Поз.
Артикул
Описание
200
P.T.O. FOR BREAK-DOWN,SEE UNIT STANDARD VERSIONMODEL: 723.6
200
P.T.O.NA 859-C/34 (NL6)
200
P.T.O. FOR BREAK-DOWN,SEE UNIT STANDARD VERSIONMODEL: 723.620-683, FOR COMPONENT PARTS SEE SPARE PARTS LIST
200
P.T.O.NA 859-C/28 (NL7)
200
P.T.O.NA 859-C/24 (NL9)
200
P.T.O.I 1:1,71, COMPONENT PARTS NOT AVAILABLE
200
P.T.O.NA 859-C/31 (NL4)
205
CONNECTOR
210
HOSE P.T.O. LUBRICATION 1066MM
210
HOSE P.T.O. LUBRICATION 673 MM
220
SWITCH P.T.O. INDICATOR ACTUATION
225
PARTS KIT P.T.O. TO TRANSMISSION
230
PIN P.T.O. MOUNTING PARTS
235
LINE P.T.O. LUBRICATION
237
T-FITTING LINE CONNECTION
238
VALVE BODY ASSEMBLY P.T.O., UP TO 01.2010
240
VALVE HOUSING,BOTTOM, UP TO 01.2010
242
TS SOLENOID VALVE HOUSING,BOTTOM, FROM 02.2010
245
GASKET HOUSING,BOTTOM, UP TO 01.2010
247
COVER HOUSING,BOTTOM, UP TO 01.2010
249
BOLT W FLANGE HOUSING,BOTTOM ZOLLGEWINDE
250
GASKET HOUSING,TOP
255
PLUG
257
HEXAGON HEAD FIT BOLT
265
SEALING RING
265
SEAL RING
270
SEAL RING BEARING COVER
275
SPRING
280
SEAL RING
285
PLUG PLUG SOCKET M 27X1
290
FITTING
293
FLANGE
295
COVER P.T.O. FLANGE
298
DECALCOMANIA TO PLUG HYDRAULIC PUMP CONNECTION OPENING
300
GASKET COVER TO FLANGE
305
HEXALOBULAR BOLT BRACKET TO SIDE MEMBER M12X25,229552
