Поз.
Артикул
Описание
290
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
290
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
294
SEAL RING SOLENOID VALVE A 18X24
298
LINE FROM STEERING TO HIGH PRESSURE HOSE, CIRCUIT I
302
LINE FROM STEERING TO HIGH PRESSURE HOSE, CIRCUIT I
306
LINE FROM HIGH PRESSURE HOSE TO POWER CYLINDER,CONNECTION: "C"
310
LINE FROM HIGH PRESSURE HOSE TO POWER CYLINDER,CONNECTION: "D"
314
UNION NUT LINE CONNECTION, Replaced By: N000000006239
314
UNION NUT LINE CONNECTION
318
GLAND , Replaced By: A0019901967
318
SEAL CONE LINE CONNECTION
322
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
322
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
322
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
326
LINE FROM STEERING TO HIGH PRESSURE HOSE, CIRCUIT II
330
LINE FROM STEERING TO HIGH PRESSURE HOSE, CIRCUIT II
334
LINE FROM HIGH PRESSURE HOSE TO POWER CYLINDER,CONNECTION: "B"
338
UNION NUT LINE CONNECTION, Replaced By: N000000006239
338
UNION NUT LINE CONNECTION
342
SEAL CONE LINE CONNECTION
342
GLAND , Replaced By: A0019901967
346
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
346
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
346
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
350
BRACKET LINES TO SIDE MEMBER
354
BRACKET COVERING
358
BRACKET LINES TO SIDE MEMBER
362
BRACKET DELIVERY LINE TO FRAME
366
BRACKET DELIVERY LINE TO POWER CYLINDER
370
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
374
CLAMP DELIVERY AND SUCTION LINES TO STEERING
374
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
378
FITTING POWER CYLINDER,STEERING CONNECTION, CIRCUITS I AND II
382
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
382
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
386
SEAL RING SOLENOID VALVE A 18X24
999
BRACKET LINE TO TRANSMISSION
