
WELT , Replaced By: A1097301880
999
WELT , Replaced By: A1097301780
999
DOOR LOCKING DEVICE RIGHT
999
WELT RIGHT, 019 UP TO CHASSIS 010646
999
WEATHERSTRIP RIGHT
999
WINDOW REGULATOR RAIL
999
DOOR LOCKING DEVICE
999
WELT LEFT, 019 UP TO CHASSIS 010646
999
WEATHERSTRIP LEFT
999
WINDOW REGULATOR RAIL LEFT
999
EDGE GUARD SECTION RIGHT
999
EDGE GUARD SECTION LEFT
999
EDGE GUARD SECTION , Replaced By: A1097300497
999
WEATHERSTRIP , Replaced By: A1097300678
999
EDGE GUARD SECTION , Replaced By: A1097300397
999
WEATHERSTRIP , Replaced By: A1097300578
999
WASHER
999
CLIP , Replaced By: A1159880078
999
PAD , Replaced By: A1237600020
999
PAD REAR LEFT, 012 FROM CHASSIS 044562,014 FROM CHASSIS 035569
999
ESCUTCHEON LEFT
999
INSERT LEFT
999
DOOR HANDLE OUTSIDE LEFT, 012 FROM CHASSIS 044562,014 FROM CHASSIS 035569
999
INTERIOR HANDLE ASSEMBLY LEFT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990
999
CRANK , FROM CHASSIS: 000,002,010 046471 015 047683 100,102,110 111771 103,112 112413 115 051671 005,017,105,107,108,117,119 000001, Replaced By: A1237600102
999
PAD , Replaced By: A1087380497
999
PAD , Replaced By: A1087380397
999
GARNISH MOULDING FRONT LEFT
999
SEAL , Replaced By: A1087380180
999
SEAL CENTRAL PILLAR,LEFT
999
SEAL LEFT
999
WINDOW REGULATOR LEFT, FROM CHASSIS: 000,002,010 046471 015 047683 100,102,110 111771 103,112 112413 115 051671 005,017,105,107,108,117,119 000001
999
WINDOW REGULATOR , UP TO CHASSIS: 000,002,010 046470 015 047682 100,102,110 111770 103,112 112412 115 051670, Replaced By: A1087350402, +001A1237600102, +001A1237600020, +001A1087680113
999
GLASS PANE LEFT
999
WINDOW REGULATOR , UP TO CHASSIS: 000,002,010 046470 015 047682 100,102,110 111770 103,112 112412 115 051670, Replaced By: A1087350302, +001A1237600102, +001A1237600020, +001A1087680113
999
PANELLING RIGHT, STATE COLOR AND CHASSIS NUMBERS WHEN ORDERING
999
PANELLING LEFT, STATE COLOR AND CHASSIS NO.WHEN ORDERING
999
DOOR SHELL RIGHT
999
DOOR SHELL LEFT,040076
999
DOOR SHELL , FROM CHASSIS 019325-040075, Replaced By: A1087303005, +001A1087300719
999
DOOR SHELL , FROM CHASSIS 019325-040075, Replaced By: A1087302905, +001A1087300719
999
PANELLING TOP RIGHT
999
PANELLING TOP LEFT
999
DOOR SHELL ,019325-040075, Replaced By: A1087303005, +001A1087300719
999
DOOR SHELL , FROM CHASSIS 019325-040075, Replaced By: A1087302905, +001A1087300719
999
PANELLING FRONT LEFT
999
DOOR SHELL , UP TO CHASSIS 019325, Replaced By: A1087303005, +001A1087300819, +001A1157600261
999
DOOR SHELL ,019325, Replaced By: A1087302905, +001A1087300719, +001A1157600161
999
PULL ROD RIGHT, 067,068 FROM CHASSIS 002675
999
WINDOW STAYBAR RIGHT, 016 FROM CHASSIS 032903, 018 FROM CHASSIS 033679, 019 FROM CHASSIS 040076
999
WINDOW STAYBAR LEFT, 016 FROM CHASSIS 032903, 018 FROM CHASSIS 033679, 019 FROM CHASSIS 040076
999
PULL ROD REAR DOOR
999
WINDOW STAYBAR LEFT, 016 UP TO CHASSIS 032902,018 UP TO CHASSIS 033678,019 UP TO CHASSIS 040076
999
WINDOW RUN LEFT
999
EDGING
999
PLATE 2.0 MM 2.0 MM, TO BE ADAPTED DURING ASSEMBLY
999
ADHESIVE TAPE , Replaced By: A0019875646
999
CLIP , Replaced By: A0069886378
999
CLIP , Replaced By: A0039884178
999
CLIP , Replaced By: A0039884178
999
CLIP SEAL TO REAR DOOR
999
LOCK , Replaced By: A1155860072
999
NUT RETAINER , Replaced By: A0009908391
999
SCREW
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
FASTENER BUTTON
999
WASHER , FROM CHASSIS:113.043 002980 113.044 000001
999
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
SPRING , Replaced By: A0007680905
