Поз.
Артикул
Описание
44
BEARING COVER LEFT OUTSIDE
44
BEARING COVER INTERLOCK
44
BEARING COVER , Replaced By: A9452683634
44
BEARING COVER , Replaced By: A9452687434
44
BEARING COVER , Replaced By: A9452685434
44
BEARING COVER , Replaced By: A9452687634
47
NEEDLE BEARING BEARING COVER
47
NEEDLE BEARING ON DRIVE END
50
CYLINDRICAL PIN BEARING COVER 10X40 MM
56
PIN INTERLOCK
59
ROLL PIN. CLAMPING SLEEVE
65
BUSHING INTERLOCK
65
BUSHING , Replaced By: A9452682650
65
BUSHING INTERLOCK
68
SCREW CLAMP ON BRACKET
87
BEARING COVER
87
BEARING COVER RIGHT OUTSIDE, Replaced By: A9452602113
87
TRANSMISSION CASE COVER RIGHT OUTSIDE
87
TRANSMISSION CASE COVER RIGHT OUTSIDE
87
BEARING COVER RIGHT OUTSIDE
88
SHIFTING CYLINDER (GEAR CYLINDER)
89
SHIFTING CYLINDER (GEAR CYLINDER)
90
VALVE , Replaced By: A9452601957
90
PNEUMATIC SHIFT VALVE
93
SHIFTING CYLINDER PARTS KIT
94
SCREW. UNION SCREW LINE CONNECTION
95
LOCK LINE CONNECTION
96
LOCK RING LINE CONNECTION
97
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, VOSS 230
98
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
99
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
100
SEAL RING. REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
101
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
107
NEEDLE BEARING BEARING COVER,INSIDE
107
NEEDLE BEARING BEARING COVER,INSIDE
107
NEEDLE BEARING INSIDE AND OUTSIDE
107
NEEDLE BEARING INSIDE AND OUTSIDE
107
NEEDLE BEARING , Replaced By: A0219814710
110
SEAL RING BEARING COVER TO TRANSMISSION CASE
110
SEAL RING BEARING COVER TO TRANSMISSION CASE
110
SEAL RING BEARING COVER TO TRANSMISSION CASE
113
CYLINDRICAL PIN
116
THREADED PIN TRANSMISSION CASE TO TRANSMISSION CASE
119
SHIFTING SEGMENT GEAR INTERLOCK
119
SHIFTING SEGMENT GEAR INTERLOCK
119
SHIFT SEGMENT GEAR INTERLOCK
119
SHIFTING SEGMENT , Replaced By: A9452681546
119
DETENT , Replaced By: A9452680746
119
SHIFTING SEGMENT , Replaced By: A9452680446
119
SHIFTING SEGMENT BEARING COVER
122
CLAMPING PIN SHIFTING SEGMENT
122
SLEEVE
125
HEXALOBULAR BOLT SHIFTING SEGMENT TO BEARING COVER M8X25
125
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
125
SCREW , Replaced By: N910143008002
128
SEAL RING VALVE TO SHIFTER COVER
131
HEXALOBULAR BOLT TRAVEL SENSOR TO FRAME SIDE MEMBER M8X70,V 207570
131
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
131
HEXALOBULAR BOLT COUPLING FLANGE TO P.T.O. M8X50
131
SCREW , Replaced By: N910105008019
131
SCREW CLAMP ON BRACKET
131
HEXALOBULAR BOLT SOLENOID VALVE TO BRACKET M8X100
999
SEALANT CASE UPPER PART TO CASE LOWER PART LOCTITE 50ML
