Поз.
Артикул
Описание
8
FRONT AXLE BEAM ,6951998 000001
11
BOLT
14
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
17
NUT
20
STEERING KNUCKLE , Replaced By: A3163300120
20
STEERING KNUCKLE ,6951998 000001
23
BUSHING STEERING KNUCKLE,6951998 000001
26
SEAL RING STEERING KNUCKLE,6951998 000001
26
SEAL RING STEERING KNUCKLE,6951998 000001
29
THRUST WASHER INTERMEDIATE LEVER TO STEERING SUPPORT
38
SCREW , Replaced By: N000912008202
38
SCREW. CAP BOLT COVER TO CASE M8X25
41
NUT , Replaced By: A6753300088
41
NUT
44
GREASE NIPPLE PROTECTIVE TUBE
47
EXPANSION PLUG
50
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
50
SCREW , Replaced By: N308676012015
50
SCREW LEFT AND RIGHT CONSOLES TO CAB
53
NUT STRAP TO SUPPORT
56
PLUG TO PLUG HYDRAULIC LINE
59
KING PIN PARTS KIT,STANDARD 30 MM,6951998 000001
62
KINGPIN STANDARD SIZE I,6951998 000001
65
TAPERED ROLLER BEARING STEERING KNUCKLE,6951998 000001
65
ROLLER BEARING STEERING KNUCKLE,6951998 000001
65
ROLLER BEARING STEERING KNUCKLE,6951998 000001
68
SPACER WASHER0.90 MM
68
SPACER WASHER1.00 MM
68
SPACER WASHER1.10 MM
68
SPACER WASHER1.20 MM
68
SPACER WASHER1.30 MM
68
SPACER WASHER1.40 MM
68
SPACER WASHER1.50 MM
68
SPACER WASHER1.60 MM
68
SPACER WASHER1.70 MM
68
SPACER WASHER2.10 MM
71
OIL COLLECTOR ,6951998 000001
74
RING
74
RING
77
SEAL RING
77
SEAL RING
86
TAPERED ROLLER BEARING
86
TAPERED ROLLER BEARING
86
TAPERED ROLLER BEARING
92
WHEEL MOUNTING BOLT
95
TAPERED ROLLER BEARING , FROM CHASSIS 791607-910369 ALSO INSTALLED ON 500000-501455
95
TAPERED ROLLER BEARING , FROM CHASSIS 791607-910369 ALSO INSTALLED ON 500000-501455
95
TAPERED ROLLER BEARING , FROM CHASSIS 791607-910369 ALSO INSTALLED ON 500000-501455
98
HUB CAP
999
STEERING ARM , Replaced By: A3163380708
999
STEERING ARM , Replaced By: A3163380707
999
STEERING ARM , Replaced By: A3163380306
999
STEERING ARM , Replaced By: A3163380305
999
SPACER RING , ELIMINATED - NO LONGER REQUIRED
999
BUSHING , Replaced By: A3163320048
999
FRONT AXLE BEAM , Replaced By: A3163310201
999
TIE ROD , Replaced By: A3163300603
999
WHEEL MOUNTING BOLT , Replaced By: A3144020071
999
SPACER WASHER , Replaced By: A3143320452
999
HUB CAP , Replaced By: A3183340025
999
SEAL RING , Replaced By: A0089977546
