Поз.
Артикул
Описание
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
6
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
6
BANJO UNION , Replaced By: N915052006013
10
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
10
PLASTIC PIPE RISING PIPE 4X6 MM
15
SLEEVE LINE CONNECTION
17
UNION NUT LINE CONNECTION
19
GLAND LINE CONNECTION
25
ANGLE LINE MOUNTING
55
SWITCH , Replaced By: A0005456009
55
SWITCH EXHAUST BRAKE,K 251255
60
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
60
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
60
VALVE , Replaced By: A0004342301
60
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342101
60
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342301
62
HANDLETO 000 434 23 01
63
CUP , Replaced By: A0004340486
63
CUPTO 000 434 10 01
63
CUP 3/2-WAY VALVE WABCO
64
SEAL RINGTO 000 434 23 01
64
SEAL RINGTO 000 434 23 01
64
SEAL RINGTO 000 434 21 01
66
STRAINERTO 000 434 21 01
67
REPAIR KIT 3/2-WAY VALVE WABCO
67
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
67
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 427
67
REPAIR KIT 3/2-WAY VALVE BOSCH
67
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 428
78
SPRING WASHER AT CAB FLOOR
80
NUT SUCTION LINE TO OIL PUMP
85
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
85
TS DOUBLE FITTING SOLENOID VALVE
85
FITTING , Replaced By: A0029906071
85
FITTING , Replaced By: A0039979072
90
SEAL RING LINE CONNECTION
101
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
102
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
103
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
104
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
105
FITTING LINE CONNECTION, Replaced By: N000000006446
107
SEAL RING LINE CONNECTION
110
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
110
BREATHER , Replaced By: A3933280065
113
SWITCH EXHAUST BRAKE,K 251255
115
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
116
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
119
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
122
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
125
FITTING LINE CONNECTION, Replaced By: N000000006446
128
SEAL RING LINE CONNECTION
999
SEAL RING VALVE TO CAB,4 278267
999
SPRINGTO 000 434 21 01
999
FITTING , Replaced By: A0019972572
999
BUSHINGTO 000 434 10 01
