Поз.
Артикул
Описание
5
MICROPHONE , Replaced By: A2028200635
10
MICROPHONE RADIOPHONE
15
PLATE
20
SHEET METAL SCREW BRACKET TO FLOOR PLATE
25
PLATE DRILLING TEMPLATE
30
BRACKET
35
BRACKET RADIOPHONE
40
COVERTELEDUX
40
COVERING RADIOPHONE
40
COVERBOSCH
45
RIVET BUSHING AND LEVER TO CAB
50
SUPPRESSOR FILTER ON EQUIPMENT CARRIER
55
TRANSMITTER RADIO REMOTE CONTROL FOR TAXI ALARM CALL, J 93854220110401, Replaced By: A2118203197
55
SENDER. TRANSMITTER RADIO REMOTE CONTROL ACTIVATION, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 12296120010501, Replaced By: A2108201597
100
ELECTRIC CABLE SWITCH
105
PLUG HOUSING SWITCH TO CLUTCH PEDAL 2-PIN JPT2.8
115
SOCKET HOUSING. PIN BUSHING HOUSING FRONT MIRROR R 27, 2 PIN
120
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
120
CONTACT BUSHINGR 27, 0.75 MM2
125
PIN BUSHING HOUSING TELL-TALE LAMP ASD
130
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
165
CONTACT SPRING0.5-1.0 MM2
210
FLAT PLUG0.5-1.0 MM2
220
PLUG PEDAL OPERATION CONTACT SWITCH 6-PIN E95,S146
230
CONTACT SPRING0,5-1,0 MM
230
REP.SET CONTACT0.75 MM2 E95
240
PIN BUSHING HOUSING CONNECTOR, DASH SUPPORT WIRING HARNESS FRONT MIRROR HEATING X 209, 2 PINCODE A
250
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
250
PLUG PINX 209, 0.75 MM2
260
PLUG HOUSING
270
PLUG PIN
