Поз.
Артикул
Описание
27
PULL ROD FROM INTERMEDIATE LEVER TO DETENT LEVER
33
SECURING CLIP. CIRCLIP
38
BRACKET INTERMEDIATE LEVER
44
LOCK WASHERROCKINGER TYP 59 G140,59 G150
48
SCREW WIRE CABLE TO TRANSMISSION
53
LEVER (INTERMEDIATE LEVER),TRANSMISSION, ON TRUCKS FROM CHASSIS 165464-290001,ON BUSES FROM CHASSIS 020079-290001
59
BALL PIVOT BOTTOM B13X5 MM
66
SCREW BRACKET TO FRAME SIDE MEMBER
70
WASHER STRUT TO CROSS MEMBER
74
BUSHING INTERMEDIATE LEVER TO CONSOLE
79
NUT , Replaced By: N910113010000
79
NUT STRAP TO BRACKET
85
PULL ROD FROM INTERMEDIATE LEVER TO SHIFT LEVER
89
SECURING CLIP. CIRCLIP
94
LEVER GEARSHIFT LEVER LOWER PART
98
BUSHING
104
BUSHING , 114.005,007,015 037181 114.010 033492 114.021 001931 114.022 002382 115.000,002,010 037475 115.015 035971 115.100,102,110 085311 115.115 039087
109
GUIDE PULL ROD TO SHIFT LEVER
113
SCREW SOLENOID VALVE TO TRANSMISSION CASE TOP COVER M 6X32,002,003,006-009 4 263014-4 422632,034,134 4 276784-4 422632
117
WASHER COMPRESSED AIR LINE TO BRACKET
117
WASHER , Replaced By: N009021006208
121
NUT , Replaced By: N913004006001
121
NUT PUMP TO BRACKET
128
BEARING BRACKET
135
BOOT BEARING BRACKET TO CAB FLOOR
141
SHIM BEARING BRACKET TO CAB FLOOR
147
PIVOT PIN LEVER TO BEARING BRACKET
152
LOCK LEVER TO BEARING BRACKET
158
SCREW BRACKET TO TAIL LAMP BRACKET
163
SPRING WASHER ALTERNATOR CONNECTION D+
170
SHIFT LEVER
177
BALL PIVOT
183
PIVOT PIN SHIFT LEVER
188
SPRING SHIFT LEVER
193
HANDLE , 108.018,019 071883 EXCEPT FOR 071802,071873 109.016 UNTIL PRODUCTION STOP 109.056 003758 111.024,025 005065 111.026,027 002941
199
BRACKET , ON TRUCKS UP TO CHASSIS 156152,ON BUSES UP TO CHASSIS 020033
207
LOCK WASHER LINE MOUNTING, TRUCKS UP TO CHASSIS 171900,BUS UP TO CHASSIS 024088 OR UP TO ENGINE 188371
211
SCREW BRACKET TO FLYWHEEL HOUSING
217
CLAMPING PIECE LINE MOUNTING, ON TRUCKS UP TO CHASSIS 156152,ON BUSES UP TO CHASSIS 020033
221
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
224
NUT , Replaced By: N913002006009
224
NUT OIL TANK TO BRACKET
231
YOKE GEARSHIFT MECHANISM, ON TRUCKS UP TO CHASSIS 156152,ON BUSES UP TO CHASSIS 020033
236
GUIDE GEARSHIFT MECHANISM, ON TRUCKS UP TO CHASSIS 156152,ON BUSES UP TO CHASSIS 020033
240
SCREW TWO-WAY VALVE TO BRACKET
244
WASHER , Replaced By: N009021005205
244
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
248
NUT DIODE TO BRACKET,5 922534
274
CLAMPING PIECE LINE MOUNTING, ON TRUCKS FROM CHASSIS 156442-263695,ON BUSES FROM CHASSIS 020034-263695,FROM CHASSIS 263696 SEE MICRO FICHE 723.0 ONLY FOR USE WITH HYDRAULIC MODULATOR
279
CLAMP LINE MOUNTING, ON TRUCKS FROM CHASSIS 156442-263695,ON BUSES FROM CHASSIS 020034-263695,FROM CHASSIS 263696 SEE MICRO FICHE 723.0 ONLY FOR USE WITH HYDRAULIC MODULATOR
284
SHIM DELIVERY LINE IN CLAMPING PIECE, ON TRUCKS FROM CHASSIS 156442-263695,ON BUSES FROM CHASSIS 020034-263695,FROM CHASSIS 263696 SEE MICRO FICHE 723.0 ONLY FOR USE WITH HYDRAULIC MODULATOR
290
SCREW , Replaced By: N304017006018
290
SCREW COVER PLATE TO COVER PLATE M 6 X 12
323
BRACKET
329
SCREW COVER PLATE TO BRACKET
333
SPRING WASHER LICENSE PLATE TO BRACKET
336
WASHER BRACKET TO TRANSMISSION
341
PULL ROD
346
BALL SOCKET
442
EXPANSION PLUG BREATHER HOSE THRU FLOOR PLATE,775095
448
EXPANSION PLUG ELECTRIC CABLE THRU FIRE WALL,4 9400475 187082
477
PROTECTIVE PLATE HAND BRAKE
482
STOP HAND BRAKE
487
SCREW BRACKET TO COVERING
487
SCREW , Replaced By: N000000001145
491
NUT , Replaced By: N913004006001
491
NUT PUMP TO BRACKET
497
COVER
999
CLAMP , Replaced By: N000000001045
999
CLAMP , Replaced By: N916016010211
999
CLAMP LINE CONNECTION
999
NUT. UNION NUT RETURN
999
UNION NUT LINE MOUNTING,5 9363655 812730
999
BALL-TYPE NIPPLE. SEAL CONE OIL LINES
999
BALL-TYPE NIPPLE. SEAL CONE , Replaced By: A3449907067
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N913004006001
999
NUT TWO-WAY VALVE TO BRACKET
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
HOSE COOLING WATER LINE TO AIR COMPRESSOR, ORDER BY THE METER
999
SCREW CONTROL UNIT TO CAB
999
SHEET METAL SCREW HAND BRAKE ROD WITH COVERING TO CAB FLOOR
999
GLAND LINE MOUNTING,5 9363655 812730
999
SCREW HANDLE TO LID
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
CLAMP CABLE HARNESS MOUNTING
999
CLAMP LINE MOUNTING
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SHIM , Replaced By: A3520780186
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
CLAMP
999
ROD , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 565454, Replaced By: A3102900439
999
CLAMP , Replaced By: A3179950832
999
BRACKET FUEL LINES
999
BRACKET FUEL LINE
999
BRACKET FUEL LINE
999
ENGINE CROSS MEMBER , Replaced By: A3103120407
999
BRACKET PEDAL ASSEMBLY
999
RADIATOR , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 290001, Replaced By: A3095003602
999
SPACER TUBE MASTER CYLINDER TO CONSOLE TO 000 295 91 06
999
INTERMEDIATE PIECE FROM CLUTCH MASTER CYLINDER TO RESERVOIR
999
HOSE FROM CLUTCH HOSE TO SLAVE CYLINDER
999
SPRING RETAINER SPRING TO PUSH ROD
999
PEDAL ,275293-526086, Replaced By: A3092902216, +001A3102900339, +001A1232950150, +001N000931008047, +001N913004008004
999
BRACKET CLUTCH PEDAL AND BRAKE PEDAL,314243
999
LINE FEED
999
LINE RETURN
999
LINE , Replaced By: A3092701996, +001A0009974452
999
LINE , Replaced By: A3092701896, +001A0009974452
999
LEVER , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 290001, Replaced By: A3092603837
999
LEVER (INTERMEDIATE LEVER),TRANSMISSION, ON TRUCKS UP TO CHASSIS 165463,ON BUSES UP TO CHASSIS 020078
999
NUT ROD TO LEVER,526440
999
STOP
999
WASHER PEDALS TO PIVOT PINS
999
ROD
999
GROMMET , Replaced By: A1079970881
999
SPRING (DEAD CENTER SPRING) 35 MM
999
EXPANSION PLUG VENTILATION BORE IN WHEELHOUSE, ONLY FOR REPAIR PURPOSES
999
BUSHING
999
BUSHING , Replaced By: A1242920050
999
PAD , Replaced By: A1072910182
999
HOSE CLAMP HOSE FASTENING 9/13MM
999
GROMMET PLUG SOCKET
999
CLAMP , Replaced By: N916016010201
999
LOCK AT WATER EXPANSION TANK
999
SEAL CONE
999
MASTER CYLINDER , 000,003,007,102,103,105,200 A 091118 083,086,093,183,190,193,280,283 F 015866, Replaced By: A0012954406, +001A0002950833
