Поз.
Артикул
Описание
200
PLASTIC PIPE RISING PIPE 4X6 MM
200
PLASTIC PIPE RISING PIPE 4X6 MM
200
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
208
HOSE LEAK LINE, ORDER BY THE METER
212
UNION NUT
214
SEAL CONE
214
GLAND , Replaced By: A0019901667
215
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
216
SLEEVE LEAK LINE
216
BUSHING , Replaced By: N915062004000
273
SEAL RINGTO 000 429 28 95,GRAU
423
RUBBER RINGTO 001 431 43 05,002 431 05 05, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
426
SEAL RINGBOSCH
429
VALVE DISCTO 001 431 43 05,BOSCH-TEVES
429
VALVE DISC , Replaced By: A0004312781
432
CUPTO 001 431 43 05,BOSCH-TEVES, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
436
VALVE DISCTO 001 431 43 05,BOSCH-TEVES
440
WHEEL BRAKE CYLINDER SLAVE CYLINDER SCHAEFER,TO001 431 94 05,002 431 05 05, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
440
WHEEL BRAKE CYLINDER SLAVE CYLINDER TEVES,TO 001 431 35 05,001 431 43 05, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
443
VALVE CLUTCH SLAVE CYLINDER
443
VALVE , Replaced By: A3075530107
443
BLEEDER VALVE , Replaced By: A0004310265
443
BLEEDER VALVE , Replaced By: A0004310265
446
PROTECTIVE CAP ,5 962906
446
PROTECTIVE CAP , Replaced By: A0004217187
446
PROTECTIVE CAP , Replaced By: A0004210887
450
REPAIR KIT COMPRESSED AIR CYLINDER TO 001 431 35 05,001 431 94 05,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
454
REPAIR KIT VALVE DISC TO 001 431 43 05,002 431 05 05,BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
458
REPAIR KIT SLAVE CYLINDER TO 007 420 21 18,TEVES, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
459
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
461
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
462
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
462
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
462
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
462
NUT , Replaced By: N913004008001
466
BRACKET ,4 315692
468
SCREW REAR EXHAUST PIPE TO MUFFLER
470
NUT STRAP TO BRACKET
470
NUT , Replaced By: N910113010000
474
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
476
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
480
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
480
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
480
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
480
TEST CONNECTION
483
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
485
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
493
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
495
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
497
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
499
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
502
LOOM TIE LINE MOUNTING 280 MM
999
VALVETO 003 429 04 44,WABCO
999
REPAIR KITTO 000 429 27 95,WABCO
999
FITTINGWABCO
999
GUIDE , Replaced By: N071752014000
999
CUPTO 007 420 68 18,WABCO
999
CUP , Replaced By: A0004213886
999
SEAL RINGKNORR
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
FILTER ELEMENTTO 000 429 28 95,GRAU
999
VALVE (CHECK VALVE)
999
FILTER ELEMENT MAJOR TO 000 429 27 95,WABCO
999
FILTER ELEMENT MINOR TO 000 429 27 95,WABCO
999
DIAPHRAGM , Replaced By: A0004290745
999
THRUST WASHERTO 003 429 12 44,SCHAEFER
999
SEAL CONETO 003 429 12 44,SCHAEFER
999
DIAPHRAGM
999
FILTER ELEMENTTO 000 429 25 95,BOSCH
999
DIAPHRAGMTO 000 429 25 95,BOSCH
999
AIR CLEANERBOSCH
999
AIR CLEANERKNORR
999
AIR CLEANERWABCO
999
AIR CLEANERGRAU
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KITTO 001 431 47 06,WABCO 2210, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KITTO 001 431 84 06,KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BRAKE POWER REGULATOR
999
REPAIR KIT , Replaced By: A0024209824, +002A0024209424
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KIT SEAL RING BOSCH,209
999
REPAIR KIT (SERVICE BRAKE VALVE) WABCO
999
GASKET34X2X6 MM,GRAU
999
VALVE SEATGRAU
999
DIAPHRAGMTO 007 420 42 18,KNORR
999
DIAPHRAGMBOSCH,K 262627
999
VALVE
999
VALVEWABCO
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
SEALING CORDTO 000 429 27 95, WABCO
999
CROSS FITTING AIR RESERVOIRS I AND II,4 821954 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
CONNECTOR REPAIR SIZE
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
PLUG
999
VALVE (RELAY VALVE) GRAU
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 90 18, BOSCH
999
PROTECTIVE CAPTO WABCO
999
CUPTO 002 431 04 06,BOSCH
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
SPRINGBOSCH
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034315006
999
SWITCH SUPPLY PRESSURE
999
SEALING CORD38X8 MM
999
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
999
BANJO UNION BETWEEN THE LINES,5 298635
999
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
FITTING PRESSURE REGULATOR,CONNECTION: "40"
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
FITTING SHUTTLE VALVE,CONNECTION: "20"
999
SEAL RINGTO 000 429 25 95,BOSCH
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
REPAIR KIT. BRAKE CYLINDER DIAPHRAGM PART TO 007 420 42 18, KNORR
999
REPAIR KIT DIAPHRAGM PART KNORR, Replaced By: A0024209524
999
VALVE
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820, Replaced By: A0034315006
999
VALVE , Replaced By: A0034315006
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KIT , Replaced By: A0034303881
999
REPAIR KITTO BOSCH
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 433281
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
FITTING RELAY VALVE,CONNECTION: "40",5 359430
999
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
REPAIR KITTO 001 430 56 81,001 430 57 81
999
REPAIR KITTO 000 430 66 81,000 430 67 81, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
REPAIR KITTO 001 431 87 06,KNORR
999
SEAL RING8X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING4 X 1.50 MM, 415 5 014668 416 5 000515 417 4 972023
999
CHAIN LOCK LINK ,4 652830
999
SEAL RING5X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING BRAKE HOSE
999
FITTING , Replaced By: A0029906171
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RING34.6X2.6 MM
999
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
999
SEAL RING56X1.7 MM
999
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RINGTO 001 431 43 05
999
SEAL RING , Replaced By: A0049970248
999
SEAL RINGTO 000 429 25 95,BOSCH
999
SEAL RINGTO 000 429 27 95, WABCO
999
ANGLE LINE MOUNTING
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET BUMPER,RIGHT, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET LINE MOUNTING
999
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
999
BRACKET COMPRESSED AIR LINE TO BUMPER STRUT
999
BEARING BRACKET WHEEL CYLINDER, IN CASE OF CAST AXLE
999
BRACKET RIGHT COMPRESSED AIR LINES
999
BRACKET , Replaced By: A6154200186
999
SEAL RING TO SEAL CABLE HARNESS OPENING IN CAB
999
LOCK BRAKE HOSE TO ANGLE
999
BRACKET BREATHER LINE TO SIDE MEMBER
999
BRACKET PRESSURE RATIO VALVE,5 180559
999
BRACKET PRESSURE RATIO VALVE,5 180559
999
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
999
BRACKET AIR CLEANER,5 007175
999
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
999
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES,5 329400
999
BRACKET RELAY VALVE
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
COTTER PIN STRAP TO SUPPORT
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER RADIATOR TO RUBBER MOUNTING
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
