Поз.
Артикул
Описание
5
BREATHER AT FRAME ABOVE FUEL TAK
8
DAMPING STRIP AT FRAME ABOVE FUEL TAK
11
HOSE FROM LEFT FUEL TANK TO DEAERATION PIPE
17
HOSE ADDITIONAL FUEL TANK, ORDER BY THE METER
20
HOSE ADDITIONAL FUEL TANK, ORDER BY THE METER
23
HOSE ADDITIONAL FUEL TANK, ORDER BY THE METER
29
HOSE BETWEEN BREATHER AND GRAVITIY VALVE
35
LOOM TIE FUEL HOSE TO RETURN LINE
35
LOOM TIE , Replaced By: A1049970190
41
GROMMET FOR PASSAGE OF LINE
41
GROMMET
44
LOOM TIE
47
VALVE COMBINATION VALVE,906515
50
HOSE TO ELEMENT AT FRONT SEAT
52
HOSE *** 30 MM
54
CLIP BELT LOCK TO SEAT RAIL
56
BOOTTO 116 540 01 81
59
BRACKET GRAVITY VALVE
62
RIVET TYPE PLATE
65
HOSE FUEL LINE TO TANK 13.5 X 7.5 MM, ORDER BY THE METER
68
LOOM TIE
71
HOSE (VENT VALVE), 055662 903941
74
HOSE IN WHEELHOUSE,BETWEEN BREATHER PIPES 90 MM, ORDER BY THE METER
83
LOOM TIE LINE MOUNTING
86
LOOM TIE
89
LOOM TIE
