Поз.
Артикул
Описание
5
TANK EXPANSION TANK
5
TANK
8
FILLER CAP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 205503, Replaced By: A1245000406
8
CLOSING COVER RADIATOR
11
SWITCH COOLING WATER LEVEL INDICATOR
14
SEAL RING
17
LOCK RING MAIN SHAFT,FRONT
20
BRACKET EXPANSION TANK
23
BRACKET EXPANSION TANK
26
SCREW BRACKET ON LOAD SENSOR
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
29
WASHER COMPRESSED AIR LINE TO BRACKET
32
TANK OVERFLOW
74
WASHER COMPRESSED AIR LINE TO BRACKET
74
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
77
NUT BALL PIVOT TO LEVER
86
SCREW BRACKET ON LOAD SENSOR
95
INSULATING HOSE16X1 MM, ORDER BY THE METER
98
CLAMP DE-AERATION LINE TO RADIATOR
110
SHEET METAL SCREW CONTROL UNIT TO CAB B 5.5X19
113
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
116
NUT BALL PIVOT TO LEVER
119
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
119
WASHER COMPRESSED AIR LINE TO BRACKET
156
VALVE (CHECK VALVE)
158
RECIRCULATING PUMP , Replaced By: A0008354164
158
RECIRCULATING PUMP. PUMP , NOT FOR AUSTRALIA
158
RECIRCULATING PUMP"SWF",5/91
158
PUMP
160
CLAMP PUMP TO WHEELHOUSE
162
BUSHING USED WITHOUT AUXILIARY HEATER, USED WITHOUT AUXILIARY HEATER
164
SCREW PLUG SOCKET TO REAR CROSS MEMBER
166
LOCK WASHER STEP SWITCH
168
WASHER BOOT TO CAB FLOOR
168
WASHER , Replaced By: N000433005304
170
NUT TACHOGRAPH TO BRACKET
172
RUBBER BUFFER COVERING TO FRAME
174
WASHER EXHAUST MUFFLER TO STRAP
174
WASHER , Replaced By: N000125008443
176
NUT
186
VALVE AT HEATER
188
BRACKET CONTROL VALVE
190
CLIP CONTROL VALVE
192
GROMMET HOSE TO FIRE WALL
195
LOOM TIE
195
LOOM TIE. CLAMP HOSE FASTENING
195
CLAMP PRESSURE REGULATOR
195
CLAMP25-40X13 MM
195
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
195
CLAMP FLEXIBLE SHAFT TO GROUND CABLE, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
195
HOSE CLAMP LINE MOUNTING
195
CLAMP , Replaced By: A0069974390
195
CLAMP , Replaced By: A0069970590
195
CLAMP , Replaced By: A0069970490
195
CLAMP , Replaced By: N000000000667
195
CLAMP , Replaced By: A0059970190
195
CLAMP , Replaced By: A1409950036
195
CLAMP , Replaced By: A0059970190
195
LOOM TIE , Replaced By: N000000000668
999
HOSE BETWEEN CHECK VALVE AND RECIRCULATING PUMP, 075636 906620
999
HOSE FROM HEATER UNIT TO CHECK VALVE, 075636 906620
999
HOSE BETWEEN CHECK VALVE AND RECIRCULATING PUMP, 075635 906619
999
HOSE FROM PIPE LINE TO CHECK VALVE, 075635 906619
999
HOSE FROM HEATER UNIT TO CHECK VALVE, 075635 906619
999
CLAMP6/14-15 MM
999
CLAMP
