Поз.
Артикул
Описание
5
ALTERNATOR12V/120A, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR12V/120A, VALEO
5
ALTERNATOR12V/90A, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
PULLEYTO A 009 154 44 02, BOSCH
8
PULLEY. BELT PULLEY BOSCH ALTERNATOR
11
NUT PULLEY TO ALTERNATOR
14
SCREW. BOLT FRONT BALL BEARING FASTENING M4X22.6 MM,BOSCH
20
BALL BEARING DRIVE END BEARING TO A 011 154 94 02, 9202
23
BALL BEARING REAR
23
BALL BEARING SLIP RING SIDE TO A 011 154 94 02, 92 02, Replaced By: A0089818625
26
RINGBOSCH
29
BOLT. SCREW
32
SCREW
35
SCREW RECTIFIER TO A 011 154 94 02, 92 02
41
REGULATOR AND CUT-OUTTO A 012 154 09 12, A 012 154 03 02
41
REGULATOR AND CUT-OUTVALEO, TO A 011 154 66 02
47
SCREW REGULATOR AND CUT-OUT
50
COVERVALEO
53
COVERTO A 013 154 13 02,15 02,17 02, 203 A 237173 203 F 177684 203 R 028781 210 B 438526 210 X 065664 901-904 R337626 638 246705 SEE CHASSIS PARTS KIT FOR "FROM VIN" NO.
59
NUT COVER TO A 011 154 94 02, 92 02
62
NUT BOOT M8,BOSCH
65
SCREW , Replaced By: N304014010008
65
HEXAGON HEAD BOLT. SCREW RETAINING PLATE TO SHIFTER COVER,4 411810
68
SLEEVE ALTERNATOR TO SUPPORT
80
TS ANNULAR BALL BEARING. GROOVED BALL BEARING (PARTS KIT) TO A 012 154 20 02, 2202,2402,5402
83
TS FASTENING PARTS KIT. ATTACHMENT (PARTS KIT) TO A 0121542002,2202,2402,5402, 203 A 237173 203 F 177684 203 R 028781 210 B 438526 210 X 065664 901-904 R337626 638 246705 SEE CHASSIS PARTS KIT FOR "FROM VIN" NO.
