Поз.
Артикул
Описание
5
DASHPOT. STRAINER VACUUM LINE
11
INDUCTOR VACUUM PUMP
11
THROTTLE , Replaced By: A1231580057
17
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
23
BRANCH-OFF FITTING
23
BRANCH-OFF FITTING INCREASE IN TRANSMISSION SHIFT POINT & 2 SELECTION PROGRAMS, F 140421 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM F 140422 WITH CODE 806
29
LINE. HOSE FROM VACUUM CONTROL VALVE TO PASSENGER COMPARTMENT 4 MM, ORDER BY THE METER
29
HOSE , Replaced By: A0019978152
35
HOSE TO ELEMENT AT FRONT SEAT
41
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
41
HOSE , ORDER BY THE METER
44
HOSE FROM STEERING LOCK TO VACUUM PUMP LINE 830 MM
47
PIPE LINE ADVANCE RETARD MECHANISM,RED 460 MM, ORDER BY THE METER
53
HOSE
56
LOOM TIE , 962 12/52,22/62 000028 EXCEPT FOR 000023,000026,000027 961 12/52,22/62 003837 EXCEPT FOR 003172,003173,003300,003301,003423,003624,003635,003636,003697,003700,003816.
59
LOOM TIE , Replaced By: A0019974190
59
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
62
HOSE CLAMP. CLAMP , UP TO ENGINE 602.962 12/52,22/62 007728 EXCEPT FOR 007701,007702,007716-007718,007722-007726
65
CLAMP RISING PIPE,5 4734955 909351
65
LOOM TIE , Replaced By: N916002008100
68
CLAMP , Replaced By: A0009955244
68
CLAMP
71
BRACKET LINE MOUNTING 11 MM
71
CLAMP , Replaced By: A0004760436
74
CLAMP HOSE TO HOSE 20 MM
77
HOSE MASTER SWITCH AND VACUUM SWITCH 40 MM, 023 164780 033 066774 123 158077 130 172061
83
INSULATING HOSE ELECTRONICS AT SUPPORT, ORDER BY THE METER
83
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
