Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
11
CLIP
14
KICK-DOWN SWITCH , FROM CHASSIS: 011: 12/52 100001 007,008,015,017: 12/52 200001
17
SEAL RING KICK-DOWN SWITCH
20
LEVER ACCELERATOR PEDAL
23
BEARING PEDAL LEVER TO FRONT PANEL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
26
LOCK RINGTO 000 553 37 01,000 553 39 01,
29
FITTED WASHER ACCELERATOR PEDAL BEARING,B 838714,J 003392
32
SCREW LICENSE PLATE TO BRACKET
32
SCREW , Replaced By: N304017006020
32
SCREW PUMP TO BRACKET
35
WASHER COMPRESSED AIR LINE TO BRACKET
38
SPRING WASHER LICENSE PLATE TO BRACKET
41
SERRATED WASHER BRACKET TO CAB FLOOR,4 411811
47
SPRING
47
SPRING
50
WIRE CABLE , Replaced By: A4633004130
50
WIRE CABLE480 MM, A 698508 X 012426 EXEPT FOR VEHICULES WITH CODE 808
50
BOWDEN CABLE TO ACCELERATOR PEDAL LEVER, X 16755320060816
53
SHIM
56
RUBBER BUFFER WIRE CABLE TO FIRE WALL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
59
CIRCLIP PIN TO CLUTCH SLAVE CYLINDER BOOT
59
LOCK PLATE PIN TO CLUTCH SLAVE CYLINDER BOOT, Replaced By: N006799005004
62
SENDER UNIT (PEDAL VALUE SENSOR)
65
LEVER (REVERSING LEVER), A 698508 X 012426 EXEPT FOR VEHICULES WITH CODE 808 ALSO INSTALLED IN VEHICLE TO A 698507, X 012425 WITH CODE 809
68
BALL PIVOT
71
ROLLER , NOT USED
74
LOCK PLATE , 656999
77
LOCK PLATE ROLLER TO LEVER
80
SCREW PUMP TO BRACKET
83
SPRING , NOT USED
86
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
89
SPRING WASHER , Replaced By: N000137008212
89
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
92
NUT
999
PAD , 000 112328 003 056792 007 046654 083 000998 086 000712 093 000557 102,103 091560 105 115062 183 001323 190 001262
