Поз.
Артикул
Описание
5
HOUSING REAR AXLE CENTER ASSEMBLY W/O FLANGE 1:3.46, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
HOUSING REAR AXLE HOUSING WITH DIFFERENTIAL, AUTOMATIC FIVE-SPEED TRANSMISSION ETS/ASR 1:3.27, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
HOUSING REAR AXLE HOUSING WITH DIFFERENTIAL, MANUAL FIVE-SPEED TRANSMISSION ETS/ASR 1:3.46,F 381314 A 436535 F 483847 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 436536, F 483848 WITH CODE 806 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
HOUSING , Replaced By: A2023508914
5
HOUSING REAR AXLE CENTER ASSEMBLY W/O FLANGE 1:3.27, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
HOUSING ,F 870048
11
SCREW PLUG
11
SCREW PLUG , Replaced By: A0009972632
44
TAPERED ROLLER BEARING RING GEAR BEARING, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 3.7 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 3.9 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 3.6 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.2 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 3.95 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.0 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.60 MM
47
LOCK AS REQUIRED 3.8 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.50 MM
47
LOCK AS REQUIRED 4.1 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.3 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 3.85 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.4 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.05 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
47
LOCK AS REQUIRED 4.15 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
50
SEAL RING INTERIOR FLANGE, USED WITHOUT AUTOMATIC LOCKING DIFFERENTIAL (ASD) FOR USE WITHOUT ACCELERATION SKID CONTROL (A S R)
53
REPAIR KIT REAR AXLE HOUSING WITH DIFFERENTIAL
56
FLANGE INSIDE, USED WITHOUT AUTOMATIC LOCKING DIFFERENTIAL (ASD)
59
SPACER WASHER AS REQUIRED 1.15 MM
59
SPACER WASHER AS REQUIRED 0.7 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 1.05 MM
59
SPACER WASHER AS REQUIRED 1.0 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 0.95 MM, USED WITHOUT AUTOMATIC LOCKING DIFFERENTIAL (ASD)
59
SPACER WASHER AS REQUIRED 1.25 MM
59
SPACER WASHER AS REQUIRED 0.9 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 0.8 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 1.35 MM
59
SPACER WASHER AS REQUIRED 1.2 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 1.5 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 1.10 MM
59
SPACER WASHER AS REQUIRED 1.3 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
59
SPACER WASHER AS REQUIRED 0.85 MM
59
SPACER WASHER AS REQUIRED 1.4 MM, REAR AXLE HOUSING WITH DIFFERENTIAL,LESS SIDE BEARING CABS 003 103239 007 087551 086 007106 093 008992 102,103 240183 105 231729 183 015395 190 021957 193 002093 200 027295 280 000777 283 003632
62
SNAP RING AXLE SHAFT TO AXLE HOUSING
89
COVER END COVER, B 976853,F 258572
92
SCREW. HEXALOBULAR BOLT SUPPORT TO BRACKET M10X25
92
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
95
VALVE
